• Mitsubishi Electric GV-S 0.75kW 400V Class S-PM Sensorless Servo Geared Motor (Parallel Shaft, Leg Mount, without Brake)
1 1

Mitsubishi Electric GV-S 0.75kW 400V Class S-PM Sensorless Servo Geared Motor (Parallel Shaft, Leg Mount, without Brake)

Mitsubishi Electric GV-S 0.75kW 400V Class S-PM Sensorless Servo Geared Motor (Parallel Shaft, Leg Mount, without Brake)

Mitsubishi Electric GV-S 0.75kW 400V class S-PM sensorless servo geared motor, parallel shaft type with leg mounting, without brake.

Key features

  • Combines an S-PM permanent magnet motor with Mitsubishi PM sensorless vector control for high-accuracy speed regulation under load fluctuation without an encoder
  • Motor rated speed 3000r/min, 21 reduction ratios 1/5-1/1200, permissible output shaft torque 11-1230Nm
  • Requires dedicated drive unit FR-D740-1.5K-G (3-phase 380-480V 50/60Hz input; direct commercial power connection is not possible). 4P motor, TENV enclosure, indoor IP44, grease lubrication, insulation class 130(B), continuous rating
  • Semi-standard options: outdoor type, tropical treatment, one-touch manual release brake

Specifications

Voltage Class 400V (drive input 3-phase 380-480V 50/60Hz)
Output 0.75kW
Motor Rated Voltage 340V
Motor Rated Current 1.4A
Poles 4P
Motor Rated Frequency 100Hz
Motor Speed 3000r/min
Drive Unit FR-D740-1.5K-G
Power Supply Capacity 2.5kVA
Mount Leg
Brake None
Shaft Solid shaft
GV-S 0.75kW 1/5 400V GV-S 0.75kW ratio 1/5 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/5 | Actual Ratio: 1/5.04 | Output Shaft Speed: 600r/min | Permissible Output Torque: 11Nm | Permissible Overhang Load: 685N | Permissible Thrust Load: 30N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/10 400V GV-S 0.75kW ratio 1/10 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/10 | Actual Ratio: 1/9.80 | Output Shaft Speed: 300r/min | Permissible Output Torque: 21Nm | Permissible Overhang Load: 685N | Permissible Thrust Load: 50N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/15 400V GV-S 0.75kW ratio 1/15 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/15 | Actual Ratio: 1/14.44 | Output Shaft Speed: 200r/min | Permissible Output Torque: 31Nm | Permissible Overhang Load: 685N | Permissible Thrust Load: 50N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/20 400V GV-S 0.75kW ratio 1/20 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/20 | Actual Ratio: 1/19.60 | Output Shaft Speed: 150r/min | Permissible Output Torque: 42Nm | Permissible Overhang Load: 1370N | Permissible Thrust Load: 100N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/25 400V GV-S 0.75kW ratio 1/25 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/25 | Actual Ratio: 1/25.73 | Output Shaft Speed: 120r/min | Permissible Output Torque: 55Nm | Permissible Overhang Load: 1370N | Permissible Thrust Load: 100N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/30 400V GV-S 0.75kW ratio 1/30 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/30 | Actual Ratio: 1/28.51 | Output Shaft Speed: 100r/min | Permissible Output Torque: 61Nm | Permissible Overhang Load: 1470N | Permissible Thrust Load: 150N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/40 400V GV-S 0.75kW ratio 1/40 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/40 | Actual Ratio: 1/38.89 | Output Shaft Speed: 75r/min | Permissible Output Torque: 79Nm | Permissible Overhang Load: 1570N | Permissible Thrust Load: 200N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/50 400V GV-S 0.75kW ratio 1/50 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/50 | Actual Ratio: 1/43.27 | Output Shaft Speed: 60r/min | Permissible Output Torque: 88Nm | Permissible Overhang Load: 1620N | Permissible Thrust Load: 250N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/60 400V GV-S 0.75kW ratio 1/60 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/60 | Actual Ratio: 1/61.95 | Output Shaft Speed: 50r/min | Permissible Output Torque: 126Nm | Permissible Overhang Load: 1760N | Permissible Thrust Load: 300N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/80 400V GV-S 0.75kW ratio 1/80 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/80 | Actual Ratio: 1/81.69 | Output Shaft Speed: 37.5r/min | Permissible Output Torque: 166Nm | Permissible Overhang Load: 