Mitsubishi Electric MELSERVO-J4 LM-H3 (High Thrust, Cored) Linear Servo Motor

Mitsubishi Electric MELSERVO-J4 LM-H3 (High Thrust, Cored) Linear Servo Motor

Mitsubishi MELSERVO-J4 LM-H3 (High Thrust, Cored) linear servo motor, high continuous thrust cored type with natural cooling.

Key features

  • Direct-drive linear motion, max speed up to 3.0 m/s, IP00, MR-J4 servo amplifier compatible
  • System = primary (coil) + secondary (magnet) parts

Specifications

Protection Open IP00
LM-H3P2A-07P-BSS0 LM-H3P2A-07P-BSS0, linear servo motor primary (coil), LM-H3 (High Thrust, Cored) | Part Type: Primary (coil) | Type: Cored, natural cooling | Continuous Thrust: 70 N | Max Thrust: 175 N | Max Speed: 3.0 m/s | Magnetic Attraction: 630 N | Rated Current: 1.8 A | Max Current: 5.8 A | Mass: 0.9 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-40
LM-H3P3A-12P-CSS0 LM-H3P3A-12P-CSS0, linear servo motor primary (coil), LM-H3 (High Thrust, Cored) | Part Type: Primary (coil) | Type: Cored, natural cooling | Continuous Thrust: 120 N | Max Thrust: 300 N | Max Speed: 3.0 m/s | Magnetic Attraction: 1100 N | Rated Current: 1.7 A | Max Current: 5.0 A | Mass: 1.3 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-40
LM-H3P3B-24P-CSS0 LM-H3P3B-24P-CSS0, linear servo motor primary (coil), LM-H3 (High Thrust, Cored) | Part Type: Primary (coil) | Type: Cored, natural cooling | Continuous Thrust: 240 N | Max Thrust: 600 N | Max Speed: 3.0 m/s | Magnetic Attraction: 2200 N | Rated Current: 3.4 A | Max Current: 9.9 A | Mass: 2.3 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-70
LM-H3P3C-36P-CSS0 LM-H3P3C-36P-CSS0, linear servo motor primary (coil), LM-H3 (High Thrust, Cored) | Part Type: Primary (coil) | Type: Cored, natural cooling | Continuous Thrust: 360 N | Max Thrust: 900 N | Max Speed: 3.0 m/s | Magnetic Attraction: 3300 N | Rated Current: 5.1 A | Max Current: 14.9 A | Mass: 3.3 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-70
LM-H3P3D-48P-CSS0 LM-H3P3D-48P-CSS0, linear servo motor primary (coil), LM-H3 (High Thrust, Cored) | Part Type: Primary (coil) | Type: Cored, natural cooling | Continuous Thrust: 480 N | Max Thrust: 1200 N | Max Speed: 3.0 m/s | Magnetic Attraction: 4400 N | Rated Current: 6.8 A | Max Current: 19.8 A | Mass: 4.3 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-200
LM-H3P7A-24P-ASS0 LM-H3P7A-24P-ASS0, linear servo motor primary (coil), LM-H3 (High Thrust, Cored) | Part Type: Primary (coil) | Type: Cored, natural cooling | Continuous Thrust: 240 N | Max Thrust: 600 N | Max Speed: 3.0 m/s | Magnetic Attraction: 2200 N | Rated Current: 3.4 A | Max Current: 9.6 A | Mass: 2.2 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-70
LM-H3P7B-48P-ASS0 LM-H3P7B-48P-ASS0, linear servo motor primary (coil), LM-H3 (High Thrust, Cored) | Part Type: Primary (coil) | Type: Cored, natural cooling | Continuous Thrust: 480 N | Max Thrust: 1200 N | Max Speed: 3.0 m/s | Magnetic Attraction: 4400 N | Rated Current: 6.8 A | Max Current: 19.1 A | Mass: 3.9 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-200
LM-H3P7C-72P-ASS0 LM-H3P7C-72P-ASS0, linear servo motor primary (coil), LM-H3 (High Thrust, Cored) | Part Type: Primary (coil) | Type: Cored, natural cooling | Continuous Thrust: 720 N | Max Thrust: 1800 N | Max Speed: 3.0 m/s | Magnetic Attraction: 6600 N | Rated Current: 10.2 A | Max Current: 28.6 A | Mass: 5.6 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-200
