• Mitsubishi Electric GV-SF 0.2kW 400V Class S-PM Sensorless Servo Geared Motor (Parallel Shaft, Flange Mount, without Brake)
1 1

Mitsubishi Electric GV-SF 0.2kW 400V Class S-PM Sensorless Servo Geared Motor (Parallel Shaft, Flange Mount, without Brake)

Mitsubishi Electric GV-SF 0.2kW 400V Class S-PM Sensorless Servo Geared Motor (Parallel Shaft, Flange Mount, without Brake)

Mitsubishi Electric GV-SF 0.2kW 400V class S-PM sensorless servo geared motor, parallel shaft type with flange mounting, without brake.

Key features

  • Combines an S-PM permanent magnet motor with Mitsubishi PM sensorless vector control for high-accuracy speed regulation under load fluctuation without an encoder
  • Motor rated speed 3000r/min, 21 reduction ratios 1/5-1/1200, permissible output shaft torque 2.8-441Nm
  • Requires dedicated drive unit FR-D740-0.4K-G (3-phase 380-480V 50/60Hz input; direct commercial power connection is not possible). 4P motor, TENV enclosure, indoor IP44, grease lubrication, insulation class 130(B), continuous rating
  • Semi-standard options: outdoor type, tropical treatment, one-touch manual release brake

