Mitsubishi Electric GM-S 0.4kW Single-Phase Parallel Shaft Geared Motor (Flange Mount, IP65)

Mitsubishi Electric GM-S 0.4kW Single-Phase Parallel Shaft Geared Motor (Flange Mount, IP65)

Mitsubishi Electric GM-S series parallel shaft geared motor, 0.4kW Single-Phase, W-type IP65 dust-proof and waterproof construction. 4-pole induction motor with integral helical gear reducer, flange-mount, grease-lubricated, service factor 1.0.

Key features

  • Reduction ratios from 1/3 to 1/1200
  • Available with or without built-in electromagnetic brake
  • Efficiency class IE1
  • For washdown, food, and humid-environment power transmission

Specifications

Type Parallel Shaft Geared Motor
Series GM-S
Capacity 0.4kW
Poles 4P
Phase Single-Phase
Voltage 100/100V 50/60Hz
Mount Flange
Protection IP65 (W-type)
Service Factor 1.0
Lubrication Grease
Efficiency Class IE1
Availability Made-to-order (consult)
GM-SFSW 0.4kW 1/3 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/3 ratio, 500/600 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/3 | Output Speed: 500rpm (50Hz) / 600rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/5 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/5 ratio, 300/360 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/5 | Output Speed: 300rpm (50Hz) / 360rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/10 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/10 ratio, 150/180 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/10 | Output Speed: 150rpm (50Hz) / 180rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/15 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/15 ratio, 100/120 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/15 | Output Speed: 100rpm (50Hz) / 120rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/20 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/20 ratio, 75/90 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/20 | Output Speed: 75rpm (50Hz) / 90rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/25 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/25 ratio, 60/72 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/25 | Output Speed: 60rpm (50Hz) / 72rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/30 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/30 ratio, 50/60 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/30 | Output Speed: 50rpm (50Hz) / 60rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/40 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/40 ratio, 37.5/45 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/40 | Output Speed: 37.5rpm (50Hz) / 45rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: C | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/50 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/50 ratio, 30/36 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/50 | Output Speed: 30rpm (50Hz) / 36rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: C | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/60 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/60 ratio, 25/30 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/60 | Output Speed: 25rpm (50Hz) / 30rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: E | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/80 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/80 ratio, 18.8/22.5 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/80 | Output Speed: 18.8rpm (50Hz) / 22.5rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: E | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/100 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/100 ratio, 15/18 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/100 | Output Speed: 15rpm (50Hz) / 18rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: E | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/120 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/120 ratio, 12.5/15 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/120 | Output Speed: 12.5rpm (50Hz) / 15rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: G | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/160 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/160 ratio, 9.4/11.3 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/160 | Output Speed: 9.4rpm (50Hz) / 11.3rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: G | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/200 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/200 ratio, 7.5/9 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/200 | Output Speed: 7.5rpm (50Hz) / 9rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: G | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/270 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/270 ratio, 5.6/6.7 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/270 | Output Speed: 5.6rpm (50Hz) / 6.7rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: JM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/360 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/360 ratio, 4.2/5 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/360 | Output Speed: 4.2rpm (50Hz) / 5rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: JM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/450 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/450 ratio, 3.3/4 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/450 | Output Speed: 3.3rpm (50Hz) / 4rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: JM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/540 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/540 ratio, 2.8/3.3 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/540 | Output Speed: 2.8rpm (50Hz) / 3.3rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: LM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/720 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/720 ratio, 2.1/2.5 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/720 | Output Speed: 2.1rpm (50Hz) / 2.5rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: LM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/900 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/900 ratio, 1.7/2 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/900 | Output Speed: 1.7rpm (50Hz) / 2rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: LM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/1200 GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/1200 ratio, 1.3/1.5 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/1200 | Output Speed: 1.3rpm (50Hz) / 1.5rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: LM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/3 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/3 ratio, 500/600 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/3 | Output Speed: 500rpm (50Hz) / 600rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/5 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/5 ratio, 300/360 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/5 | Output Speed: 300rpm (50Hz) / 360rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/10 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/10 ratio, 150/180 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/10 | Output Speed: 150rpm (50Hz) / 180rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/15 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/15 ratio, 100/120 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/15 | Output Speed: 100rpm (50Hz) / 120rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/20 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/20 ratio, 75/90 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/20 | Output Speed: 75rpm (50Hz) / 90rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/25 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/25 ratio, 60/72 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/25 | Output Speed: 60rpm (50Hz) / 72rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/30 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/30 ratio, 50/60 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/30 | Output Speed: 50rpm (50Hz) / 60rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/40 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/40 ratio, 37.5/45 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/40 | Output Speed: 37.5rpm (50Hz) / 45rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: C | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/50 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/50 ratio, 30/36 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/50 | Output Speed: 30rpm (50Hz) / 36rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: C | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/60 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/60 ratio, 25/30 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/60 | Output Speed: 25rpm (50Hz) / 30rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: E | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/80 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/80 ratio, 18.8/22.5 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/80 | Output Speed: 18.8rpm (50Hz) / 22.5rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: E | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/100 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/100 ratio, 15/18 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/100 | Output Speed: 15rpm (50Hz) / 18rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: E | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/120 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/120 ratio, 12.5/15 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/120 | Output Speed: 12.5rpm (50Hz) / 15rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: G | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/160 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/160 ratio, 9.4/11.3 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/160 | Output Speed: 9.4rpm (50Hz) / 11.3rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: G | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/200 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/200 ratio, 7.5/9 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/200 | Output Speed: 7.5rpm (50Hz) / 9rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: G | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/270 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/270 ratio, 5.6/6.7 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/270 | Output Speed: 5.6rpm (50Hz) / 6.7rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: JM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/360 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/360 ratio, 4.2/5 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/360 | Output Speed: 4.2rpm (50Hz) / 5rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: JM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/450 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/450 ratio, 3.3/4 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/450 | Output Speed: 3.3rpm (50Hz) / 4rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: JM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/540 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/540 ratio, 2.8/3.3 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/540 | Output Speed: 2.8rpm (50Hz) / 3.3rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: LM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/720 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/720 ratio, 2.1/2.5 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/720 | Output Speed: 2.1rpm (50Hz) / 2.5rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: LM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/900 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/900 ratio, 1.7/2 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/900 | Output Speed: 1.7rpm (50Hz) / 2rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: LM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/1200 GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/1200 ratio, 1.3/1.5 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/1200 | Output Speed: 1.3rpm (50Hz) / 1.5rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: LM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
Geared MotorsMitsubishi Electric
44 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric GM-S 0.4kW Single-Phase Parallel Shaft Geared Motor (Flange Mount, IP65)

