Mitsubishi Electric GV-SF 2.2kW 400V Class S-PM Sensorless Servo Geared Motor (Parallel Shaft, Flange Mount, without Brake)

Mitsubishi Electric GV-SF 2.2kW 400V Class S-PM Sensorless Servo Geared Motor (Parallel Shaft, Flange Mount, without Brake)

Mitsubishi Electric GV-SF 2.2kW 400V class S-PM sensorless servo geared motor, parallel shaft type with flange mounting, without brake.

Key features

  • Combines an S-PM permanent magnet motor with Mitsubishi PM sensorless vector control for high-accuracy speed regulation under load fluctuation without an encoder
  • Motor rated speed 3000r/min, 14 reduction ratios 1/5-1/200, permissible output shaft torque 31-1094Nm
  • Requires dedicated drive unit FR-D740-3.7K-G (3-phase 380-480V 50/60Hz input; direct commercial power connection is not possible). 6P motor, TEFC enclosure, indoor IP44, grease lubrication, insulation class 130(B), continuous rating
  • Semi-standard options: outdoor type, tropical treatment, one-touch manual release brake

Specifications

Voltage Class 400V (drive input 3-phase 380-480V 50/60Hz)
Output 2.2kW
Motor Rated Voltage 315V
Motor Rated Current 4.7A
Poles 6P
Motor Rated Frequency 150Hz
Motor Speed 3000r/min
Drive Unit FR-D740-3.7K-G
Power Supply Capacity 9.5kVA
Mount Flange
Brake None
Shaft Solid shaft
GV-SF 2.2kW 1/5 400V GV-SF 2.2kW ratio 1/5 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/5 | Actual Ratio: 1/4.98 | Output Shaft Speed: 600r/min | Permissible Output Torque: 31Nm | Permissible Overhang Load: 1560N | Permissible Thrust Load: 56N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/10 400V GV-SF 2.2kW ratio 1/10 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/10 | Actual Ratio: 1/9.57 | Output Shaft Speed: 300r/min | Permissible Output Torque: 60Nm | Permissible Overhang Load: 1560N | Permissible Thrust Load: 94N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/15 400V GV-SF 2.2kW ratio 1/15 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/15 | Actual Ratio: 1/14.49 | Output Shaft Speed: 200r/min | Permissible Output Torque: 91Nm | Permissible Overhang Load: 1560N | Permissible Thrust Load: 94N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/20 400V GV-SF 2.2kW ratio 1/20 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/20 | Actual Ratio: 1/20.31 | Output Shaft Speed: 150r/min | Permissible Output Torque: 128Nm | Permissible Overhang Load: 1960N | Permissible Thrust Load: 186N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/25 400V GV-SF 2.2kW ratio 1/25 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/25 | Actual Ratio: 1/24.80 | Output Shaft Speed: 120r/min | Permissible Output Torque: 156Nm | Permissible Overhang Load: 1960N | Permissible Thrust Load: 186N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/30 400V GV-SF 2.2kW ratio 1/30 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/30 | Actual Ratio: 1/27.72 | Output Shaft Speed: 100r/min | Permissible Output Torque: 175Nm | Permissible Overhang Load: 2350N | Permissible Thrust Load: 280N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/40 400V GV-SF 2.2kW ratio 1/40 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/40 | Actual Ratio: 1/39.27 | Output Shaft Speed: 75r/min | Permissible Output Torque: 234Nm | Permissible Overhang Load: 2740N | Permissible Thrust Load: 374N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/50 400V GV-SF 2.2kW ratio 1/50 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/50 | Actual Ratio: 1/49.07 | Output Shaft Speed: 60r/min | Permissible Output Torque: 292Nm | Permissible Overhang Load: 2740N | Permissible Thrust Load: 374N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/60 400V GV-SF 2.2kW ratio 1/60 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/60 | Actual Ratio: 1/58.42 | Output Shaft Speed: 50r/min | Permissible Output Torque: 348Nm | Permissible Overhang Load: 3130N | Permissible Thrust Load: 560N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/80 400V GV-SF 2.2kW ratio 1/80 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/80 | Actual Ratio: 1/81.24 | Output Shaft Speed: 37.5r/min | Permissible Output Torque: 484Nm | Permissible Overhang Load: 3130N | Permissible Thrust Load: 560N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/100 400V GV-SF 2.2kW ratio 1/100 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/100 | Actual Ratio: 1/90.27 | Output Shaft Speed: 30r/min | Permissible Output Torque: 537Nm | Permissible Overhang Load: 3130N | Permissible Thrust Load: 560N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/120 400V GV-SF 2.2kW ratio 1/120 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/120 | Actual Ratio: 1/115.15 | Output Shaft Speed: 25r/min | Permissible Output Torque: 685Nm | Permissible Overhang Load: 4700N | Permissible Thrust Load: 960N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/160 400V GV-SF 2.2kW ratio 1/160 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/160 | Actual Ratio: 1/160.07 | Output Shaft Speed: 18.8r/min | Permissible Output Torque: 953Nm | Permissible Overhang Load: 4930N | Permissible Thrust Load: 960N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/200 400V GV-SF 2.2kW ratio 1/200 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/200 | Actual Ratio: 1/183.75 | Output Shaft Speed: 15r/min | Permissible Output Torque: 1094Nm | Permissible Overhang Load: 5090N | Permissible Thrust Load: 960N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
Sensorless Servo Geared MotorsMitsubishi Electric
14 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric GV-SF 2.2kW 400V Class S-PM Sensorless Servo Geared Motor (Parallel Shaft, Flange Mount, without Brake)

