• Mitsubishi Electric GV-SB 2.2kW S-PM Sensorless Servo Geared Motor (Leg Mount, Brake)
1 1

Mitsubishi Electric GV-SB 2.2kW S-PM Sensorless Servo Geared Motor (Leg Mount, Brake)

Mitsubishi Electric GV-SB 2.2kW S-PM Sensorless Servo Geared Motor (Leg Mount, Brake)

Mitsubishi Electric GV-SB 2.2kW S-PM sensorless servo geared motor, leg mount, combining a permanent-magnet motor with PM sensorless vector control for wide constant-torque speed range.

Key features

  • Nominal reduction ratios 1/5 to 1/160 with permissible output torque 31 to 953 Nm
  • Motor rated 3000 r/min, 6P, insulation class 130(B), grease-lubricated, IP44 indoor
  • Built-in DC spring-applied brake for load holding
  • Requires a matching S-PM drive unit (3-phase 200-240V input; cannot be connected directly to commercial power)

Specifications

Series GV-S (S-PM sensorless servo)
Type Parallel Shaft
Mount Leg mount
Brake Built-in DC spring-applied
Output 2.2kW
Poles 6P
Motor Rated Voltage 155V
Motor Rated Current 9.4A
Drive Input 3-phase 200-240V 50/60Hz (drive unit required)
Insulation 130(B)
Enclosure Totally-enclosed fan-cooled (TEFC)
Lubrication Grease
GV-SB 2.2kW 1/5 GV-SB 2.2kW 1/5, leg mount, 31Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/5 | Actual Ratio: 1/4.98 | Output Speed: 600 r/min (motor 3000 r/min) | Permissible Output Torque: 31 Nm | Permissible Overhang Load: 1560 N | Permissible Thrust Load: 56 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/10 GV-SB 2.2kW 1/10, leg mount, 60Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/10 | Actual Ratio: 1/9.57 | Output Speed: 300 r/min (motor 3000 r/min) | Permissible Output Torque: 60 Nm | Permissible Overhang Load: 1560 N | Permissible Thrust Load: 94 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/15 GV-SB 2.2kW 1/15, leg mount, 91Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/15 | Actual Ratio: 1/14.49 | Output Speed: 200 r/min (motor 3000 r/min) | Permissible Output Torque: 91 Nm | Permissible Overhang Load: 1560 N | Permissible Thrust Load: 94 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/20 GV-SB 2.2kW 1/20, leg mount, 128Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/20 | Actual Ratio: 1/20.31 | Output Speed: 150 r/min (motor 3000 r/min) | Permissible Output Torque: 128 Nm | Permissible Overhang Load: 1960 N | Permissible Thrust Load: 186 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/25 GV-SB 2.2kW 1/25, leg mount, 156Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/25 | Actual Ratio: 1/24.80 | Output Speed: 120 r/min (motor 3000 r/min) | Permissible Output Torque: 156 Nm | Permissible Overhang Load: 1960 N | Permissible Thrust Load: 186 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/30 GV-SB 2.2kW 1/30, leg mount, 175Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/30 | Actual Ratio: 1/27.72 | Output Speed: 100 r/min (motor 3000 r/min) | Permissible Output Torque: 175 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 280 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/40 GV-SB 2.2kW 1/40, leg mount, 234Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/40 | Actual Ratio: 1/39.27 | Output Speed: 75 r/min (motor 3000 r/min) | Permissible Output Torque: 234 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 374 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/50 GV-SB 2.2kW 1/50, leg mount, 292Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/50 | Actual Ratio: 1/49.07 | Output Speed: 60 r/min (motor 3000 r/min) | Permissible Output Torque: 292 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 374 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/60 GV-SB 2.2kW 1/60, leg mount, 348Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/60 | Actual Ratio: 1/58.42 | Output Speed: 50 r/min (motor 3000 r/min) | Permissible Output Torque: 348 Nm | Permissible Overhang Load: 3130 N | Permissible Thrust Load: 560 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/80 GV-SB 2.2kW 1/80, leg mount, 484Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/80 | Actual Ratio: 1/81.24 | Output Speed: 37.5 r/min (motor 3000 r/min) | Permissible Output Torque: 484 Nm | Permissible Overhang Load: 3130 N | Permissible Thrust Load: 560 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/100 GV-SB 2.2kW 1/100, leg mount, 537Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/100 | Actual Ratio: 1/90.27 | Output Speed: 30 r/min (motor 3000 r/min) | Permissible Output Torque: 537 Nm | Permissible Overhang Load: 3130 N | Permissible Thrust Load: 560 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/120 GV-SB 2.2kW 1/120, leg mount, 685Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/120 | Actual Ratio: 1/115.15 | Output Speed: 25 r/min (motor 3000 r/min) | Permissible Output Torque: 685 Nm | Permissible Overhang Load: 4700 N | Permissible Thrust Load: 960 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/160 GV-SB 2.2kW 1/160, leg mount, 953Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/160 | Actual Ratio: 1/160.07 | Output Speed: 18.8 r/min (motor 3000 r/min) | Permissible Output Torque: 953 Nm | Permissible Overhang Load: 4930 N | Permissible Thrust Load: 960 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
Sensorless Servo Geared MotorsMitsubishi Electric
13 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric GV-SB 2.2kW S-PM Sensorless Servo Geared Motor (Leg Mount, Brake)