Brand Mitsubishi Electric·Geared Motors

Available part numbers (44)

GM-SFSW 0.4kW 1/3, GM-SFSW 0.4kW 1/5, GM-SFSW 0.4kW 1/10, GM-SFSW 0.4kW 1/15, GM-SFSW 0.4kW 1/20, GM-SFSW 0.4kW 1/25, GM-SFSW 0.4kW 1/30, GM-SFSW 0.4kW 1/40, GM-SFSW 0.4kW 1/50, GM-SFSW 0.4kW 1/60 + 34 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
GM-SFSW 0.4kW 1/3GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/3 ratio, 500/600 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/3 | Output Speed: 500rpm (50Hz) / 600rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/5GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/5 ratio, 300/360 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/5 | Output Speed: 300rpm (50Hz) / 360rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/10GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/10 ratio, 150/180 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/10 | Output Speed: 150rpm (50Hz) / 180rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/15GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/15 ratio, 100/120 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/15 | Output Speed: 100rpm (50Hz) / 120rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/20GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/20 ratio, 75/90 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/20 | Output Speed: 75rpm (50Hz) / 90rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/25GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/25 ratio, 60/72 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/25 | Output Speed: 60rpm (50Hz) / 72rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/30GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/30 ratio, 50/60 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/30 | Output Speed: 50rpm (50Hz) / 60rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/40GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/40 ratio, 37.5/45 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/40 | Output Speed: 37.5rpm (50Hz) / 45rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: C | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/50GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/50 ratio, 30/36 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/50 | Output Speed: 30rpm (50Hz) / 36rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: C | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/60GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/60 ratio, 25/30 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/60 | Output Speed: 25rpm (50Hz) / 30rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: E | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/80GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/80 ratio, 18.8/22.5 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/80 | Output Speed: 18.8rpm (50Hz) / 22.5rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: E | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/100GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/100 ratio, 15/18 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/100 | Output Speed: 15rpm (50Hz) / 18rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: E | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/120GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/120 ratio, 12.5/15 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/120 | Output Speed: 12.5rpm (50Hz) / 15rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: G | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/160GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/160 ratio, 9.4/11.3 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/160 | Output Speed: 9.4rpm (50Hz) / 11.3rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: G | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/200GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/200 ratio, 7.5/9 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/200 | Output Speed: 7.5rpm (50Hz) / 9rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: G | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/270GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/270 ratio, 5.6/6.7 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/270 | Output Speed: 5.6rpm (50Hz) / 6.7rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: JM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/360GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/360 ratio, 4.2/5 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/360 | Output Speed: 4.2rpm (50Hz) / 5rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: JM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/450GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/450 ratio, 3.3/4 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/450 | Output Speed: 3.3rpm (50Hz) / 4rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: JM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/540GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/540 ratio, 2.8/3.3 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/540 | Output Speed: 2.8rpm (50Hz) / 3.3rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: LM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/720GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/720 ratio, 2.1/2.5 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/720 | Output Speed: 2.1rpm (50Hz) / 2.5rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: LM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/900GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/900 ratio, 1.7/2 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/900 | Output Speed: 1.7rpm (50Hz) / 2rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: LM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSW 0.4kW 1/1200GM-SFSW 0.4kW single-phase parallel shaft geared motor, IP65, 1/1200 ratio, 1.3/1.5 rpm output, flange mount, without brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/1200 | Output Speed: 1.3rpm (50Hz) / 1.5rpm (60Hz) | Mount: Flange | Brake: None | Protection: IP65 (W-type) | Gear