• Mitsubishi Electric MELSERVO-J4 LM-K2 (Dual-Sided, Zero Attraction) Linear Servo Motor
1 1

Mitsubishi Electric MELSERVO-J4 LM-K2 (Dual-Sided, Zero Attraction) Linear Servo Motor

Mitsubishi Electric MELSERVO-J4 LM-K2 (Dual-Sided, Zero Attraction) Linear Servo Motor

Mitsubishi MELSERVO-J4 LM-K2 (Dual-Sided, Zero Attraction) linear servo motor, dual-sided structure with zero net magnetic attraction.

Key features

  • Direct-drive linear motion, max speed up to 3.0 m/s, IP00, MR-J4 servo amplifier compatible
  • System = primary (coil) + secondary (magnet) parts

Specifications

Protection Open IP00
LM-K2P1A-01M-2SS1 LM-K2P1A-01M-2SS1, linear servo motor primary (coil), LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Primary (coil) | Type: Dual-sided, natural cooling | Continuous Thrust: 120 N | Max Thrust: 300 N | Max Speed: 2.0 m/s | Magnetic Attraction: 0 N (net, dual-sided); 800 N single-side | Rated Current: 2.3 A | Max Current: 7.6 A | Mass: 2.5 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-40 | Note: Requires minimum 2 secondary (magnet) parts of same model
LM-K2P1C-03M-2SS1 LM-K2P1C-03M-2SS1, linear servo motor primary (coil), LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Primary (coil) | Type: Dual-sided, natural cooling | Continuous Thrust: 360 N | Max Thrust: 900 N | Max Speed: 2.0 m/s | Magnetic Attraction: 0 N (net, dual-sided); 2400 N single-side | Rated Current: 6.8 A | Max Current: 23 A | Mass: 6.5 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-200 | Note: Requires minimum 2 secondary (magnet) parts of same model
LM-K2P2A-02M-1SS1 LM-K2P2A-02M-1SS1, linear servo motor primary (coil), LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Primary (coil) | Type: Dual-sided, natural cooling | Continuous Thrust: 240 N | Max Thrust: 600 N | Max Speed: 2.0 m/s | Magnetic Attraction: 0 N (net, dual-sided); 1100 N single-side | Rated Current: 3.7 A | Max Current: 13 A | Mass: 4.0 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-70 | Note: Requires minimum 2 secondary (magnet) parts of same model
LM-K2P2C-07M-1SS1 LM-K2P2C-07M-1SS1, linear servo motor primary (coil), LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Primary (coil) | Type: Dual-sided, natural cooling | Continuous Thrust: 720 N | Max Thrust: 1800 N | Max Speed: 2.0 m/s | Magnetic Attraction: 0 N (net, dual-sided); 3200 N single-side | Rated Current: 12 A | Max Current: 39 A | Mass: 10 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-350 | Note: Requires minimum 2 secondary (magnet) parts of same model
LM-K2P2E-12M-1SS1 LM-K2P2E-12M-1SS1, linear servo motor primary (coil), LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Primary (coil) | Type: Dual-sided, natural cooling | Continuous Thrust: 1200 N | Max Thrust: 3000 N | Max Speed: 2.0 m/s | Magnetic Attraction: 0 N (net, dual-sided); 5300 N single-side | Rated Current: 19 A | Max Current: 65 A | Mass: 16 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-500 | Note: Requires minimum 2 secondary (magnet) parts of same model
LM-K2P3C-14M-1SS1 LM-K2P3C-14M-1SS1, linear servo motor primary (coil), LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Primary (coil) | Type: Dual-sided, natural cooling | Continuous Thrust: 1440 N | Max Thrust: 3600 N | Max Speed: 2.0 m/s | Magnetic Attraction: 0 N (net, dual-sided); 6400 N single-side | Rated Current: 15 A | Max Current: 47 A | Mass: 18 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-350 | Note: Requires minimum 2 secondary (magnet) parts of same model
