Mitsubishi Electric GV-SFB 0.1kW S-PM Sensorless Servo Geared Motor (Flange Mount, Brake)

Mitsubishi Electric GV-SFB 0.1kW S-PM Sensorless Servo Geared Motor (Flange Mount, Brake)

Mitsubishi Electric GV-SFB 0.1kW S-PM sensorless servo geared motor, flange mount, combining a permanent-magnet motor with PM sensorless vector control for wide constant-torque speed range.

Key features

  • Nominal reduction ratios 1/5 to 1/1200 with permissible output torque 1.4 to 294 Nm
  • Motor rated 3000 r/min, 4P, insulation class 130(B), grease-lubricated, IP44 indoor
  • Built-in DC spring-applied brake for load holding
  • Requires a matching S-PM drive unit (3-phase 200-240V input; cannot be connected directly to commercial power)

Specifications

Series GV-S (S-PM sensorless servo)
Type Parallel Shaft
Mount Flange mount
Brake Built-in DC spring-applied
Output 0.1kW
Poles 4P
Motor Rated Voltage 155V
Motor Rated Current 0.55A
Drive Input 3-phase 200-240V 50/60Hz (drive unit required)
Insulation 130(B)
Enclosure Totally-enclosed non-ventilated (TENV)
Lubrication Grease
GV-SFB 0.1kW 1/5 GV-SFB 0.1kW 1/5, flange mount, 1.4Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/5 | Actual Ratio: 1/4.97 | Output Speed: 600 r/min (motor 3000 r/min) | Permissible Output Torque: 1.4 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 25 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/10 GV-SFB 0.1kW 1/10, flange mount, 2.8Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/10 | Actual Ratio: 1/9.93 | Output Speed: 300 r/min (motor 3000 r/min) | Permissible Output Torque: 2.8 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 42 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/15 GV-SFB 0.1kW 1/15, flange mount, 4.2Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/15 | Actual Ratio: 1/14.81 | Output Speed: 200 r/min (motor 3000 r/min) | Permissible Output Torque: 4.2 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 42 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/20 GV-SFB 0.1kW 1/20, flange mount, 5.8Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/20 | Actual Ratio: 1/20.08 | Output Speed: 150 r/min (motor 3000 r/min) | Permissible Output Torque: 5.8 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 83 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/25 GV-SFB 0.1kW 1/25, flange mount, 6.8Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/25 | Actual Ratio: 1/23.85 | Output Speed: 120 r/min (motor 3000 r/min) | Permissible Output Torque: 6.8 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 83 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/30 GV-SFB 0.1kW 1/30, flange mount, 8.3Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/30 | Actual Ratio: 1/28.88 | Output Speed: 100 r/min (motor 3000 r/min) | Permissible Output Torque: 8.3 Nm | Permissible Overhang Load: 735 N | Permissible Thrust Load: 125 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/40 GV-SFB 0.1kW 1/40, flange mount, 10Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/40 | Actual Ratio: 1/37.92 | Output Speed: 75 r/min (motor 3000 r/min) | Permissible Output Torque: 10 Nm | Permissible Overhang Load: 1030 N | Permissible Thrust Load: 167 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/50 GV-SFB 0.1kW 1/50, flange mount, 13Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/50 | Actual Ratio: 1/47.32 | Output Speed: 60 r/min (motor 3000 r/min) | Permissible Output Torque: 13 Nm | Permissible Overhang Load: 1180 N | Permissible Thrust Load: 208 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/60 GV-SFB 0.1kW 1/60, flange mount, 16Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/60 | Actual Ratio: 1/58.98 | Output Speed: 50 r/min (motor 3000 r/min) | Permissible Output Torque: 16 Nm | Permissible Overhang Load: 1180 N | Permissible