LM-H3P7D-96P-ASS0 LM-H3P7D-96P-ASS0, linear servo motor primary (coil), LM-H3 (High Thrust, Cored) | Part Type: Primary (coil) | Type: Cored, natural cooling | Continuous Thrust: 960 N | Max Thrust: 2400 N | Max Speed: 3.0 m/s | Magnetic Attraction: 8800 N | Rated Current: 13.6 A | Max Current: 38.1 A | Mass: 7.3 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-350
LM-H3S20-288-BSS0 LM-H3S20-288-BSS0, linear servo motor secondary (magnet), 288mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 288 mm | Mass: 0.7 kg | Pairs With Primary: P2A (BSS0) | Protection: Open IP00
LM-H3S20-384-BSS0 LM-H3S20-384-BSS0, linear servo motor secondary (magnet), 384mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 384 mm | Mass: 0.9 kg | Pairs With Primary: P2A (BSS0) | Protection: Open IP00
LM-H3S20-480-BSS0 LM-H3S20-480-BSS0, linear servo motor secondary (magnet), 480mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 480 mm | Mass: 1.1 kg | Pairs With Primary: P2A (BSS0) | Protection: Open IP00
LM-H3S20-768-BSS0 LM-H3S20-768-BSS0, linear servo motor secondary (magnet), 768mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 768 mm | Mass: 1.8 kg | Pairs With Primary: P2A (BSS0) | Protection: Open IP00
LM-H3S30-288-CSS0 LM-H3S30-288-CSS0, linear servo motor secondary (magnet), 288mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 288 mm | Mass: 1.0 kg | Pairs With Primary: P3 (CSS0) | Protection: Open IP00
LM-H3S30-384-CSS0 LM-H3S30-384-CSS0, linear servo motor secondary (magnet), 384mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 384 mm | Mass: 1.4 kg | Pairs With Primary: P3 (CSS0) | Protection: Open IP00
LM-H3S30-480-CSS0 LM-H3S30-480-CSS0, linear servo motor secondary (magnet), 480mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 480 mm | Mass: 1.7 kg | Pairs With Primary: P3 (CSS0) | Protection: Open IP00
LM-H3S30-768-CSS0 LM-H3S30-768-CSS0, linear servo motor secondary (magnet), 768mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 768 mm | Mass: 2.7 kg | Pairs With Primary: P3 (CSS0) | Protection: Open IP00
LM-H3S70-288-ASS0 LM-H3S70-288-ASS0, linear servo motor secondary (magnet), 288mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 288 mm | Mass: 2.8 kg | Pairs With Primary: P7 (ASS0) | Protection: Open IP00
LM-H3S70-384-ASS0 LM-H3S70-384-ASS0, linear servo motor secondary (magnet), 384mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 384 mm | Mass: 3.7 kg | Pairs With Primary: P7 (ASS0) | Protection: Open IP00
LM-H3S70-480-ASS0 LM-H3S70-480-ASS0, linear servo motor secondary (magnet), 480mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 480 mm | Mass: 4.7 kg | Pairs With Primary: P7 (ASS0) | Protection: Open IP00
LM-H3S70-768-ASS0 LM-H3S70-768-ASS0, linear servo motor secondary (magnet), 768mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 768 mm | Mass: 7.4 kg | Pairs With Primary: P7 (ASS0) | Protection: Open IP00
Linear Servo MotorsMitsubishi Electric
21 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric MELSERVO-J4 LM-H3 (High Thrust, Cored) Linear Servo Motor

