Mitsubishi Electric GV-SB 0.4kW S-PM Sensorless Servo Geared Motor (Leg Mount, Brake)

Mitsubishi Electric GV-SB 0.4kW S-PM Sensorless Servo Geared Motor (Leg Mount, Brake)

Mitsubishi Electric GV-SB 0.4kW S-PM sensorless servo geared motor, leg mount, combining a permanent-magnet motor with PM sensorless vector control for wide constant-torque speed range.

Key features

  • Nominal reduction ratios 1/5 to 1/900 with permissible output torque 5.7 to 769 Nm
  • Motor rated 3000 r/min, 4P, insulation class 130(B), grease-lubricated, IP44 indoor
  • Built-in DC spring-applied brake for load holding
  • Requires a matching S-PM drive unit (3-phase 200-240V input; cannot be connected directly to commercial power)

Specifications

Series GV-S (S-PM sensorless servo)
Type Parallel Shaft
Mount Leg mount
Brake Built-in DC spring-applied
Output 0.4kW
Poles 4P
Motor Rated Voltage 175V
Motor Rated Current 1.6A
Drive Input 3-phase 200-240V 50/60Hz (drive unit required)
Insulation 130(B)
Enclosure Totally-enclosed non-ventilated (TENV)
Lubrication Grease
GV-SB 0.4kW 1/5 GV-SB 0.4kW 1/5, leg mount, 5.7Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/5 | Actual Ratio: 1/4.97 | Output Speed: 600 r/min (motor 3000 r/min) | Permissible Output Torque: 5.7 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 25 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/10 GV-SB 0.4kW 1/10, leg mount, 11Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/10 | Actual Ratio: 1/9.93 | Output Speed: 300 r/min (motor 3000 r/min) | Permissible Output Torque: 11 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 42 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/15 GV-SB 0.4kW 1/15, leg mount, 17Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/15 | Actual Ratio: 1/14.81 | Output Speed: 200 r/min (motor 3000 r/min) | Permissible Output Torque: 17 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 42 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/20 GV-SB 0.4kW 1/20, leg mount, 23Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/20 | Actual Ratio: 1/20.08 | Output Speed: 150 r/min (motor 3000 r/min) | Permissible Output Torque: 23 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 83 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/25 GV-SB 0.4kW 1/25, leg mount, 27Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/25 | Actual Ratio: 1/23.85 | Output Speed: 120 r/min (motor 3000 r/min) | Permissible Output Torque: 27 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 83 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/30 GV-SB 0.4kW 1/30, leg mount, 33Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/30 | Actual Ratio: 1/28.88 | Output Speed: 100 r/min (motor 3000 r/min) | Permissible Output Torque: 33 Nm | Permissible Overhang Load: 880 N | Permissible Thrust Load: 125 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/40 GV-SB 0.4kW 1/40, leg mount, 44Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/40 | Actual Ratio: 1/41.07 | Output Speed: 75 r/min (motor 3000 r/min) | Permissible Output Torque: 44 Nm | Permissible Overhang Load: 1180 N | Permissible Thrust Load: 167 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/50 GV-SB 0.4kW 1/50, leg mount, 53Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/50 | Actual Ratio: 1/48.96 | Output Speed: 60 r/min (motor 3000 r/min) | Permissible Output Torque: 53 Nm | Permissible Overhang Load: 1180 N | Permissible Thrust Load: 208 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/60 GV-SB 0.4kW 1/60, leg mount, 66Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/60 | Actual Ratio: 1/60.54 | Output Speed: 50 r/min (motor 3000 r/min) | Permissible Output Torque: 66 Nm | Permissible Overhang Load: 1230 N | Permissible Thrust Load: 250 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/80 GV-SB 0.4kW 1/80, leg mount, 87Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/80 | Actual Ratio: 1/80.50 | Output Speed: 37.5 r/min (motor 3000 r/min) | Permissible Output Torque: 87 Nm | Permissible Overhang Load: 1570 N | Permissible Thrust Load: 300 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/100 GV-SB 0.4kW 1/100, leg mount, 97Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/100 | Actual Ratio: 1/89.57 | Output Speed: 30 r/min (motor 3000 r/min) | Permissible Output Torque: 97 Nm | Permissible Overhang Load: 1620 N | Permissible Thrust Load: 300 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/120 GV-SB 0.4kW 1/120, leg mount, 122Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/120 | Actual Ratio: 1/112.29 | Output Speed: 25 r/min (motor 3000 r/min) | Permissible Output Torque: 122 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/160 GV-SB 0.4kW 1/160, leg mount, 160Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/160 | Actual Ratio: 1/148.08 | Output Speed: 18.8 r/min (motor 3000 r/min) | Permissible Output Torque: 160 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/200 GV-SB 0.4kW 1/200, leg mount, 198Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/200 | Actual Ratio: 1/182.78 | Output Speed: 15 r/min (motor 3000 r/min) | Permissible Output Torque: 198 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/270 GV-SB 0.4kW 1/270, leg mount, 256Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/270 | Actual Ratio: 1/251.20 | Output Speed: 11.1 r/min (motor 3000 r/min) | Permissible Output Torque: 256 Nm | Permissible Overhang Load: 2650 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/360 GV-SB 0.4kW 1/360, leg mount, 349Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/360 | Actual Ratio: 1/342.55 | Output Speed: 8.3 r/min (motor 3000 r/min) | Permissible Output Torque: 349 Nm | Permissible Overhang Load: 2700 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/450 GV-SB 0.4kW 1/450, leg mount, 436Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/450 | Actual Ratio: 1/427.98 | Output Speed: 6.7 r/min (motor 3000 r/min) | Permissible Output Torque: 436 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/540 GV-SB 0.4kW 1/540, leg mount, 519Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/540 | Actual Ratio: 1/509.38 | Output Speed: 5.6 r/min (motor 3000 r/min) | Permissible Output Torque: 519 Nm | Permissible Overhang Load: 3920 N | Permissible Thrust Load: 700 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/720 GV-SB 0.4kW 1/720, leg mount, 722Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/720 | Actual Ratio: 1/708.40 | Output Speed: 4.2 r/min (motor 3000 r/min) | Permissible Output Torque: 722 Nm | Permissible Overhang Load: 3920 N | Permissible Thrust Load: 700 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/900 GV-SB 0.4kW 1/900, leg mount, 769Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/900 | Actual Ratio: 1/787.10 | Output Speed: 3.3 r/min (motor 3000 r/min) | Permissible Output Torque: 769 Nm (torque-limited) | Permissible Overhang Load: 3920 N | Permissible Thrust Load: 700 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
Sensorless Servo Geared MotorsMitsubishi Electric
20 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric GV-SB 0.4kW S-PM Sensorless Servo Geared Motor (Leg Mount, Brake)