2350N | Permissible Thrust Load: 500N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/100 400V GV-S 0.75kW ratio 1/100 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/100 | Actual Ratio: 1/100.84 | Output Shaft Speed: 30r/min | Permissible Output Torque: 205Nm | Permissible Overhang Load: 2350N | Permissible Thrust Load: 500N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/120 400V GV-S 0.75kW ratio 1/120 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/120 | Actual Ratio: 1/112.93 | Output Shaft Speed: 25r/min | Permissible Output Torque: 229Nm | Permissible Overhang Load: 2550N | Permissible Thrust Load: 500N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/160 400V GV-S 0.75kW ratio 1/160 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/160 | Actual Ratio: 1/154.00 | Output Shaft Speed: 18.8r/min | Permissible Output Torque: 313Nm | Permissible Overhang Load: 2650N | Permissible Thrust Load: 500N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/200 400V GV-S 0.75kW ratio 1/200 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/200 | Actual Ratio: 1/192.40 | Output Shaft Speed: 15r/min | Permissible Output Torque: 390Nm | Permissible Overhang Load: 2740N | Permissible Thrust Load: 500N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/270 400V GV-S 0.75kW ratio 1/270 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/270 | Actual Ratio: 1/262.89 | Output Shaft Speed: 11.1r/min | Permissible Output Torque: 502Nm | Permissible Overhang Load: 3920N | Permissible Thrust Load: 700N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/360 400V GV-S 0.75kW ratio 1/360 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/360 | Actual Ratio: 1/365.59 | Output Shaft Speed: 8.3r/min | Permissible Output Torque: 698Nm | Permissible Overhang Load: 3920N | Permissible Thrust Load: 700N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/450 400V GV-S 0.75kW ratio 1/450 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/450 | Actual Ratio: 1/406.22 | Output Shaft Speed: 6.7r/min | Permissible Output Torque: 769Nm (torque-limited) | Permissible Overhang Load: 3920N | Permissible Thrust Load: 700N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/540 400V GV-S 0.75kW ratio 1/540 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/540 | Actual Ratio: 1/518.18 | Output Shaft Speed: 5.6r/min | Permissible Output Torque: 990Nm | Permissible Overhang Load: 6370N | Permissible Thrust Load: 1200N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/720 400V GV-S 0.75kW ratio 1/720 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/720 | Actual Ratio: 1/720.30 | Output Shaft Speed: 4.2r/min | Permissible Output Torque: 1230Nm (torque-limited) | Permissible Overhang Load: 6370N | Permissible Thrust Load: 1200N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/900 400V GV-S 0.75kW ratio 1/900 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/900 | Actual Ratio: 1/826.88 | Output Shaft Speed: 3.3r/min | Permissible Output Torque: 1230Nm (torque-limited) | Permissible Overhang Load: 6370N | Permissible Thrust Load: 1200N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-S 0.75kW 1/1200 400V GV-S 0.75kW ratio 1/1200 400V class, leg mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.75kW | Nominal Ratio: 1/1200 | Actual Ratio: 1/1102.50 | Output Shaft Speed: 2.5r/min | Permissible Output Torque: 1230Nm (torque-limited) | Permissible Overhang Load: 6370N | Permissible Thrust Load: 1200N | Motor Rated Voltage: 340V | Motor Rated Current: 1.4A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-1.5K-G | Power Supply Capacity: 2.5kVA | Mount: Leg | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
Sensorless Servo Geared MotorsMitsubishi Electric
21 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric GV-S 0.75kW 400V Class S-PM Sensorless Servo Geared Motor (Parallel Shaft, Leg Mount, without Brake)

Brand Mitsubishi Electric·Sensorless Servo Geared Motors

Available part numbers (21)

GV-S 0.75kW 1/5 400V, GV-S 0.75kW 1/10 400V, GV-S 0.75kW 1/15 400V, GV-S 0.75kW 1/20 400V, GV-S 0.75kW 1/25 400V, GV-S 0.75kW 1/30 400V, GV-S 0.75kW 1/40 400V, GV-S 0.75kW 1/50 400V, GV-S 0.75kW 1/60 400V, GV-S 0.75kW 1/80 400V + 11 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
