Mitsubishi Electric GV-S 0.1kW S-PM Sensorless Servo Geared Motor (Leg Mount)

Mitsubishi Electric GV-S 0.1kW S-PM Sensorless Servo Geared Motor (Leg Mount)

Mitsubishi Electric GV-S 0.1kW S-PM sensorless servo geared motor, leg mount, combining a permanent-magnet motor with PM sensorless vector control for wide constant-torque speed range.

Key features

  • Nominal reduction ratios 1/5 to 1/1200 with permissible output torque 1.4 to 294 Nm
  • Motor rated 3000 r/min, 4P, insulation class 130(B), grease-lubricated, IP44 indoor
  • Requires a matching S-PM drive unit (3-phase 200-240V input; cannot be connected directly to commercial power)

Specifications

Series GV-S (S-PM sensorless servo)
Type Parallel Shaft
Mount Leg mount
Brake None
Output 0.1kW
Poles 4P
Motor Rated Voltage 155V
Motor Rated Current 0.55A
Drive Input 3-phase 200-240V 50/60Hz (drive unit required)
Insulation 130(B)
Enclosure Totally-enclosed non-ventilated (TENV)
Lubrication Grease
GV-S 0.1kW 1/5 GV-S 0.1kW 1/5, leg mount, 1.4Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/5 | Actual Ratio: 1/4.97 | Output Speed: 600 r/min (motor 3000 r/min) | Permissible Output Torque: 1.4 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 25 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/10 GV-S 0.1kW 1/10, leg mount, 2.8Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/10 | Actual Ratio: 1/9.93 | Output Speed: 300 r/min (motor 3000 r/min) | Permissible Output Torque: 2.8 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 42 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/15 GV-S 0.1kW 1/15, leg mount, 4.2Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/15 | Actual Ratio: 1/14.81 | Output Speed: 200 r/min (motor 3000 r/min) | Permissible Output Torque: 4.2 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 42 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/20 GV-S 0.1kW 1/20, leg mount, 5.8Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/20 | Actual Ratio: 1/20.08 | Output Speed: 150 r/min (motor 3000 r/min) | Permissible Output Torque: 5.8 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 83 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/25 GV-S 0.1kW 1/25, leg mount, 6.8Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/25 | Actual Ratio: 1/23.85 | Output Speed: 120 r/min (motor 3000 r/min) | Permissible Output Torque: 6.8 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 83 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/30 GV-S 0.1kW 1/30, leg mount, 8.3Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/30 | Actual Ratio: 1/28.88 | Output Speed: 100 r/min (motor 3000 r/min) | Permissible Output Torque: 8.3 Nm | Permissible Overhang Load: 735 N | Permissible Thrust Load: 125 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/40 GV-S 0.1kW 1/40, leg mount, 10Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/40 | Actual Ratio: 1/37.92 | Output Speed: 75 r/min (motor 3000 r/min) | Permissible Output Torque: 10 Nm | Permissible Overhang Load: 1030 N | Permissible Thrust Load: 167 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/50 GV-S 0.1kW 1/50, leg mount, 13Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/50 | Actual Ratio: 1/47.32 | Output Speed: 60 r/min (motor 3000 r/min) | Permissible Output Torque: 13 Nm | Permissible Overhang Load: 1180 N | Permissible Thrust Load: 208 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/60 GV-S 0.1kW 1/60, leg mount, 16Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/60 | Actual Ratio: 1/58.98 | Output Speed: 50 r/min (motor 3000 r/min) | Permissible Output Torque: 16 Nm | Permissible Overhang Load: 1180 N | Permissible Thrust Load: 250 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/80 GV-S 0.1kW 1/80, leg mount, 22Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/80 | Actual Ratio: 1/80.05 | Output Speed: 37.5 r/min (motor 3000 r/min) | Permissible Output Torque: 22 Nm | Permissible Overhang Load: 1230 N | Permissible Thrust Load: 250 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/100 GV-S 0.1kW 1/100, leg mount, 26Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/100 | Actual Ratio: 1/95.44 | Output Speed: 30 r/min (motor 3000 r/min) | Permissible Output Torque: 26 Nm | Permissible Overhang Load: 1270 N | Permissible Thrust Load: 250 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/120 GV-S 0.1kW 1/120, leg mount, 31Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/120 | Actual Ratio: 1/114.05 | Output Speed: 25 r/min (motor 3000 r/min) | Permissible Output Torque: 31 Nm | Permissible Overhang Load: 1620 N | Permissible Thrust Load: 300 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/160 GV-S 0.1kW 1/160, leg mount, 41Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/160 | Actual Ratio: 1/151.67 | Output Speed: 18.8 r/min (motor 3000 r/min) | Permissible Output Torque: 41 Nm | Permissible Overhang Load: 1670 N | Permissible Thrust Load: 300 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/200 GV-S 0.1kW 1/200, leg mount, 46Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/200 | Actual Ratio: 1/168.76 | Output Speed: 15 r/min (motor 3000 r/min) | Permissible Output Torque: 46 Nm | Permissible Overhang Load: 1720 N | Permissible Thrust Load: 300 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/270 GV-S 0.1kW 1/270, leg mount, 71Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/270 | Actual Ratio: 1/278.78 | Output Speed: 11.1 r/min (motor 3000 r/min) | Permissible Output Torque: 71 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 600 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/360 GV-S 0.1kW 1/360, leg mount, 94Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/360 | Actual Ratio: 1/367.62 | Output Speed: 8.3 r/min (motor 3000 r/min) | Permissible Output Torque: 94 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 600 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/450 GV-S 0.1kW 1/450, leg mount, 116Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/450 | Actual Ratio: 1/453.76 | Output Speed: 6.7 r/min (motor 3000 r/min) | Permissible Output Torque: 116 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 600 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/540 GV-S 0.1kW 1/540, leg mount, 129Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/540 | Actual Ratio: 1/508.20 | Output Speed: 5.6 r/min (motor 3000 r/min) | Permissible Output Torque: 129 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/720 GV-S 0.1kW 1/720, leg mount, 176Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/720 | Actual Ratio: 1/693.00 | Output Speed: 4.2 r/min (motor 3000 r/min) | Permissible Output Torque: 176 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/900 GV-S 0.1kW 1/900, leg mount, 220Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/900 | Actual Ratio: 1/865.82 | Output Speed: 3.3 r/min (motor 3000 r/min) | Permissible Output Torque: 220 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-S 0.1kW 1/1200 GV-S 0.1kW 1/1200, leg mount, 294Nm, no brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: None | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/1200 | Actual Ratio: 1/1154.42 | Output Speed: 2.5 r/min (motor 3000 r/min) | Permissible Output Torque: 294 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
Sensorless Servo Geared MotorsMitsubishi Electric
21 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric GV-S 0.1kW S-PM Sensorless Servo Geared Motor (Leg Mount)

Brand Mitsubishi Electric·Sensorless Servo Geared Motors

Available part numbers (21)

GV-S 0.1kW 1/5, GV-S 0.1kW 1/10, GV-S 0.1kW 1/15, GV-S 0.1kW 1/20, GV-S 0.1kW 1/25, GV-S 0.1kW 1/30, GV-S 0.1kW 1/40, GV-S 0.1kW 1/50, GV-S 0.1kW 1/60, GV-S 0.1kW 1/80 + 11 more — see full table ↓