Brand Mitsubishi Electric·Sensorless Servo Geared Motors

Available part numbers (14)

GV-SF 2.2kW 1/5 400V, GV-SF 2.2kW 1/10 400V, GV-SF 2.2kW 1/15 400V, GV-SF 2.2kW 1/20 400V, GV-SF 2.2kW 1/25 400V, GV-SF 2.2kW 1/30 400V, GV-SF 2.2kW 1/40 400V, GV-SF 2.2kW 1/50 400V, GV-SF 2.2kW 1/60 400V, GV-SF 2.2kW 1/80 400V + 4 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
GV-SF 2.2kW 1/5 400VGV-SF 2.2kW ratio 1/5 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/5 | Actual Ratio: 1/4.98 | Output Shaft Speed: 600r/min | Permissible Output Torque: 31Nm | Permissible Overhang Load: 1560N | Permissible Thrust Load: 56N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/10 400VGV-SF 2.2kW ratio 1/10 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/10 | Actual Ratio: 1/9.57 | Output Shaft Speed: 300r/min | Permissible Output Torque: 60Nm | Permissible Overhang Load: 1560N | Permissible Thrust Load: 94N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/15 400VGV-SF 2.2kW ratio 1/15 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/15 | Actual Ratio: 1/14.49 | Output Shaft Speed: 200r/min | Permissible Output Torque: 91Nm | Permissible Overhang Load: 1560N | Permissible Thrust Load: 94N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/20 400VGV-SF 2.2kW ratio 1/20 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/20 | Actual Ratio: 1/20.31 | Output Shaft Speed: 150r/min | Permissible Output Torque: 128Nm | Permissible Overhang Load: 1960N | Permissible Thrust Load: 186N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/25 400VGV-SF 2.2kW ratio 1/25 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/25 | Actual Ratio: 1/24.80 | Output Shaft Speed: 120r/min | Permissible Output Torque: 156Nm | Permissible Overhang Load: 1960N | Permissible Thrust Load: 186N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/30 400VGV-SF 2.2kW ratio 1/30 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/30 | Actual Ratio: 1/27.72 | Output Shaft Speed: 100r/min | Permissible Output Torque: 175Nm | Permissible Overhang Load: 2350N | Permissible Thrust Load: 280N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/40 400VGV-SF 2.2kW ratio 1/40 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/40 | Actual Ratio: 1/39.27 | Output Shaft Speed: 75r/min | Permissible Output Torque: 234Nm | Permissible Overhang Load: 2740N | Permissible Thrust Load: 374N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/50 400VGV-SF 2.2kW ratio 1/50 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/50 | Actual Ratio: 1/49.07 | Output Shaft Speed: 60r/min | Permissible Output Torque: 292Nm | Permissible Overhang Load: 2740N | Permissible Thrust Load: 374N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/60 400VGV-SF 2.2kW ratio 1/60 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/60 | Actual Ratio: 1/58.42 | Output Shaft Speed: 50r/min | Permissible Output Torque: 348Nm | Permissible Overhang Load: 3130N | Permissible Thrust Load: 560N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/80 400VGV-SF 2.2kW ratio 1/80 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/80 | Actual Ratio: 1/81.24 | Output Shaft Speed: 37.5r/min | Permissible Output Torque: 484Nm | Permissible Overhang Load: 3130N | Permissible Thrust Load: 560N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/100 400VGV-SF 2.2kW ratio 1/100 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/100 | Actual Ratio: 1/90.27 | Output Shaft Speed: 30r/min | Permissible Output Torque: 537Nm | Permissible Overhang Load: 3130N | Permissible Thrust Load: 560N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/120 400VGV-SF 2.2kW ratio 1/120 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/120 | Actual Ratio: 1/115.15 | Output Shaft Speed: 25r/min | Permissible Output Torque: 685Nm | Permissible Overhang Load: 4700N | Permissible Thrust Load: 960N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/160 400VGV-SF 2.2kW ratio 1/160 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/160 | Actual Ratio: 1/160.07 | Output Shaft Speed: 18.8r/min | Permissible Output Torque: 953Nm | Permissible Overhang Load: 4930N | Permissible Thrust Load: 960N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SF 2.2kW 1/200 400VGV-SF 2.2kW ratio 1/200 400V class, flange mount, without brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 2.2kW | Nominal Ratio: 1/200 | Actual Ratio: 1/183.75 | Output Shaft Speed: 15r/min | Permissible Output Torque: 1094Nm | Permissible Overhang Load: 5090N | Permissible Thrust Load: 960N | Motor Rated Voltage: 315V | Motor Rated Current: 4.7A | Poles: 6P | Motor Rated Frequency: 150Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-3.7K-G | Power Supply Capacity: 9.5kVA | Mount: Flange | Brake: None | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