LM-K2P3E-24M-1SS1 LM-K2P3E-24M-1SS1, linear servo motor primary (coil), LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Primary (coil) | Type: Dual-sided, natural cooling | Continuous Thrust: 2400 N | Max Thrust: 6000 N | Max Speed: 2.0 m/s | Magnetic Attraction: 0 N (net, dual-sided); 10700 N single-side | Rated Current: 25 A | Max Current: 79 A | Mass: 27 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-500 | Note: Requires minimum 2 secondary (magnet) parts of same model
LM-K2S10-288-2SS1 LM-K2S10-288-2SS1, linear servo motor secondary (magnet), 288mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 288 mm | Mass: 1.5 kg | Pairs With Primary: P1 (2SS1) | Protection: Open IP00
LM-K2S10-384-2SS1 LM-K2S10-384-2SS1, linear servo motor secondary (magnet), 384mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 384 mm | Mass: 2.0 kg | Pairs With Primary: P1 (2SS1) | Protection: Open IP00
LM-K2S10-480-2SS1 LM-K2S10-480-2SS1, linear servo motor secondary (magnet), 480mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 480 mm | Mass: 2.5 kg | Pairs With Primary: P1 (2SS1) | Protection: Open IP00
LM-K2S10-768-2SS1 LM-K2S10-768-2SS1, linear servo motor secondary (magnet), 768mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 768 mm | Mass: 3.9 kg | Pairs With Primary: P1 (2SS1) | Protection: Open IP00
LM-K2S20-288-1SS1 LM-K2S20-288-1SS1, linear servo motor secondary (magnet), 288mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 288 mm | Mass: 1.9 kg | Pairs With Primary: P2 (1SS1) | Protection: Open IP00
LM-K2S20-384-1SS1 LM-K2S20-384-1SS1, linear servo motor secondary (magnet), 384mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 384 mm | Mass: 2.5 kg | Pairs With Primary: P2 (1SS1) | Protection: Open IP00
LM-K2S20-480-1SS1 LM-K2S20-480-1SS1, linear servo motor secondary (magnet), 480mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 480 mm | Mass: 3.2 kg | Pairs With Primary: P2 (1SS1) | Protection: Open IP00
LM-K2S20-768-1SS1 LM-K2S20-768-1SS1, linear servo motor secondary (magnet), 768mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 768 mm | Mass: 5.0 kg | Pairs With Primary: P2 (1SS1) | Protection: Open IP00
LM-K2S30-288-1SS1 LM-K2S30-288-1SS1, linear servo motor secondary (magnet), 288mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 288 mm | Mass: 5.5 kg | Pairs With Primary: P3 (1SS1) | Protection: Open IP00
LM-K2S30-384-1SS1 LM-K2S30-384-1SS1, linear servo motor secondary (magnet), 384mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 384 mm | Mass: 7.3 kg | Pairs With Primary: P3 (1SS1) | Protection: Open IP00
LM-K2S30-480-1SS1 LM-K2S30-480-1SS1, linear servo motor secondary (magnet), 480mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 480 mm | Mass: 9.2 kg | Pairs With Primary: P3 (1SS1) | Protection: Open IP00
LM-K2S30-768-1SS1 LM-K2S30-768-1SS1, linear servo motor secondary (magnet), 768mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 768 mm | Mass: 14.6 kg | Pairs With Primary: P3 (1SS1) | Protection: Open IP00
Linear Servo MotorsMitsubishi Electric
19 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric MELSERVO-J4 LM-K2 (Dual-Sided, Zero Attraction) Linear Servo Motor