Brand Mitsubishi Electric·Linear Servo Motors

Available part numbers (21)

LM-H3P2A-07P-BSS0, LM-H3P3A-12P-CSS0, LM-H3P3B-24P-CSS0, LM-H3P3C-36P-CSS0, LM-H3P3D-48P-CSS0, LM-H3P7A-24P-ASS0, LM-H3P7B-48P-ASS0, LM-H3P7C-72P-ASS0, LM-H3P7D-96P-ASS0, LM-H3S20-288-BSS0 + 11 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
LM-H3P2A-07P-BSS0LM-H3P2A-07P-BSS0, linear servo motor primary (coil), LM-H3 (High Thrust, Cored) | Part Type: Primary (coil) | Type: Cored, natural cooling | Continuous Thrust: 70 N | Max Thrust: 175 N | Max Speed: 3.0 m/s | Magnetic Attraction: 630 N | Rated Current: 1.8 A | Max Current: 5.8 A | Mass: 0.9 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-40
LM-H3P3A-12P-CSS0LM-H3P3A-12P-CSS0, linear servo motor primary (coil), LM-H3 (High Thrust, Cored) | Part Type: Primary (coil) | Type: Cored, natural cooling | Continuous Thrust: 120 N | Max Thrust: 300 N | Max Speed: 3.0 m/s | Magnetic Attraction: 1100 N | Rated Current: 1.7 A | Max Current: 5.0 A | Mass: 1.3 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-40
LM-H3P3B-24P-CSS0LM-H3P3B-24P-CSS0, linear servo motor primary (coil), LM-H3 (High Thrust, Cored) | Part Type: Primary (coil) | Type: Cored, natural cooling | Continuous Thrust: 240 N | Max Thrust: 600 N | Max Speed: 3.0 m/s | Magnetic Attraction: 2200 N | Rated Current: 3.4 A | Max Current: 9.9 A | Mass: 2.3 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-70
LM-H3P3C-36P-CSS0LM-H3P3C-36P-CSS0, linear servo motor primary (coil), LM-H3 (High Thrust, Cored) | Part Type: Primary (coil) | Type: Cored, natural cooling | Continuous Thrust: 360 N | Max Thrust: 900 N | Max Speed: 3.0 m/s | Magnetic Attraction: 3300 N | Rated Current: 5.1 A | Max Current: 14.9 A | Mass: 3.3 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-70
LM-H3P3D-48P-CSS0LM-H3P3D-48P-CSS0, linear servo motor primary (coil), LM-H3 (High Thrust, Cored) | Part Type: Primary (coil) | Type: Cored, natural cooling | Continuous Thrust: 480 N | Max Thrust: 1200 N | Max Speed: 3.0 m/s | Magnetic Attraction: 4400 N | Rated Current: 6.8 A | Max Current: 19.8 A | Mass: 4.3 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-200
LM-H3P7A-24P-ASS0LM-H3P7A-24P-ASS0, linear servo motor primary (coil), LM-H3 (High Thrust, Cored) | Part Type: Primary (coil) | Type: Cored, natural cooling | Continuous Thrust: 240 N | Max Thrust: 600 N | Max Speed: 3.0 m/s | Magnetic Attraction: 2200 N | Rated Current: 3.4 A | Max Current: 9.6 A | Mass: 2.2 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-70
LM-H3P7B-48P-ASS0LM-H3P7B-48P-ASS0, linear servo motor primary (coil), LM-H3 (High Thrust, Cored) | Part Type: Primary (coil) | Type: Cored, natural cooling | Continuous Thrust: 480 N | Max Thrust: 1200 N | Max Speed: 3.0 m/s | Magnetic Attraction: 4400 N | Rated Current: 6.8 A | Max Current: 19.1 A | Mass: 3.9 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-200
LM-H3P7C-72P-ASS0LM-H3P7C-72P-ASS0, linear servo motor primary (coil), LM-H3 (High Thrust, Cored) | Part Type: Primary (coil) | Type: Cored, natural cooling | Continuous Thrust: 720 N | Max Thrust: 1800 N | Max Speed: 3.0 m/s | Magnetic Attraction: 6600 N | Rated Current: 10.2 A | Max Current: 28.6 A | Mass: 5.6 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-200
