Mitsubishi Electric GV-SFB 1.5kW S-PM Sensorless Servo Geared Motor (Flange Mount, Brake)

Mitsubishi Electric GV-SFB 1.5kW S-PM Sensorless Servo Geared Motor (Flange Mount, Brake)

Mitsubishi Electric GV-SFB 1.5kW S-PM sensorless servo geared motor, flange mount, combining a permanent-magnet motor with PM sensorless vector control for wide constant-torque speed range.

Key features

  • Nominal reduction ratios 1/5 to 1/450 with permissible output torque 22 to 1230 Nm
  • Motor rated 3000 r/min, 6P, insulation class 130(B), grease-lubricated, IP44 indoor
  • Built-in DC spring-applied brake for load holding
  • Requires a matching S-PM drive unit (3-phase 200-240V input; cannot be connected directly to commercial power)

Specifications

Series GV-S (S-PM sensorless servo)
Type Parallel Shaft
Mount Flange mount
Brake Built-in DC spring-applied
Output 1.5kW
Poles 6P
Motor Rated Voltage 180V
Motor Rated Current 5.5A
Drive Input 3-phase 200-240V 50/60Hz (drive unit required)
Insulation 130(B)
Enclosure Totally-enclosed fan-cooled (TEFC)
Lubrication Grease
GV-SFB 1.5kW 1/5 GV-SFB 1.5kW 1/5, flange mount, 22Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/5 | Actual Ratio: 1/4.87 | Output Speed: 600 r/min (motor 3000 r/min) | Permissible Output Torque: 22 Nm | Permissible Overhang Load: 980 N | Permissible Thrust Load: 50 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/10 GV-SFB 1.5kW 1/10, flange mount, 45Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/10 | Actual Ratio: 1/10.00 | Output Speed: 300 r/min (motor 3000 r/min) | Permissible Output Torque: 45 Nm | Permissible Overhang Load: 980 N | Permissible Thrust Load: 83 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/15 GV-SFB 1.5kW 1/15, flange mount, 66Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/15 | Actual Ratio: 1/14.54 | Output Speed: 200 r/min (motor 3000 r/min) | Permissible Output Torque: 66 Nm | Permissible Overhang Load: 980 N | Permissible Thrust Load: 83 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/20 GV-SFB 1.5kW 1/20, flange mount, 88Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/20 | Actual Ratio: 1/19.44 | Output Speed: 150 r/min (motor 3000 r/min) | Permissible Output Torque: 88 Nm | Permissible Overhang Load: 1470 N | Permissible Thrust Load: 167 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/25 GV-SFB 1.5kW 1/25, flange mount, 104Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/25 | Actual Ratio: 1/22.95 | Output Speed: 120 r/min (motor 3000 r/min) | Permissible Output Torque: 104 Nm | Permissible Overhang Load: 1470 N | Permissible Thrust Load: 167 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/30 GV-SFB 1.5kW 1/30, flange mount, 139Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/30 | Actual Ratio: 1/30.60 | Output Speed: 100 r/min (motor 3000 r/min) | Permissible Output Torque: 139 Nm | Permissible Overhang Load: 1570 N | Permissible Thrust Load: 250 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/40 GV-SFB 1.5kW 1/40, flange mount, 163Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/40 | Actual Ratio: 1/37.15 | Output Speed: 75 r/min (motor 3000 r/min) | Permissible Output Torque: 163 Nm | Permissible Overhang Load: 1760 N | Permissible Thrust Load: 333 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/50 GV-SFB 