Brand Mitsubishi Electric·Linear Servo Motors

Available part numbers (19)

LM-K2P1A-01M-2SS1, LM-K2P1C-03M-2SS1, LM-K2P2A-02M-1SS1, LM-K2P2C-07M-1SS1, LM-K2P2E-12M-1SS1, LM-K2P3C-14M-1SS1, LM-K2P3E-24M-1SS1, LM-K2S10-288-2SS1, LM-K2S10-384-2SS1, LM-K2S10-480-2SS1 + 9 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
LM-K2P1A-01M-2SS1LM-K2P1A-01M-2SS1, linear servo motor primary (coil), LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Primary (coil) | Type: Dual-sided, natural cooling | Continuous Thrust: 120 N | Max Thrust: 300 N | Max Speed: 2.0 m/s | Magnetic Attraction: 0 N (net, dual-sided); 800 N single-side | Rated Current: 2.3 A | Max Current: 7.6 A | Mass: 2.5 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-40 | Note: Requires minimum 2 secondary (magnet) parts of same model
LM-K2P1C-03M-2SS1LM-K2P1C-03M-2SS1, linear servo motor primary (coil), LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Primary (coil) | Type: Dual-sided, natural cooling | Continuous Thrust: 360 N | Max Thrust: 900 N | Max Speed: 2.0 m/s | Magnetic Attraction: 0 N (net, dual-sided); 2400 N single-side | Rated Current: 6.8 A | Max Current: 23 A | Mass: 6.5 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-200 | Note: Requires minimum 2 secondary (magnet) parts of same model
LM-K2P2A-02M-1SS1LM-K2P2A-02M-1SS1, linear servo motor primary (coil), LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Primary (coil) | Type: Dual-sided, natural cooling | Continuous Thrust: 240 N | Max Thrust: 600 N | Max Speed: 2.0 m/s | Magnetic Attraction: 0 N (net, dual-sided); 1100 N single-side | Rated Current: 3.7 A | Max Current: 13 A | Mass: 4.0 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-70 | Note: Requires minimum 2 secondary (magnet) parts of same model
LM-K2P2C-07M-1SS1LM-K2P2C-07M-1SS1, linear servo motor primary (coil), LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Primary (coil) | Type: Dual-sided, natural cooling | Continuous Thrust: 720 N | Max Thrust: 1800 N | Max Speed: 2.0 m/s | Magnetic Attraction: 0 N (net, dual-sided); 3200 N single-side | Rated Current: 12 A | Max Current: 39 A | Mass: 10 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-350 | Note: Requires minimum 2 secondary (magnet) parts of same model
LM-K2P2E-12M-1SS1LM-K2P2E-12M-1SS1, linear servo motor primary (coil), LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Primary (coil) | Type: Dual-sided, natural cooling | Continuous Thrust: 1200 N | Max Thrust: 3000 N | Max Speed: 2.0 m/s | Magnetic Attraction: 0 N (net, dual-sided); 5300 N single-side | Rated Current: 19 A | Max Current: 65 A | Mass: 16 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-500 | Note: Requires minimum 2 secondary (magnet) parts of same model
LM-K2P3C-14M-1SS1LM-K2P3C-14M-1SS1, linear servo motor primary (coil), LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Primary (coil) | Type: Dual-sided, natural cooling | Continuous Thrust: 1440 N | Max Thrust: 3600 N | Max Speed: 2.0 m/s | Magnetic Attraction: 0 N (net, dual-sided); 6400 N single-side | Rated Current: 15 A | Max Current: 47 A | Mass: 18 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-350 | Note: Requires minimum 2 secondary (magnet) parts of same model
LM-K2P3E-24M-1SS1LM-K2P3E-24M-1SS1, linear servo motor primary (coil), LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Primary (coil) | Type: Dual-sided, natural cooling | Continuous Thrust: 2400 N | Max Thrust: 6000 N | Max Speed: 2.0 m/s | Magnetic Attraction: 0 N (net, dual-sided); 10700 N single-side | Rated Current: 25 A | Max Current: 79 A | Mass: 27 kg | Protection: Open IP00 | Encoder: select linear encoder separately (refer to linear encoder list) | Compatible Amplifier: MR-J4-500 | Note: Requires minimum 2 secondary (magnet) parts of same model
LM-K2S10-288-2SS1LM-K2S10-288-2SS1, linear servo motor secondary (magnet), 288mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 288 mm | Mass: 1.5 kg | Pairs With Primary: P1 (2SS1) | Protection: Open IP00
LM-K2S10-384-2SS1LM-K2S10-384-2SS1, linear servo motor secondary (magnet), 384mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 384 mm | Mass: 2.0 kg | Pairs With Primary: P1 (2SS1) | Protection: Open IP00
LM-K2S10-480-2SS1LM-K2S10-480-2SS1, linear servo motor secondary (magnet), 480mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 480 mm | Mass: 2.5 kg | Pairs With Primary: P1 (2SS1) | Protection: Open IP00
LM-K2S10-768-2SS1LM-K2S10-768-2SS1, linear servo motor secondary (magnet), 768mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 768 mm | Mass: 3.9 kg | Pairs With Primary: P1 (2SS1) | Protection: Open IP00
LM-K2S20-288-1SS1LM-K2S20-288-1SS1, linear servo motor secondary (magnet), 288mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 288 mm | Mass: 1.9 kg | Pairs With Primary: P2 (1SS1) | Protection: Open IP00
LM-K2S20-384-1SS1LM-K2S20-384-1SS1, linear servo motor secondary (magnet), 384mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 384 mm | Mass: 2.5 kg | Pairs With Primary: P2 (1SS1) | Protection: Open IP00
LM-K2S20-480-1SS1LM-K2S20-480-1SS1, linear servo motor secondary (magnet), 480mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 480 mm | Mass: 3.2 kg | Pairs With Primary: P2 (1SS1) | Protection: Open IP00
LM-K2S20-768-1SS1LM-K2S20-768-1SS1, linear servo motor secondary (magnet), 768mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 768 mm | Mass: 5.0 kg | Pairs With Primary: P2 (1SS1) | Protection: Open IP00
LM-K2S30-288-1SS1LM-K2S30-288-1SS1, linear servo motor secondary (magnet), 288mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 288 mm | Mass: 5.5 kg | Pairs With Primary: P3 (1SS1) | Protection: Open IP00
LM-K2S30-384-1SS1LM-K2S30-384-1SS1, linear servo motor secondary (magnet), 384mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 384 mm | Mass: 7.3 kg | Pairs With Primary: P3 (1SS1) | Protection: Open IP00
LM-K2S30-480-1SS1LM-K2S30-480-1SS1, linear servo motor secondary (magnet), 480mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 480 mm | Mass: 9.2 kg | Pairs With Primary: P3 (1SS1) | Protection: Open IP00
LM-K2S30-768-1SS1LM-K2S30-768-1SS1, linear servo motor secondary (magnet), 768mm, LM-K2 (Dual-Sided, Zero Attraction) | Part Type: Secondary (magnet) | Series: LM-K2 | Length: 768 mm | Mass: 14.6 kg | Pairs With Primary: P3 (1SS1) | Protection: Open IP00