Size: LM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/3GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/3 ratio, 500/600 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/3 | Output Speed: 500rpm (50Hz) / 600rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/5GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/5 ratio, 300/360 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/5 | Output Speed: 300rpm (50Hz) / 360rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/10GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/10 ratio, 150/180 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/10 | Output Speed: 150rpm (50Hz) / 180rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/15GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/15 ratio, 100/120 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/15 | Output Speed: 100rpm (50Hz) / 120rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/20GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/20 ratio, 75/90 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/20 | Output Speed: 75rpm (50Hz) / 90rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/25GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/25 ratio, 60/72 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/25 | Output Speed: 60rpm (50Hz) / 72rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/30GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/30 ratio, 50/60 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/30 | Output Speed: 50rpm (50Hz) / 60rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: B | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/40GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/40 ratio, 37.5/45 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/40 | Output Speed: 37.5rpm (50Hz) / 45rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: C | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/50GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/50 ratio, 30/36 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/50 | Output Speed: 30rpm (50Hz) / 36rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: C | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/60GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/60 ratio, 25/30 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/60 | Output Speed: 25rpm (50Hz) / 30rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: E | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/80GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/80 ratio, 18.8/22.5 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/80 | Output Speed: 18.8rpm (50Hz) / 22.5rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: E | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/100GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/100 ratio, 15/18 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/100 | Output Speed: 15rpm (50Hz) / 18rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: E | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/120GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/120 ratio, 12.5/15 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/120 | Output Speed: 12.5rpm (50Hz) / 15rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: G | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/160GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/160 ratio, 9.4/11.3 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/160 | Output Speed: 9.4rpm (50Hz) / 11.3rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: G | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/200GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/200 ratio, 7.5/9 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/200 | Output Speed: 7.5rpm (50Hz) / 9rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: G | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/270GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/270 ratio, 5.6/6.7 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/270 | Output Speed: 5.6rpm (50Hz) / 6.7rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: JM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/360GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/360 ratio, 4.2/5 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/360 | Output Speed: 4.2rpm (50Hz) / 5rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: JM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/450GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/450 ratio, 3.3/4 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/450 | Output Speed: 3.3rpm (50Hz) / 4rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: JM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/540GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/540 ratio, 2.8/3.3 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/540 | Output Speed: 2.8rpm (50Hz) / 3.3rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: LM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/720GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/720 ratio, 2.1/2.5 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/720 | Output Speed: 2.1rpm (50Hz) / 2.5rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: LM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/900GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/900 ratio, 1.7/2 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/900 | Output Speed: 1.7rpm (50Hz) / 2rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: LM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
GM-SFSBW 0.4kW 1/1200GM-SFSBW 0.4kW single-phase parallel shaft geared motor, IP65, 1/1200 ratio, 1.3/1.5 rpm output, flange mount, with brake, IE1 | Type: Parallel Shaft Geared Motor | Series: GM-S | Capacity: 0.4kW | Poles: 4P | Phase: Single-Phase | Voltage: 100/100V 50/60Hz | Reduction Ratio: 1/1200 | Output Speed: 1.3rpm (50Hz) / 1.5rpm (60Hz) | Mount: Flange | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: LM | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE1 | Availability: Made-to-order (consult)
