• Mitsubishi Electric GV-SFB 0.75kW S-PM Sensorless Servo Geared Motor (Flange Mount, Brake)
1 1

Mitsubishi Electric GV-SFB 0.75kW S-PM Sensorless Servo Geared Motor (Flange Mount, Brake)

Mitsubishi Electric GV-SFB 0.75kW S-PM Sensorless Servo Geared Motor (Flange Mount, Brake)

Mitsubishi Electric GV-SFB 0.75kW S-PM sensorless servo geared motor, flange mount, combining a permanent-magnet motor with PM sensorless vector control for wide constant-torque speed range.

Key features

  • Nominal reduction ratios 1/5 to 1/1200 with permissible output torque 11 to 1230 Nm
  • Motor rated 3000 r/min, 4P, insulation class 130(B), grease-lubricated, IP44 indoor
  • Built-in DC spring-applied brake for load holding
  • Requires a matching S-PM drive unit (3-phase 200-240V input; cannot be connected directly to commercial power)

Specifications

Series GV-S (S-PM sensorless servo)
Type Parallel Shaft
Mount Flange mount
Brake Built-in DC spring-applied
Output 0.75kW
Poles 4P
Motor Rated Voltage 175V
Motor Rated Current 2.8A
Drive Input 3-phase 200-240V 50/60Hz (drive unit required)
Insulation 130(B)
Enclosure Totally-enclosed non-ventilated (TENV)
Lubrication Grease
GV-SFB 0.75kW 1/5 GV-SFB 0.75kW 1/5, flange mount, 11Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/5 | Actual Ratio: 1/5.04 | Output Speed: 600 r/min (motor 3000 r/min) | Permissible Output Torque: 11 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 30 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/10 GV-SFB 0.75kW 1/10, flange mount, 21Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/10 | Actual Ratio: 1/9.80 | Output Speed: 300 r/min (motor 3000 r/min) | Permissible Output Torque: 21 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 50 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/15 GV-SFB 0.75kW 1/15, flange mount, 31Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/15 | Actual Ratio: 1/14.44 | Output Speed: 200 r/min (motor 3000 r/min) | Permissible Output Torque: 31 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 50 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/20 GV-SFB 0.75kW 1/20, flange mount, 42Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/20 | Actual Ratio: 1/19.60 | Output Speed: 150 r/min (motor 3000 r/min) | Permissible Output Torque: 42 Nm | Permissible Overhang Load: 1370 N | Permissible Thrust Load: 100 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/25 GV-SFB 0.75kW 1/25, flange mount, 55Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/25 | Actual Ratio: 1/25.73 | Output Speed: 120 r/min (motor 3000 r/min) | Permissible Output Torque: 55 Nm | Permissible Overhang Load: 1370 N | Permissible Thrust Load: 100 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/30 GV-SFB 0.75kW 1/30, flange mount, 61Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/30 | Actual Ratio: 1/28.51 | Output Speed: 100 r/min (motor 3000 r/min) | Permissible Output Torque: 61 Nm | Permissible Overhang Load: 1470 N | Permissible Thrust Load: 150 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/40 GV-SFB 0.75kW 1/40, flange mount, 79Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/40 | Actual Ratio: 1/38.89 | Output Speed: 75 r/min (motor 3000 r/min) | Permissible Output Torque: 79 Nm | Permissible Overhang Load: 1570 N | Permissible Thrust Load: 200 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/50 GV-SFB 0.75kW 1/50, flange mount, 88Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/50 | Actual Ratio: 1/43.27 | Output Speed: 60 r/min (motor 3000 r/min) | Permissible Output Torque: 88 Nm | Permissible Overhang Load: 1620 N | Permissible Thrust Load: 250 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/60 GV-SFB 0.75kW 1/60, flange mount, 126Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/60 | Actual Ratio: 1/61.95 | Output Speed: 50 r/min (motor 3000 r/min) | Permissible Output Torque: 126 Nm | Permissible Overhang Load: 1760 N | Permissible Thrust