Thrust Load: 250 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/80 GV-SFB 0.1kW 1/80, flange mount, 22Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/80 | Actual Ratio: 1/80.05 | Output Speed: 37.5 r/min (motor 3000 r/min) | Permissible Output Torque: 22 Nm | Permissible Overhang Load: 1230 N | Permissible Thrust Load: 250 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/100 GV-SFB 0.1kW 1/100, flange mount, 26Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/100 | Actual Ratio: 1/95.44 | Output Speed: 30 r/min (motor 3000 r/min) | Permissible Output Torque: 26 Nm | Permissible Overhang Load: 1270 N | Permissible Thrust Load: 250 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/120 GV-SFB 0.1kW 1/120, flange mount, 31Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/120 | Actual Ratio: 1/114.05 | Output Speed: 25 r/min (motor 3000 r/min) | Permissible Output Torque: 31 Nm | Permissible Overhang Load: 1620 N | Permissible Thrust Load: 300 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/160 GV-SFB 0.1kW 1/160, flange mount, 41Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/160 | Actual Ratio: 1/151.67 | Output Speed: 18.8 r/min (motor 3000 r/min) | Permissible Output Torque: 41 Nm | Permissible Overhang Load: 1670 N | Permissible Thrust Load: 300 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/200 GV-SFB 0.1kW 1/200, flange mount, 46Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/200 | Actual Ratio: 1/168.76 | Output Speed: 15 r/min (motor 3000 r/min) | Permissible Output Torque: 46 Nm | Permissible Overhang Load: 1720 N | Permissible Thrust Load: 300 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/270 GV-SFB 0.1kW 1/270, flange mount, 71Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/270 | Actual Ratio: 1/278.78 | Output Speed: 11.1 r/min (motor 3000 r/min) | Permissible Output Torque: 71 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 600 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/360 GV-SFB 0.1kW 1/360, flange mount, 94Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/360 | Actual Ratio: 1/367.62 | Output Speed: 8.3 r/min (motor 3000 r/min) | Permissible Output Torque: 94 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 600 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/450 GV-SFB 0.1kW 1/450, flange mount, 116Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/450 | Actual Ratio: 1/453.76 | Output Speed: 6.7 r/min (motor 3000 r/min) | Permissible Output Torque: 116 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 600 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/540 GV-SFB 0.1kW 1/540, flange mount, 129Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/540 | Actual Ratio: 1/508.20 | Output Speed: 5.6 r/min (motor 3000 r/min) | Permissible Output Torque: 129 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/720 GV-SFB 0.1kW 1/720, flange mount, 176Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/720 | Actual Ratio: 1/693.00 | Output Speed: 4.2 r/min (motor 3000 r/min) | Permissible Output Torque: 176 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/900 GV-SFB 0.1kW 1/900, flange mount, 220Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/900 | Actual Ratio: 1/865.82 | Output Speed: 3.3 r/min (motor 3000 r/min) | Permissible Output Torque: 220 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/1200 GV-SFB 0.1kW 1/1200, flange mount, 294Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/1200 | Actual Ratio: 1/1154.42 | Output Speed: 2.5 r/min (motor 3000 r/min) | Permissible Output Torque: 294 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
Sensorless Servo Geared MotorsMitsubishi Electric
21 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric GV-SFB 0.1kW S-PM Sensorless Servo Geared Motor (Flange Mount, Brake)

