• Mitsubishi Electric GM-SP 2.2kW 3-Phase Parallel Shaft Geared Motor (Leg Mount, IP65)
1 1

Mitsubishi Electric GM-SP 2.2kW 3-Phase Parallel Shaft Geared Motor (Leg Mount, IP65)

Mitsubishi Electric GM-SP 2.2kW 3-Phase Parallel Shaft Geared Motor (Leg Mount, IP65)

Mitsubishi Electric GM-SP series parallel shaft geared motor, 2.2kW 3-Phase, W-type IP65 dust-proof and waterproof construction. 4-pole induction motor with integral helical gear reducer, leg-mount, grease-lubricated, service factor 1.0.

Key features

  • Reduction ratios from 1/3 to 1/100
  • Available with or without built-in electromagnetic brake
  • Efficiency class IE3
  • For washdown, food, and humid-environment power transmission

Specifications

Type Parallel Shaft Geared Motor
Series GM-SP
Capacity 2.2kW
Poles 4P
Phase 3-Phase
Voltage 200/200/220V 50/60/60Hz
Mount Leg
Protection IP65 (W-type)
Service Factor 1.0
Lubrication Grease
Efficiency Class IE3
Availability Made-to-order (consult)
GM-SPW 2.2kW 1/3 GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/3 ratio, 500/600 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/3 | Output Speed: 500rpm (50Hz) / 600rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/5 GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/5 ratio, 300/360 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/5 | Output Speed: 300rpm (50Hz) / 360rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/10 GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/10 ratio, 150/180 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/10 | Output Speed: 150rpm (50Hz) / 180rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/15 GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/15 ratio, 100/120 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/15 | Output Speed: 100rpm (50Hz) / 120rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/20 GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/20 ratio, 75/90 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/20 | Output Speed: 75rpm (50Hz) / 90rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/25 GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/25 ratio, 60/72 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/25 | Output Speed: 60rpm (50Hz) / 72rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/30 GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/30 ratio, 50/60 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/30 | Output Speed: 50rpm (50Hz) / 60rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/40 GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/40 ratio, 37.5/45 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/40 | Output Speed: 37.5rpm (50Hz) / 45rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: J | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/50 GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/50 ratio, 30/36 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/50 | Output Speed: 30rpm (50Hz) / 36rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: J | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/60 GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/60 ratio, 25/30 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/60 | Output Speed: 25rpm (50Hz) / 30rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: L | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/80 GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/80 ratio, 18.8/22.5 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/80 | Output Speed: 18.8rpm (50Hz) / 22.5rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: L | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/100 GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/100 ratio, 15/18 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/100 | Output Speed: 15rpm (50Hz) / 18rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: L | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/3 GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/3 ratio, 500/600 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/3 | Output Speed: 500rpm (50Hz) / 600rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/5 GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/5 ratio, 300/360 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/5 | Output Speed: 300rpm (50Hz) / 360rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/10 GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/10 ratio, 150/180 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/10 | Output Speed: 150rpm (50Hz) / 180rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/15 GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/15 ratio, 100/120 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/15 | Output Speed: 100rpm (50Hz) / 120rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/20 GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/20 ratio, 75/90 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/20 | Output Speed: 75rpm (50Hz) / 90rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/25 GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/25 ratio, 60/72 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/25 | Output Speed: 60rpm (50Hz) / 72rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/30 GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/30 ratio, 50/60 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/30 | Output Speed: 50rpm (50Hz) / 60rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/40 GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/40 ratio, 37.5/45 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/40 | Output Speed: 37.5rpm (50Hz) / 45rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: J | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/50 GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/50 ratio, 30/36 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/50 | Output Speed: 30rpm (50Hz) / 36rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: J | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/60 GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/60 ratio, 25/30 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/60 | Output Speed: 25rpm (50Hz) / 30rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: L | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/80 GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/80 ratio, 18.8/22.5 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/80 | Output Speed: 18.8rpm (50Hz) / 22.5rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: L | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/100 GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/100 ratio, 15/18 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/100 | Output Speed: 15rpm (50Hz) / 18rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: L | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
Geared MotorsMitsubishi Electric
24 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric GM-SP 2.2kW 3-Phase Parallel Shaft Geared Motor (Leg Mount, IP65)

