Mitsubishi Electric MS-T/N series N180-frame reversing enclosed-type magnetic starter MS-2xN180KP with TH-N220RHKP 3-element (2E) thermal overload relay providing combined overload and open-phase (single-phasing) protection.

Key features

  • AC-operated, rated 45kW / 180A (AC-3) at 200-220V and 90kW / 180A at 380-440V, Ith 260A
  • Heater designations 82A to 150A (4 steps)
  • Compliant with JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
  • Mechanical interlock fitted as standard for forward/reverse switching
  • Auxiliary contact option units cannot be added to enclosed types

Specifications

Frame N180
Type Reversing Magnetic Starter (Enclosed Type)
Poles 3
Operation AC operated
Thermal Relay TH-N220RHKP (3-element 2E, manual reset)
Protection Overload + Open-phase
AC-3 Capacity 45kW@200-220V / 90kW@380-440V / 110kW@500-550V
AC-3 Current 180A@200-220V / 180A@380-440V / 180A@500-550V
AC-1 Current 260A@200-220V / 260A@380-440V
Thermal Current Ith 260A
Aux Contact 3a3b x2
Interlock Mechanical, built-in
MS-2xN180KP 82A AC48V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 82A heater, AC48V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 82A (adjustable 65-100A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 82A AC100V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 82A heater, AC100V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 82A (adjustable 65-100A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 82A AC200V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 82A heater, AC200V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 82A (adjustable 65-100A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 82A AC300V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 82A heater, AC300V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 82A (adjustable 65-100A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 82A AC400V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 82A heater, AC400V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 82A (adjustable 65-100A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 82A AC500V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 82A heater, AC500V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 82A (adjustable 65-100A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 105A AC48V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 105A heater, AC48V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 105A AC100V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 105A heater, AC100V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 105A AC200V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 105A heater, AC200V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 105A AC300V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 105A heater, AC300V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 105A AC400V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 105A heater, AC400V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 105A AC500V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 105A heater, AC500V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 125A AC48V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 125A heater, AC48V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 125A AC100V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 125A heater, AC100V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 125A AC200V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 125A heater, AC200V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 125A AC300V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 125A heater, AC300V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 125A AC400V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 125A heater, AC400V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 125A AC500V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 125A heater, AC500V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 150A AC48V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 150A heater, AC48V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 150A AC100V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 150A heater, AC100V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 150A AC200V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 150A heater, AC200V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 150A AC300V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 150A heater, AC300V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 150A AC400V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 150A heater, AC400V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MS-2xN180KP 150A AC500V MS-2xN180KP reversing starter with 2E thermal, N180 frame, 150A heater, AC500V coil | Frame: N180 | Type: Reversing Magnetic Starter (Enclosed Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-N220RHKP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 45kW@200-220V / 90kW@380-440V / 110kW@500-550V | AC-3 Current: 180A@200-220V / 180A@380-440V / 180A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
Magnetic StartersMitsubishi Electric
24 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric MS-T/N Series MS-2xN180KP Enclosed Reversing Magnetic Starter (180A AC-3, N180 Frame, TH-N220RHKP 3-Element Thermal)

Brand Mitsubishi Electric·Magnetic Starters

Available part numbers (24)

MS-2xN180KP 82A AC48V, MS-2xN180KP 82A AC100V, MS-2xN180KP 82A AC200V, MS-2xN180KP 82A AC300V, MS-2xN180KP 82A AC400V, MS-2xN180KP 82A AC500V, MS-2xN180KP 105A AC48V, MS-2xN180KP 105A AC100V, MS-2xN180KP 105A AC200V, MS-2xN180KP 105A AC300V + 14 more — see full table ↓