Brand Mitsubishi Electric·Sensorless Servo Geared Motors

Available part numbers (21)

GV-SFB 0.1kW 1/5, GV-SFB 0.1kW 1/10, GV-SFB 0.1kW 1/15, GV-SFB 0.1kW 1/20, GV-SFB 0.1kW 1/25, GV-SFB 0.1kW 1/30, GV-SFB 0.1kW 1/40, GV-SFB 0.1kW 1/50, GV-SFB 0.1kW 1/60, GV-SFB 0.1kW 1/80 + 11 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
GV-SFB 0.1kW 1/5GV-SFB 0.1kW 1/5, flange mount, 1.4Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/5 | Actual Ratio: 1/4.97 | Output Speed: 600 r/min (motor 3000 r/min) | Permissible Output Torque: 1.4 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 25 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/10GV-SFB 0.1kW 1/10, flange mount, 2.8Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/10 | Actual Ratio: 1/9.93 | Output Speed: 300 r/min (motor 3000 r/min) | Permissible Output Torque: 2.8 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 42 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/15GV-SFB 0.1kW 1/15, flange mount, 4.2Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/15 | Actual Ratio: 1/14.81 | Output Speed: 200 r/min (motor 3000 r/min) | Permissible Output Torque: 4.2 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 42 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/20GV-SFB 0.1kW 1/20, flange mount, 5.8Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/20 | Actual Ratio: 1/20.08 | Output Speed: 150 r/min (motor 3000 r/min) | Permissible Output Torque: 5.8 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 83 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/25GV-SFB 0.1kW 1/25, flange mount, 6.8Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/25 | Actual Ratio: 1/23.85 | Output Speed: 120 r/min (motor 3000 r/min) | Permissible Output Torque: 6.8 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 83 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/30GV-SFB 0.1kW 1/30, flange mount, 8.3Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/30 | Actual Ratio: 1/28.88 | Output Speed: 100 r/min (motor 3000 r/min) | Permissible Output Torque: 8.3 Nm | Permissible Overhang Load: 735 N | Permissible Thrust Load: 125 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/40GV-SFB 0.1kW 1/40, flange mount, 10Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/40 | Actual Ratio: 1/37.92 | Output Speed: 75 r/min (motor 3000 r/min) | Permissible Output Torque: 10 Nm | Permissible Overhang Load: 1030 N | Permissible Thrust Load: 167 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/50GV-SFB 0.1kW 1/50, flange mount, 13Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/50 | Actual Ratio: 1/47.32 | Output Speed: 60 r/min (motor 3000 r/min) | Permissible Output Torque: 13 Nm | Permissible Overhang Load: 1180 N | Permissible Thrust Load: 208 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/60GV-SFB 0.1kW 1/60, flange mount, 16Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/60 | Actual Ratio: 1/58.98 | Output Speed: 50 r/min (motor 3000 r/min) | Permissible Output Torque: 16 Nm | Permissible Overhang Load: 1180 N | Permissible Thrust Load: 250 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/80GV-SFB 0.1kW 1/80, flange mount, 22Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/80 | Actual Ratio: 1/80.05 | Output Speed: 37.5 r/min (motor 3000 r/min) | Permissible Output Torque: 22 Nm | Permissible Overhang Load: 1230 N | Permissible Thrust Load: 250 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/100GV-SFB 0.1kW 1/100, flange mount, 26Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/100 | Actual Ratio: 1/95.44 | Output Speed: 30 r/min (motor 3000 r/min) | Permissible Output Torque: 26 Nm | Permissible Overhang Load: 1270 N | Permissible Thrust Load: 250 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/120GV-SFB 0.1kW 1/120, flange mount, 31Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/120 | Actual Ratio: 1/114.05 | Output Speed: 25 r/min (motor 3000 r/min) | Permissible Output Torque: 31 Nm | Permissible Overhang Load: 1620 N | Permissible Thrust Load: 300 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/160GV-SFB 0.1kW 1/160, flange mount, 41Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/160 | Actual Ratio: 1/151.67 | Output Speed: 18.8 r/min (motor 3000 r/min) | Permissible Output Torque: 41 Nm | Permissible Overhang Load: 1670 N | Permissible Thrust Load: 300 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/200GV-SFB 0.1kW 1/200, flange mount, 46Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/200 | Actual Ratio: 1/168.76 | Output Speed: 15 r/min (motor 3000 r/min) | Permissible Output Torque: 46 Nm | Permissible Overhang Load: 1720 N | Permissible Thrust Load: 300 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/270GV-SFB 0.1kW 1/270, flange mount, 71Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/270 | Actual Ratio: 1/278.78 | Output Speed: 11.1 r/min (motor 3000 r/min) | Permissible Output Torque: 71 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 600 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/360GV-SFB 0.1kW 1/360, flange mount, 94Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/360 | Actual Ratio: 1/367.62 | Output Speed: 8.3 r/min (motor 3000 r/min) | Permissible Output Torque: 94 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 600 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/450GV-SFB 0.1kW 1/450, flange mount, 116Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/450 | Actual Ratio: 1/453.76 | Output Speed: 6.7 r/min (motor 3000 r/min) | Permissible Output Torque: 116 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 600 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/540GV-SFB 0.1kW 1/540, flange mount, 129Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/540 | Actual Ratio: 1/508.20 | Output Speed: 5.6 r/min (motor 3000 r/min) | Permissible Output Torque: 129 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/720GV-SFB 0.1kW 1/720, flange mount, 176Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/720 | Actual Ratio: 1/693.00 | Output Speed: 4.2 r/min (motor 3000 r/min) | Permissible Output Torque: 176 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/900GV-SFB 0.1kW 1/900, flange mount, 220Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/900 | Actual Ratio: 1/865.82 | Output Speed: 3.3 r/min (motor 3000 r/min) | Permissible Output Torque: 220 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.1kW 1/1200GV-SFB 0.1kW 1/1200, flange mount, 294Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.1kW | Poles: 4P | Nominal Ratio: 1/1200 | Actual Ratio: 1/1154.42 | Output Speed: 2.5 r/min (motor 3000 r/min) | Permissible Output Torque: 294 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 155V | Motor Rated Current: 0.55A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