LM-H3P7D-96P-ASS0LM-H3P7D-96P-ASS0, linear servo motor primary (coil), LM-H3 (High Thrust, Cored) | Part Type: Primary (coil) | Type: Cored, natural cooling | Continuous Thrust: 960 N | Max Thrust: 2400 N | Max Speed: 3.0 m/s | Magnetic Attraction: 8800 N | Rated Current: 13.6 A | Max Current: 38.1 A | Mass: 7.3 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-350
LM-H3S20-288-BSS0LM-H3S20-288-BSS0, linear servo motor secondary (magnet), 288mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 288 mm | Mass: 0.7 kg | Pairs With Primary: P2A (BSS0) | Protection: Open IP00
LM-H3S20-384-BSS0LM-H3S20-384-BSS0, linear servo motor secondary (magnet), 384mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 384 mm | Mass: 0.9 kg | Pairs With Primary: P2A (BSS0) | Protection: Open IP00
LM-H3S20-480-BSS0LM-H3S20-480-BSS0, linear servo motor secondary (magnet), 480mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 480 mm | Mass: 1.1 kg | Pairs With Primary: P2A (BSS0) | Protection: Open IP00
LM-H3S20-768-BSS0LM-H3S20-768-BSS0, linear servo motor secondary (magnet), 768mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 768 mm | Mass: 1.8 kg | Pairs With Primary: P2A (BSS0) | Protection: Open IP00
LM-H3S30-288-CSS0LM-H3S30-288-CSS0, linear servo motor secondary (magnet), 288mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 288 mm | Mass: 1.0 kg | Pairs With Primary: P3 (CSS0) | Protection: Open IP00
LM-H3S30-384-CSS0LM-H3S30-384-CSS0, linear servo motor secondary (magnet), 384mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 384 mm | Mass: 1.4 kg | Pairs With Primary: P3 (CSS0) | Protection: Open IP00
LM-H3S30-480-CSS0LM-H3S30-480-CSS0, linear servo motor secondary (magnet), 480mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 480 mm | Mass: 1.7 kg | Pairs With Primary: P3 (CSS0) | Protection: Open IP00
LM-H3S30-768-CSS0LM-H3S30-768-CSS0, linear servo motor secondary (magnet), 768mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 768 mm | Mass: 2.7 kg | Pairs With Primary: P3 (CSS0) | Protection: Open IP00
LM-H3S70-288-ASS0LM-H3S70-288-ASS0, linear servo motor secondary (magnet), 288mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 288 mm | Mass: 2.8 kg | Pairs With Primary: P7 (ASS0) | Protection: Open IP00
LM-H3S70-384-ASS0LM-H3S70-384-ASS0, linear servo motor secondary (magnet), 384mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 384 mm | Mass: 3.7 kg | Pairs With Primary: P7 (ASS0) | Protection: Open IP00
LM-H3S70-480-ASS0LM-H3S70-480-ASS0, linear servo motor secondary (magnet), 480mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 480 mm | Mass: 4.7 kg | Pairs With Primary: P7 (ASS0) | Protection: Open IP00
LM-H3S70-768-ASS0LM-H3S70-768-ASS0, linear servo motor secondary (magnet), 768mm, LM-H3 (High Thrust, Cored) | Part Type: Secondary (magnet) | Series: LM-H3 | Length: 768 mm | Mass: 7.4 kg | Pairs With Primary: P7 (ASS0) | Protection: Open IP00