Load: 300 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/80 GV-SFB 0.75kW 1/80, flange mount, 166Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/80 | Actual Ratio: 1/81.69 | Output Speed: 37.5 r/min (motor 3000 r/min) | Permissible Output Torque: 166 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/100 GV-SFB 0.75kW 1/100, flange mount, 205Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/100 | Actual Ratio: 1/100.84 | Output Speed: 30 r/min (motor 3000 r/min) | Permissible Output Torque: 205 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/120 GV-SFB 0.75kW 1/120, flange mount, 229Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/120 | Actual Ratio: 1/112.93 | Output Speed: 25 r/min (motor 3000 r/min) | Permissible Output Torque: 229 Nm | Permissible Overhang Load: 2550 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/160 GV-SFB 0.75kW 1/160, flange mount, 313Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/160 | Actual Ratio: 1/154.00 | Output Speed: 18.8 r/min (motor 3000 r/min) | Permissible Output Torque: 313 Nm | Permissible Overhang Load: 2650 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/200 GV-SFB 0.75kW 1/200, flange mount, 390Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/200 | Actual Ratio: 1/192.40 | Output Speed: 15 r/min (motor 3000 r/min) | Permissible Output Torque: 390 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/270 GV-SFB 0.75kW 1/270, flange mount, 502Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/270 | Actual Ratio: 1/262.89 | Output Speed: 11.1 r/min (motor 3000 r/min) | Permissible Output Torque: 502 Nm | Permissible Overhang Load: 3920 N | Permissible Thrust Load: 700 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/360 GV-SFB 0.75kW 1/360, flange mount, 698Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/360 | Actual Ratio: 1/365.59 | Output Speed: 8.3 r/min (motor 3000 r/min) | Permissible Output Torque: 698 Nm | Permissible Overhang Load: 3920 N | Permissible Thrust Load: 700 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/450 GV-SFB 0.75kW 1/450, flange mount, 769Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/450 | Actual Ratio: 1/406.22 | Output Speed: 6.7 r/min (motor 3000 r/min) | Permissible Output Torque: 769 Nm (torque-limited) | Permissible Overhang Load: 3920 N | Permissible Thrust Load: 700 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/540 GV-SFB 0.75kW 1/540, flange mount, 990Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/540 | Actual Ratio: 1/518.18 | Output Speed: 5.6 r/min (motor 3000 r/min) | Permissible Output Torque: 990 Nm | Permissible Overhang Load: 6370 N | Permissible Thrust Load: 1200 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/720 GV-SFB 0.75kW 1/720, flange mount, 1230Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/720 | Actual Ratio: 1/720.30 | Output Speed: 4.2 r/min (motor 3000 r/min) | Permissible Output Torque: 1230 Nm (torque-limited) | Permissible Overhang Load: 6370 N | Permissible Thrust Load: 1200 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/900 GV-SFB 0.75kW 1/900, flange mount, 1230Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/900 | Actual Ratio: 1/826.88 | Output Speed: 3.3 r/min (motor 3000 r/min) | Permissible Output Torque: 1230 Nm (torque-limited) | Permissible Overhang Load: 6370 N | Permissible Thrust Load: 1200 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/1200 GV-SFB 0.75kW 1/1200, flange mount, 1230Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/1200 | Actual Ratio: 1/1102.50 | Output Speed: 2.5 r/min (motor 3000 r/min) | Permissible Output Torque: 1230 Nm (torque-limited) | Permissible Overhang Load: 6370 N | Permissible Thrust Load: 1200 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
Sensorless Servo Geared MotorsMitsubishi Electric
21 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric GV-SFB 0.75kW S-PM Sensorless Servo Geared Motor (Flange Mount, Brake)