Specifications

Voltage Class 400V (drive input 3-phase 380-480V 50/60Hz)
Output 0.2kW
Motor Rated Voltage 300V
Motor Rated Current 0.5A
Poles 4P
Motor Rated Frequency 100Hz
Motor Speed 3000r/min
Drive Unit FR-D740-0.4K-G
Power Supply Capacity 0.9kVA
Mount Flange
Brake None
Shaft Solid shaft
GV-SF 0.2kW 1/5 400V GV-SF 0.2kW ratio 1/5 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/5 | Actual Ratio: 1/4.97 | Output Shaft Speed: 600r/min | Permissible Output Torque: 2.8Nm | Permissible Overhang Load: 685N | Permissible Thrust Load: 25N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/10 400V GV-SF 0.2kW ratio 1/10 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/10 | Actual Ratio: 1/9.93 | Output Shaft Speed: 300r/min | Permissible Output Torque: 5.7Nm | Permissible Overhang Load: 685N | Permissible Thrust Load: 42N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/15 400V GV-SF 0.2kW ratio 1/15 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/15 | Actual Ratio: 1/14.81 | Output Shaft Speed: 200r/min | Permissible Output Torque: 8.5Nm | Permissible Overhang Load: 685N | Permissible Thrust Load: 42N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/20 400V GV-SF 0.2kW ratio 1/20 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/20 | Actual Ratio: 1/20.08 | Output Shaft Speed: 150r/min | Permissible Output Torque: 12Nm | Permissible Overhang Load: 685N | Permissible Thrust Load: 83N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/25 400V GV-SF 0.2kW ratio 1/25 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/25 | Actual Ratio: 1/23.85 | Output Shaft Speed: 120r/min | Permissible Output Torque: 14Nm | Permissible Overhang Load: 685N | Permissible Thrust Load: 83N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/30 400V GV-SF 0.2kW ratio 1/30 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/30 | Actual Ratio: 1/28.88 | Output Shaft Speed: 100r/min | Permissible Output Torque: 17Nm | Permissible Overhang Load: 735N | Permissible Thrust Load: 125N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/40 400V GV-SF 0.2kW ratio 1/40 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/40 | Actual Ratio: 1/37.92 | Output Shaft Speed: 75r/min | Permissible Output Torque: 21Nm | Permissible Overhang Load: 1030N | Permissible Thrust Load: 167N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/50 400V GV-SF 0.2kW ratio 1/50 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/50 | Actual Ratio: 1/47.32 | Output Shaft Speed: 60r/min | Permissible Output Torque: 26Nm | Permissible Overhang Load: 1180N | Permissible Thrust Load: 208N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/60 400V GV-SF 0.2kW ratio 1/60 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/60 | Actual Ratio: 1/58.98 | Output Shaft Speed: 50r/min | Permissible Output Torque: 32Nm | Permissible Overhang Load: 1180N | Permissible Thrust Load: 250N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/80 400V GV-SF 0.2kW ratio 1/80 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/80 | Actual Ratio: 1/80.05 | Output Shaft Speed: 37.5r/min | Permissible Output Torque: 43Nm | Permissible Overhang Load: 1230N | Permissible Thrust Load: 250N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/100 400V GV-SF 0.2kW ratio 1/100 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/100 | Actual Ratio: 1/95.44 | Output Shaft Speed: 30r/min | Permissible Output Torque: 52Nm | Permissible Overhang Load: 1270N | Permissible Thrust Load: 250N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/120 400V GV-SF 0.2kW ratio 1/120 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/120 | Actual Ratio: 1/114.05 | Output Shaft Speed: 25r/min | Permissible Output Torque: 62Nm | Permissible Overhang Load: 1620N | Permissible Thrust Load: 300N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/160 400V GV-SF 0.2kW ratio 1/160 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/160 | Actual Ratio: 1/151.67 | Output Shaft Speed: 18.8r/min | Permissible Output Torque: 82Nm | Permissible Overhang Load: 1670N | Permissible Thrust Load: 300N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/200 400V GV-SF 0.2kW ratio 1/200 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/200 | Actual Ratio: 1/168.76 | Output Shaft Speed: 15r/min | Permissible Output Torque: 91Nm | Permissible Overhang Load: 1720N | Permissible Thrust Load: 300N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/270 400V GV-SF 0.2kW ratio 1/270 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/270 | Actual Ratio: 1/278.78 | Output Shaft Speed: 11.1r/min | Permissible Output Torque: 142Nm | Permissible Overhang Load: 2350N | Permissible Thrust Load: 600N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/360 400V GV-SF 0.2kW ratio 1/360 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/360 | Actual Ratio: 1/367.62 | Output Shaft Speed: 8.3r/min | Permissible Output Torque: 187Nm | Permissible Overhang Load: 2350N | Permissible Thrust Load: 600N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/450 400V GV-SF 0.2kW ratio 1/450 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/450 | Actual Ratio: 1/453.76 | Output Shaft Speed: 6.7r/min | Permissible Output Torque: 231Nm | Permissible Overhang Load: 2350N | Permissible Thrust Load: 600N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/540 400V GV-SF 0.2kW ratio 1/540 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/540 | Actual Ratio: 1/508.20 | Output Shaft Speed: 5.6r/min | Permissible Output Torque: 259Nm | Permissible Overhang Load: 2740N | Permissible Thrust Load: 500N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/720 400V GV-SF 0.2kW ratio 1/720 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/720 | Actual Ratio: 1/693.00 | Output Shaft Speed: 4.2r/min | Permissible Output Torque: 353Nm | Permissible Overhang Load: 2740N | Permissible Thrust Load: 500N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/900 400V GV-SF 0.2kW ratio 1/900 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/900 | Actual Ratio: 1/865.82 | Output Shaft Speed: 3.3r/min | Permissible Output Torque: 441Nm | Permissible Overhang Load: 2740N | Permissible Thrust Load: 500N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 0.2kW 1/1200 400V GV-SF 0.2kW ratio 1/1200 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 0.2kW | Nominal Ratio: 1/1200 | Actual Ratio: 1/1154.42 | Output Shaft Speed: 2.5r/min | Permissible Output Torque: 441Nm (torque-limited) | Permissible Overhang Load: 2740N | Permissible Thrust Load: 500N | Motor Rated Voltage: 300V | Motor Rated Current: 0.5A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-0.4K-G | Power Supply Capacity: 0.9kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TENV | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
Sensorless Servo Geared MotorsMitsubishi Electric
21 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric GV-SF 0.2kW 400V Class S-PM Sensorless Servo Geared Motor (Parallel Shaft, Flange Mount, without Brake)

Brand Mitsubishi Electric·Sensorless Servo Geared Motors

Available part numbers (21)

GV-SF 0.2kW 1/5 400V, GV-SF 0.2kW 1/10 400V, GV-SF 0.2kW 1/15 400V, GV-SF 0.2kW 1/20 400V, GV-SF 0.2kW 1/25 400V, GV-SF 0.2kW 1/30 400V, GV-SF 0.2kW 1/40 400V, GV-SF 0.2kW 1/50 400V, GV-SF 0.2kW 1/60 400V, GV-SF 0.2kW 1/80 400V + 11 more — see full table ↓