1.5kW 1/50, flange mount, 201Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/50 | Actual Ratio: 1/45.86 | Output Speed: 60 r/min (motor 3000 r/min) | Permissible Output Torque: 201 Nm | Permissible Overhang Load: 1960 N | Permissible Thrust Load: 417 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/60 GV-SFB 1.5kW 1/60, flange mount, 245Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/60 | Actual Ratio: 1/55.82 | Output Speed: 50 r/min (motor 3000 r/min) | Permissible Output Torque: 245 Nm | Permissible Overhang Load: 2160 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/80 GV-SFB 1.5kW 1/80, flange mount, 334Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/80 | Actual Ratio: 1/76.12 | Output Speed: 37.5 r/min (motor 3000 r/min) | Permissible Output Torque: 334 Nm | Permissible Overhang Load: 2650 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/100 GV-SFB 1.5kW 1/100, flange mount, 418Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/100 | Actual Ratio: 1/95.11 | Output Speed: 30 r/min (motor 3000 r/min) | Permissible Output Torque: 418 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/120 GV-SFB 1.5kW 1/120, flange mount, 497Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/120 | Actual Ratio: 1/113.20 | Output Speed: 25 r/min (motor 3000 r/min) | Permissible Output Torque: 497 Nm | Permissible Overhang Load: 3920 N | Permissible Thrust Load: 700 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/160 GV-SFB 1.5kW 1/160, flange mount, 692Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/160 | Actual Ratio: 1/157.42 | Output Speed: 18.8 r/min (motor 3000 r/min) | Permissible Output Torque: 692 Nm | Permissible Overhang Load: 3920 N | Permissible Thrust Load: 700 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/200 GV-SFB 1.5kW 1/200, flange mount, 768Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/200 | Actual Ratio: 1/174.91 | Output Speed: 15 r/min (motor 3000 r/min) | Permissible Output Torque: 768 Nm | Permissible Overhang Load: 3920 N | Permissible Thrust Load: 700 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/270 GV-SFB 1.5kW 1/270, flange mount, 1165Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/270 | Actual Ratio: 1/271.09 | Output Speed: 11.1 r/min (motor 3000 r/min) | Permissible Output Torque: 1165 Nm | Permissible Overhang Load: 6660 N | Permissible Thrust Load: 1200 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/360 GV-SFB 1.5kW 1/360, flange mount, 1230Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/360 | Actual Ratio: 1/376.83 | Output Speed: 8.3 r/min (motor 3000 r/min) | Permissible Output Torque: 1230 Nm (torque-limited) | Permissible Overhang Load: 6960 N | Permissible Thrust Load: 1200 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/450 GV-SFB 1.5kW 1/450, flange mount, 1230Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/450 | Actual Ratio: 1/432.59 | Output Speed: 6.7 r/min (motor 3000 r/min) | Permissible Output Torque: 1230 Nm (torque-limited) | Permissible Overhang Load: 6960 N | Permissible Thrust Load: 1200 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
Sensorless Servo Geared MotorsMitsubishi Electric
17 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric GV-SFB 1.5kW S-PM Sensorless Servo Geared Motor (Flange Mount, Brake)

