Mitsubishi Electric - ET-N150 Electronic Motor Protection Relay (150A frame, 40 to 150A Setting Range)

Mitsubishi Electric - ET-N150 Electronic Motor Protection Relay (150A frame, 40 to 150A Setting Range)

Mitsubishi Electric MS-T/N series ET-N150 electronic motor protection relay that detects overload including locked rotor, open phase including current imbalance, and reverse phase conditions during AC motor starting and running. 150A frame covering current settings 40 to 150A across 1 setting designation, with a setting range of three to four times the minimum scale.

Key features

  • A protection mode switch selects overload only, overload plus open phase, or overload plus open phase plus reverse phase, and the overload operating time is selectable between 3, 5, 7, 15 and 30 seconds at 600 percent of the setting current
  • Independent 1a1b output contacts can be used on different voltage circuits, indicators show power, overload, open phase and reverse phase status as well as load run and stop, and a self diagnosis function trips the relay on an internal fault
  • Operating voltage AC100V or AC200V with 85 to 110 percent tolerance, manual reset, main circuit terminal connection with no need to wind the main circuit conductor

Specifications

Type Electronic motor protection relay
Frame N150 150A frame
Current Setting Designation 150A
Current Setting Range 40 to 150A
Applicable Motor Capacity 11 to 37kW at 200-220V, 22 to 75kW at 400-440V
Rated Insulation Voltage 660V 50/60Hz main circuit
Operating Voltage Tolerance 85 to 110 percent of rated voltage
Output Contact 1a1b with independent a and b contacts usable on different voltage circuits
Output Contact Rating AC240V 1A, AC120V 2A under AC-15 class
Reset Manual reset
Overload Operating Current 115 plus or minus 5 percent of the setting
Overload Operating Time 3, 5, 7, 15 or 30 seconds selectable at 600 percent of the setting current
ET-N150 150A AC100V ET-N150 electronic motor protection relay, 150A setting, AC100V control | Type: Electronic motor protection relay | Frame: N150 150A frame | Current Setting Designation: 150A | Current Setting Range: 40 to 150A | Applicable Motor Capacity: 11 to 37kW at 200-220V, 22 to 75kW at 400-440V | Operating Voltage: AC100V | Operating Circuit: AC100-120V 50/60Hz, 7VA input | Rated Insulation Voltage: 660V 50/60Hz main circuit | Operating Voltage Tolerance: 85 to 110 percent of rated voltage | Output Contact: 1a1b with independent a and b contacts usable on different voltage circuits | Output Contact Rating: AC240V 1A, AC120V 2A under AC-15 class | Reset: Manual reset | Protection Mode: Overload, overload plus open phase, or overload plus open phase plus reverse phase, selected by the protection mode switch | Overload Operating Current: 115 plus or minus 5 percent of the setting | Overload Operating Time: 3, 5, 7, 15 or 30 seconds selectable at 600 percent of the setting current | Indication: Power, overload, open phase and reverse phase indicators plus load run and stop status | Self Diagnosis: Trips on detection of an internal fault
ET-N150 150A AC200V ET-N150 electronic motor protection relay, 150A setting, AC200V control | Type: Electronic motor protection relay | Frame: N150 150A frame | Current Setting Designation: 150A | Current Setting Range: 40 to 150A | Applicable Motor Capacity: 11 to 37kW at 200-220V, 22 to 75kW at 400-440V | Operating Voltage: AC200V | Operating Circuit: AC200-240V 50/60Hz, 14VA input | Rated Insulation Voltage: 660V 50/60Hz main circuit | Operating Voltage Tolerance: 85 to 110 percent of rated voltage | Output Contact: 1a1b with independent a and b contacts usable on different voltage circuits | Output Contact Rating: AC240V 1A, AC120V 2A under AC-15 class | Reset: Manual reset | Protection Mode: Overload, overload plus open phase, or overload plus open phase plus reverse phase, selected by the protection mode switch | Overload Operating Current: 115 plus or minus 5 percent of the setting | Overload Operating Time: 3, 5, 7, 15 or 30 seconds selectable at 600 percent of the setting current | Indication: Power, overload, open phase and reverse phase indicators plus load run and stop status | Self Diagnosis: Trips on detection of an internal fault