Brand Mitsubishi Electric·Sensorless Servo Geared Motors

Available part numbers (13)

GV-SB 2.2kW 1/5, GV-SB 2.2kW 1/10, GV-SB 2.2kW 1/15, GV-SB 2.2kW 1/20, GV-SB 2.2kW 1/25, GV-SB 2.2kW 1/30, GV-SB 2.2kW 1/40, GV-SB 2.2kW 1/50, GV-SB 2.2kW 1/60, GV-SB 2.2kW 1/80 + 3 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
GV-SB 2.2kW 1/5GV-SB 2.2kW 1/5, leg mount, 31Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/5 | Actual Ratio: 1/4.98 | Output Speed: 600 r/min (motor 3000 r/min) | Permissible Output Torque: 31 Nm | Permissible Overhang Load: 1560 N | Permissible Thrust Load: 56 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/10GV-SB 2.2kW 1/10, leg mount, 60Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/10 | Actual Ratio: 1/9.57 | Output Speed: 300 r/min (motor 3000 r/min) | Permissible Output Torque: 60 Nm | Permissible Overhang Load: 1560 N | Permissible Thrust Load: 94 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/15GV-SB 2.2kW 1/15, leg mount, 91Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/15 | Actual Ratio: 1/14.49 | Output Speed: 200 r/min (motor 3000 r/min) | Permissible Output Torque: 91 Nm | Permissible Overhang Load: 1560 N | Permissible Thrust Load: 94 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/20GV-SB 2.2kW 1/20, leg mount, 128Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/20 | Actual Ratio: 1/20.31 | Output Speed: 150 r/min (motor 3000 r/min) | Permissible Output Torque: 128 Nm | Permissible Overhang Load: 1960 N | Permissible Thrust Load: 186 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/25GV-SB 2.2kW 1/25, leg mount, 156Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/25 | Actual Ratio: 1/24.80 | Output Speed: 120 r/min (motor 3000 r/min) | Permissible Output Torque: 156 Nm | Permissible Overhang Load: 1960 N | Permissible Thrust Load: 186 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/30GV-SB 2.2kW 1/30, leg mount, 175Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/30 | Actual Ratio: 1/27.72 | Output Speed: 100 r/min (motor 3000 r/min) | Permissible Output Torque: 175 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 280 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/40GV-SB 2.2kW 1/40, leg mount, 234Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/40 | Actual Ratio: 1/39.27 | Output Speed: 75 r/min (motor 3000 r/min) | Permissible Output Torque: 234 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 374 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/50GV-SB 2.2kW 1/50, leg mount, 292Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/50 | Actual Ratio: 1/49.07 | Output Speed: 60 r/min (motor 3000 r/min) | Permissible Output Torque: 292 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 374 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/60GV-SB 2.2kW 1/60, leg mount, 348Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/60 | Actual Ratio: 1/58.42 | Output Speed: 50 r/min (motor 3000 r/min) | Permissible Output Torque: 348 Nm | Permissible Overhang Load: 3130 N | Permissible Thrust Load: 560 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/80GV-SB 2.2kW 1/80, leg mount, 484Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/80 | Actual Ratio: 1/81.24 | Output Speed: 37.5 r/min (motor 3000 r/min) | Permissible Output Torque: 484 Nm | Permissible Overhang Load: 3130 N | Permissible Thrust Load: 560 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/100GV-SB 2.2kW 1/100, leg mount, 537Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/100 | Actual Ratio: 1/90.27 | Output Speed: 30 r/min (motor 3000 r/min) | Permissible Output Torque: 537 Nm | Permissible Overhang Load: 3130 N | Permissible Thrust Load: 560 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/120GV-SB 2.2kW 1/120, leg mount, 685Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/120 | Actual Ratio: 1/115.15 | Output Speed: 25 r/min (motor 3000 r/min) | Permissible Output Torque: 685 Nm | Permissible Overhang Load: 4700 N | Permissible Thrust Load: 960 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SB 2.2kW 1/160GV-SB 2.2kW 1/160, leg mount, 953Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Leg mount | Brake: Built-in DC spring-applied | Output: 2.2kW | Poles: 6P | Nominal Ratio: 1/160 | Actual Ratio: 1/160.07 | Output Speed: 18.8 r/min (motor 3000 r/min) | Permissible Output Torque: 953 Nm | Permissible Overhang Load: 4930 N | Permissible Thrust Load: 960 N | Motor Rated Voltage: 155V | Motor Rated Current: 9.4A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