Brand Mitsubishi Electric·Geared Motors

Available part numbers (24)

GM-SPW 2.2kW 1/3, GM-SPW 2.2kW 1/5, GM-SPW 2.2kW 1/10, GM-SPW 2.2kW 1/15, GM-SPW 2.2kW 1/20, GM-SPW 2.2kW 1/25, GM-SPW 2.2kW 1/30, GM-SPW 2.2kW 1/40, GM-SPW 2.2kW 1/50, GM-SPW 2.2kW 1/60 + 14 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
GM-SPW 2.2kW 1/3GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/3 ratio, 500/600 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/3 | Output Speed: 500rpm (50Hz) / 600rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/5GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/5 ratio, 300/360 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/5 | Output Speed: 300rpm (50Hz) / 360rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/10GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/10 ratio, 150/180 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/10 | Output Speed: 150rpm (50Hz) / 180rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/15GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/15 ratio, 100/120 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/15 | Output Speed: 100rpm (50Hz) / 120rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/20GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/20 ratio, 75/90 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/20 | Output Speed: 75rpm (50Hz) / 90rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/25GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/25 ratio, 60/72 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/25 | Output Speed: 60rpm (50Hz) / 72rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/30GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/30 ratio, 50/60 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/30 | Output Speed: 50rpm (50Hz) / 60rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/40GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/40 ratio, 37.5/45 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/40 | Output Speed: 37.5rpm (50Hz) / 45rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: J | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/50GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/50 ratio, 30/36 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/50 | Output Speed: 30rpm (50Hz) / 36rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: J | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/60GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/60 ratio, 25/30 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/60 | Output Speed: 25rpm (50Hz) / 30rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: L | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/80GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/80 ratio, 18.8/22.5 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/80 | Output Speed: 18.8rpm (50Hz) / 22.5rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: L | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPW 2.2kW 1/100GM-SPW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/100 ratio, 15/18 rpm output, leg mount, without brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/100 | Output Speed: 15rpm (50Hz) / 18rpm (60Hz) | Mount: Leg | Brake: None | Protection: IP65 (W-type) | Gear Size: L | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/3GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/3 ratio, 500/600 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/3 | Output Speed: 500rpm (50Hz) / 600rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/5GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/5 ratio, 300/360 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/5 | Output Speed: 300rpm (50Hz) / 360rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/10GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/10 ratio, 150/180 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/10 | Output Speed: 150rpm (50Hz) / 180rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/15GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/15 ratio, 100/120 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/15 | Output Speed: 100rpm (50Hz) / 120rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/20GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/20 ratio, 75/90 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/20 | Output Speed: 75rpm (50Hz) / 90rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/25GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/25 ratio, 60/72 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/25 | Output Speed: 60rpm (50Hz) / 72rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/30GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/30 ratio, 50/60 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/30 | Output Speed: 50rpm (50Hz) / 60rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: H | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/40GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/40 ratio, 37.5/45 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/40 | Output Speed: 37.5rpm (50Hz) / 45rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: J | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/50GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/50 ratio, 30/36 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/50 | Output Speed: 30rpm (50Hz) / 36rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: J | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/60GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/60 ratio, 25/30 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/60 | Output Speed: 25rpm (50Hz) / 30rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: L | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/80GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/80 ratio, 18.8/22.5 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/80 | Output Speed: 18.8rpm (50Hz) / 22.5rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: L | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
GM-SPBW 2.2kW 1/100GM-SPBW 2.2kW 3-phase parallel shaft geared motor, IP65, 1/100 ratio, 15/18 rpm output, leg mount, with brake, IE3 | Type: Parallel Shaft Geared Motor | Series: GM-SP | Capacity: 2.2kW | Poles: 4P | Phase: 3-Phase | Voltage: 200/200/220V 50/60/60Hz | Reduction Ratio: 1/100 | Output Speed: 15rpm (50Hz) / 18rpm (60Hz) | Mount: Leg | Brake: Built-in Electromagnetic Brake | Protection: IP65 (W-type) | Gear Size: L | Service Factor: 1.0 | Lubrication: Grease | Efficiency Class: IE3 | Availability: Made-to-order (consult)