Brand Mitsubishi Electric·Sensorless Servo Geared Motors

Available part numbers (21)

GV-SFB 0.75kW 1/5, GV-SFB 0.75kW 1/10, GV-SFB 0.75kW 1/15, GV-SFB 0.75kW 1/20, GV-SFB 0.75kW 1/25, GV-SFB 0.75kW 1/30, GV-SFB 0.75kW 1/40, GV-SFB 0.75kW 1/50, GV-SFB 0.75kW 1/60, GV-SFB 0.75kW 1/80 + 11 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
GV-SFB 0.75kW 1/5GV-SFB 0.75kW 1/5, flange mount, 11Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/5 | Actual Ratio: 1/5.04 | Output Speed: 600 r/min (motor 3000 r/min) | Permissible Output Torque: 11 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 30 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/10GV-SFB 0.75kW 1/10, flange mount, 21Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/10 | Actual Ratio: 1/9.80 | Output Speed: 300 r/min (motor 3000 r/min) | Permissible Output Torque: 21 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 50 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/15GV-SFB 0.75kW 1/15, flange mount, 31Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/15 | Actual Ratio: 1/14.44 | Output Speed: 200 r/min (motor 3000 r/min) | Permissible Output Torque: 31 Nm | Permissible Overhang Load: 685 N | Permissible Thrust Load: 50 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/20GV-SFB 0.75kW 1/20, flange mount, 42Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/20 | Actual Ratio: 1/19.60 | Output Speed: 150 r/min (motor 3000 r/min) | Permissible Output Torque: 42 Nm | Permissible Overhang Load: 1370 N | Permissible Thrust Load: 100 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/25GV-SFB 0.75kW 1/25, flange mount, 55Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/25 | Actual Ratio: 1/25.73 | Output Speed: 120 r/min (motor 3000 r/min) | Permissible Output Torque: 55 Nm | Permissible Overhang Load: 1370 N | Permissible Thrust Load: 100 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/30GV-SFB 0.75kW 1/30, flange mount, 61Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/30 | Actual Ratio: 1/28.51 | Output Speed: 100 r/min (motor 3000 r/min) | Permissible Output Torque: 61 Nm | Permissible Overhang Load: 1470 N | Permissible Thrust Load: 150 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/40GV-SFB 0.75kW 1/40, flange mount, 79Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/40 | Actual Ratio: 1/38.89 | Output Speed: 75 r/min (motor 3000 r/min) | Permissible Output Torque: 79 Nm | Permissible Overhang Load: 1570 N | Permissible Thrust Load: 200 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/50GV-SFB 0.75kW 1/50, flange mount, 88Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/50 | Actual Ratio: 1/43.27 | Output Speed: 60 r/min (motor 3000 r/min) | Permissible Output Torque: 88 Nm | Permissible Overhang Load: 1620 N | Permissible Thrust Load: 250 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/60GV-SFB 0.75kW 1/60, flange mount, 126Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/60 | Actual Ratio: 1/61.95 | Output Speed: 50 r/min (motor 3000 r/min) | Permissible Output Torque: 126 Nm | Permissible Overhang Load: 1760 N | Permissible Thrust Load: 300 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/80GV-SFB 0.75kW 1/80, flange mount, 166Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/80 | Actual Ratio: 1/81.69 | Output Speed: 37.5 r/min (motor 3000 r/min) | Permissible Output Torque: 166 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/100GV-SFB 0.75kW 1/100, flange mount, 205Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/100 | Actual Ratio: 1/100.84 | Output Speed: 30 r/min (motor 3000 r/min) | Permissible Output Torque: 205 Nm | Permissible Overhang Load: 2350 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/120GV-SFB 0.75kW 1/120, flange mount, 229Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/120 | Actual Ratio: 1/112.93 | Output Speed: 25 r/min (motor 3000 r/min) | Permissible Output Torque: 229 Nm | Permissible Overhang Load: 2550 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/160GV-SFB 0.75kW 1/160, flange mount, 313Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/160 | Actual Ratio: 1/154.00 | Output Speed: 18.8 r/min (motor 3000 r/min) | Permissible Output Torque: 313 Nm | Permissible Overhang Load: 2650 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/200GV-SFB 0.75kW 1/200, flange mount, 390Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/200 | Actual Ratio: 1/192.40 | Output Speed: 15 r/min (motor 3000 r/min) | Permissible Output Torque: 390 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/270GV-SFB 0.75kW 1/270, flange mount, 502Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/270 | Actual Ratio: 1/262.89 | Output Speed: 11.1 r/min (motor 3000 r/min) | Permissible Output Torque: 502 Nm | Permissible Overhang Load: 3920 N | Permissible Thrust Load: 700 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/360GV-SFB 0.75kW 1/360, flange mount, 698Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/360 | Actual Ratio: 1/365.59 | Output Speed: 8.3 r/min (motor 3000 r/min) | Permissible Output Torque: 698 Nm | Permissible Overhang Load: 3920 N | Permissible Thrust Load: 700 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/450GV-SFB 0.75kW 1/450, flange mount, 769Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/450 | Actual Ratio: 1/406.22 | Output Speed: 6.7 r/min (motor 3000 r/min) | Permissible Output Torque: 769 Nm (torque-limited) | Permissible Overhang Load: 3920 N | Permissible Thrust Load: 700 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/540GV-SFB 0.75kW 1/540, flange mount, 990Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/540 | Actual Ratio: 1/518.18 | Output Speed: 5.6 r/min (motor 3000 r/min) | Permissible Output Torque: 990 Nm | Permissible Overhang Load: 6370 N | Permissible Thrust Load: 1200 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/720GV-SFB 0.75kW 1/720, flange mount, 1230Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/720 | Actual Ratio: 1/720.30 | Output Speed: 4.2 r/min (motor 3000 r/min) | Permissible Output Torque: 1230 Nm (torque-limited) | Permissible Overhang Load: 6370 N | Permissible Thrust Load: 1200 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/900GV-SFB 0.75kW 1/900, flange mount, 1230Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/900 | Actual Ratio: 1/826.88 | Output Speed: 3.3 r/min (motor 3000 r/min) | Permissible Output Torque: 1230 Nm (torque-limited) | Permissible Overhang Load: 6370 N | Permissible Thrust Load: 1200 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 0.75kW 1/1200GV-SFB 0.75kW 1/1200, flange mount, 1230Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 0.75kW | Poles: 4P | Nominal Ratio: 1/1200 | Actual Ratio: 1/1102.50 | Output Speed: 2.5 r/min (motor 3000 r/min) | Permissible Output Torque: 1230 Nm (torque-limited) | Permissible Overhang Load: 6370 N | Permissible Thrust Load: 1200 N | Motor Rated Voltage: 175V | Motor Rated Current: 2.8A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed non-ventilated (TENV) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