Brand Mitsubishi Electric·Sensorless Servo Geared Motors

Available part numbers (17)

GV-SFB 1.5kW 1/5, GV-SFB 1.5kW 1/10, GV-SFB 1.5kW 1/15, GV-SFB 1.5kW 1/20, GV-SFB 1.5kW 1/25, GV-SFB 1.5kW 1/30, GV-SFB 1.5kW 1/40, GV-SFB 1.5kW 1/50, GV-SFB 1.5kW 1/60, GV-SFB 1.5kW 1/80 + 7 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
GV-SFB 1.5kW 1/5GV-SFB 1.5kW 1/5, flange mount, 22Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/5 | Actual Ratio: 1/4.87 | Output Speed: 600 r/min (motor 3000 r/min) | Permissible Output Torque: 22 Nm | Permissible Overhang Load: 980 N | Permissible Thrust Load: 50 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/10GV-SFB 1.5kW 1/10, flange mount, 45Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/10 | Actual Ratio: 1/10.00 | Output Speed: 300 r/min (motor 3000 r/min) | Permissible Output Torque: 45 Nm | Permissible Overhang Load: 980 N | Permissible Thrust Load: 83 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/15GV-SFB 1.5kW 1/15, flange mount, 66Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/15 | Actual Ratio: 1/14.54 | Output Speed: 200 r/min (motor 3000 r/min) | Permissible Output Torque: 66 Nm | Permissible Overhang Load: 980 N | Permissible Thrust Load: 83 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/20GV-SFB 1.5kW 1/20, flange mount, 88Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/20 | Actual Ratio: 1/19.44 | Output Speed: 150 r/min (motor 3000 r/min) | Permissible Output Torque: 88 Nm | Permissible Overhang Load: 1470 N | Permissible Thrust Load: 167 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/25GV-SFB 1.5kW 1/25, flange mount, 104Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/25 | Actual Ratio: 1/22.95 | Output Speed: 120 r/min (motor 3000 r/min) | Permissible Output Torque: 104 Nm | Permissible Overhang Load: 1470 N | Permissible Thrust Load: 167 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/30GV-SFB 1.5kW 1/30, flange mount, 139Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/30 | Actual Ratio: 1/30.60 | Output Speed: 100 r/min (motor 3000 r/min) | Permissible Output Torque: 139 Nm | Permissible Overhang Load: 1570 N | Permissible Thrust Load: 250 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/40GV-SFB 1.5kW 1/40, flange mount, 163Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/40 | Actual Ratio: 1/37.15 | Output Speed: 75 r/min (motor 3000 r/min) | Permissible Output Torque: 163 Nm | Permissible Overhang Load: 1760 N | Permissible Thrust Load: 333 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/50GV-SFB 1.5kW 1/50, flange mount, 201Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/50 | Actual Ratio: 1/45.86 | Output Speed: 60 r/min (motor 3000 r/min) | Permissible Output Torque: 201 Nm | Permissible Overhang Load: 1960 N | Permissible Thrust Load: 417 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/60GV-SFB 1.5kW 1/60, flange mount, 245Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/60 | Actual Ratio: 1/55.82 | Output Speed: 50 r/min (motor 3000 r/min) | Permissible Output Torque: 245 Nm | Permissible Overhang Load: 2160 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/80GV-SFB 1.5kW 1/80, flange mount, 334Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/80 | Actual Ratio: 1/76.12 | Output Speed: 37.5 r/min (motor 3000 r/min) | Permissible Output Torque: 334 Nm | Permissible Overhang Load: 2650 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/100GV-SFB 1.5kW 1/100, flange mount, 418Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/100 | Actual Ratio: 1/95.11 | Output Speed: 30 r/min (motor 3000 r/min) | Permissible Output Torque: 418 Nm | Permissible Overhang Load: 2740 N | Permissible Thrust Load: 500 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/120GV-SFB 1.5kW 1/120, flange mount, 497Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/120 | Actual Ratio: 1/113.20 | Output Speed: 25 r/min (motor 3000 r/min) | Permissible Output Torque: 497 Nm | Permissible Overhang Load: 3920 N | Permissible Thrust Load: 700 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/160GV-SFB 1.5kW 1/160, flange mount, 692Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/160 | Actual Ratio: 1/157.42 | Output Speed: 18.8 r/min (motor 3000 r/min) | Permissible Output Torque: 692 Nm | Permissible Overhang Load: 3920 N | Permissible Thrust Load: 700 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/200GV-SFB 1.5kW 1/200, flange mount, 768Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/200 | Actual Ratio: 1/174.91 | Output Speed: 15 r/min (motor 3000 r/min) | Permissible Output Torque: 768 Nm | Permissible Overhang Load: 3920 N | Permissible Thrust Load: 700 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/270GV-SFB 1.5kW 1/270, flange mount, 1165Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/270 | Actual Ratio: 1/271.09 | Output Speed: 11.1 r/min (motor 3000 r/min) | Permissible Output Torque: 1165 Nm | Permissible Overhang Load: 6660 N | Permissible Thrust Load: 1200 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/360GV-SFB 1.5kW 1/360, flange mount, 1230Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/360 | Actual Ratio: 1/376.83 | Output Speed: 8.3 r/min (motor 3000 r/min) | Permissible Output Torque: 1230 Nm (torque-limited) | Permissible Overhang Load: 6960 N | Permissible Thrust Load: 1200 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
GV-SFB 1.5kW 1/450GV-SFB 1.5kW 1/450, flange mount, 1230Nm, brake | Series: GV-S (S-PM sensorless servo) | Type: Parallel Shaft | Mount: Flange mount | Brake: Built-in DC spring-applied | Output: 1.5kW | Poles: 6P | Nominal Ratio: 1/450 | Actual Ratio: 1/432.59 | Output Speed: 6.7 r/min (motor 3000 r/min) | Permissible Output Torque: 1230 Nm (torque-limited) | Permissible Overhang Load: 6960 N | Permissible Thrust Load: 1200 N | Motor Rated Voltage: 180V | Motor Rated Current: 5.5A | Drive Input: 3-phase 200-240V 50/60Hz (drive unit required) | Insulation: 130(B) | Enclosure: Totally-enclosed fan-cooled (TEFC) | Lubrication: Grease | Protection: IP44 (indoor) | Availability: Made-to-order