Brand Mitsubishi Electric·Sensorless Servo Geared Motors

Available part numbers (20)

GV-SB 0.4kW 1/5, GV-SB 0.4kW 1/10, GV-SB 0.4kW 1/15, GV-SB 0.4kW 1/20, GV-SB 0.4kW 1/25, GV-SB 0.4kW 1/30, GV-SB 0.4kW 1/40, GV-SB 0.4kW 1/50, GV-SB 0.4kW 1/60, GV-SB 0.4kW 1/80 + 10 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
GV-SB 0.4kW 1/5GV-SB 0.4kW 1/5, leg mount, 5.7Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/5 | Actual Ratio: 1/4.97 | Output Speed: 600 r/min (motor 3000 r/min) | Permissible Output Torque: 5.7 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 25 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/10GV-SB 0.4kW 1/10, leg mount, 11Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/10 | Actual Ratio: 1/9.93 | Output Speed: 300 r/min (motor 3000 r/min) | Permissible Output Torque: 11 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 42 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/15GV-SB 0.4kW 1/15, leg mount, 17Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/15 | Actual Ratio: 1/14.81 | Output Speed: 200 r/min (motor 3000 r/min) | Permissible Output Torque: 17 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 42 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/20GV-SB 0.4kW 1/20, leg mount, 23Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/20 | Actual Ratio: 1/20.08 | Output Speed: 150 r/min (motor 3000 r/min) | Permissible Output Torque: 23 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 83 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/25GV-SB 0.4kW 1/25, leg mount, 27Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/25 | Actual Ratio: 1/23.85 | Output Speed: 120 r/min (motor 3000 r/min) | Permissible Output Torque: 27 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 83 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/30GV-SB 0.4kW 1/30, leg mount, 33Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/30 | Actual Ratio: 1/28.88 | Output Speed: 100 r/min (motor 3000 r/min) | Permissible Output Torque: 33 Nm | Permissible Overhang Load: 880 N | Permissible Thrust Load: 125 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/40GV-SB 0.4kW 1/40, leg mount, 44Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/40 | Actual Ratio: 1/41.07 | Output Speed: 75 r/min (motor 3000 r/min) | Permissible Output Torque: 44 Nm | Permissible Overhang Load: 1180 N | Permissible Thrust Load: 167 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/50GV-SB 0.4kW 1/50, leg mount, 53Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/50 | Actual Ratio: 1/48.96 | Output Speed: 60 r/min (motor 3000 r/min) | Permissible Output Torque: 53 Nm | Permissible Overhang Load: 1180 N | Permissible Thrust Load: 208 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/60GV-SB 0.4kW 1/60, leg mount, 66Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/60 | Actual Ratio: 1/60.54 | Output Speed: 50 r/min (motor 3000 r/min) | Permissible Output Torque: 66 Nm | Permissible Overhang Load: 1230 N | Permissible Thrust Load: 250 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/80GV-SB 0.4kW 1/80, leg mount, 87Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/80 | Actual Ratio: 1/80.50 | Output Speed: 37.5 r/min (motor 3000 r/min) | Permissible Output Torque: 87 Nm | Permissible Overhang Load: 1570 N | Permissible Thrust Load: 300 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/100GV-SB 0.4kW 1/100, leg mount, 97Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/100 | Actual Ratio: 1/89.57 | Output Speed: 30 r/min (motor 3000 r/min) | Permissible Output Torque: 97 Nm | Permissible Overhang Load: 1620 N | Permissible Thrust Load: 300 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/120GV-SB 0.4kW 1/120, leg mount, 122Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/120 | Actual Ratio: 1/112.29 | Output Speed: 25 r/min (motor 3000 r/min) | Permissible Output Torque: 122 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/160GV-SB 0.4kW 1/160, leg mount, 160Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/160 | Actual Ratio: 1/148.08 | Output Speed: 18.8 r/min (motor 3000 r/min) | Permissible Output Torque: 160 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/200GV-SB 0.4kW 1/200, leg mount, 198Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/200 | Actual Ratio: 1/182.78 | Output Speed: 15 r/min (motor 3000 r/min) | Permissible Output Torque: 198 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/270GV-SB 0.4kW 1/270, leg mount, 256Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/270 | Actual Ratio: 1/251.20 | Output Speed: 11.1 r/min (motor 3000 r/min) | Permissible Output Torque: 256 Nm | Permissible Overhang Load: 2650 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/360GV-SB 0.4kW 1/360, leg mount, 349Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/360 | Actual Ratio: 1/342.55 | Output Speed: 8.3 r/min (motor 3000 r/min) | Permissible Output Torque: 349 Nm | Permissible Overhang Load: 2700 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/450GV-SB 0.4kW 1/450, leg mount, 436Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/450 | Actual Ratio: 1/427.98 | Output Speed: 6.7 r/min (motor 3000 r/min) | Permissible Output Torque: 436 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/540GV-SB 0.4kW 1/540, leg mount, 519Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/540 | Actual Ratio: 1/509.38 | Output Speed: 5.6 r/min (motor 3000 r/min) | Permissible Output Torque: 519 Nm | Permissible Overhang Load: 3920 N | Permissible Thrust Load: 700 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/720GV-SB 0.4kW 1/720, leg mount, 722Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/720 | Actual Ratio: 1/708.40 | Output Speed: 4.2 r/min (motor 3000 r/min) | Permissible Output Torque: 722 Nm | Permissible Overhang Load: 3920 N | Permissible Thrust Load: 700 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 0.4kW 1/900GV-SB 0.4kW 1/900, leg mount, 769Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 0.4kW | Poles: 4P | Nominal Ratio: 1/900 | Actual Ratio: 1/787.10 | Output Speed: 3.3 r/min (motor 3000 r/min) | Permissible Output Torque: 769 Nm (torque-limited) | Permissible Overhang Load: 3920 N | Permissible Thrust Load: 700 N | Motor Rated Voltage: 175V | Motor Rated Current: 1.6A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
