Mitsubishi Electric MS-T/N Series MSO-2xT12 Reversing Magnetic Starter (13A AC-3, T12 Frame, TH-T18 Thermal)

Mitsubishi Electric MS-T/N Series MSO-2xT12 Reversing Magnetic Starter (13A AC-3, T12 Frame, TH-T18 Thermal)

Mitsubishi Electric MS-T/N series T12-frame reversing open-type magnetic starter MSO-2xT12: AC-operated contactor combined with TH-T18 2-element thermal overload relay (manual reset standard).

Key features

  • Rated 2.7kW / 13A (AC-3) at 200-220V and 4kW / 9A at 380-440V, Ith 20A
  • Heater designations 0.12A to 11A (16 steps) for overload and open-phase protection matching
  • Compliant with JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4; twin auxiliary contacts for high contact reliability
  • Mechanical interlock fitted as standard for forward/reverse motor switching

Specifications

Frame T12
Type Reversing Magnetic Starter (Open Type)
Poles 3
Operation AC operated
Thermal Relay TH-T18 (2-element, manual reset)
AC-3 Capacity 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V
AC-3 Current 13A@200-220V / 9A@380-440V / 9A@500-550V
AC-1 Current 20A@200-220V / 13A@380-440V
Thermal Current Ith 20A
Aux Contact 1a1b x2 + 2b (interlock unit b-contact)
Interlock Mechanical, built-in
Standards JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.12A AC24V MSO-2xT12 reversing starter, T12 frame, 0.12A heater, AC24V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.12A (adjustable 0.1-0.16A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.12A AC48V MSO-2xT12 reversing starter, T12 frame, 0.12A heater, AC48V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.12A (adjustable 0.1-0.16A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.12A AC100V MSO-2xT12 reversing starter, T12 frame, 0.12A heater, AC100V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.12A (adjustable 0.1-0.16A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.12A AC200V MSO-2xT12 reversing starter, T12 frame, 0.12A heater, AC200V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.12A (adjustable 0.1-0.16A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.12A AC300V MSO-2xT12 reversing starter, T12 frame, 0.12A heater, AC300V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-300V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.12A (adjustable 0.1-0.16A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.12A AC400V MSO-2xT12 reversing starter, T12 frame, 0.12A heater, AC400V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.12A (adjustable 0.1-0.16A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.12A AC500V MSO-2xT12 reversing starter, T12 frame, 0.12A heater, AC500V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.12A (adjustable 0.1-0.16A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.17A AC24V MSO-2xT12 reversing starter, T12 frame, 0.17A heater, AC24V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.17A (adjustable 0.14-0.22A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.17A AC48V MSO-2xT12 reversing starter, T12 frame, 0.17A heater, AC48V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.17A (adjustable 0.14-0.22A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.17A AC100V MSO-2xT12 reversing starter, T12 frame, 0.17A heater, AC100V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.17A (adjustable 0.14-0.22A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.17A AC200V MSO-2xT12 reversing starter, T12 frame, 0.17A heater, AC200V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.17A (adjustable 0.14-0.22A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.17A AC300V MSO-2xT12 reversing starter, T12 frame, 0.17A heater, AC300V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-300V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.17A (adjustable 0.14-0.22A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.17A AC400V MSO-2xT12 reversing starter, T12 frame, 0.17A heater, AC400V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.17A (adjustable 0.14-0.22A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.17A AC500V MSO-2xT12 reversing starter, T12 frame, 0.17A heater, AC500V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.17A (adjustable 0.14-0.22A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.24A AC24V MSO-2xT12 reversing starter, T12 frame, 0.24A heater, AC24V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.24A (adjustable 0.2-0.32A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.24A AC48V MSO-2xT12 reversing starter, T12 frame, 0.24A heater, AC48V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.24A (adjustable 0.2-0.32A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.24A AC100V MSO-2xT12 reversing starter, T12 frame, 0.24A heater, AC100V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.24A (adjustable 0.2-0.32A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.24A AC200V MSO-2xT12 reversing starter, T12 frame, 0.24A heater, AC200V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.24A (adjustable 0.2-0.32A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.24A AC300V MSO-2xT12 reversing starter, T12 frame, 0.24A heater, AC300V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-300V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.24A (adjustable 0.2-0.32A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.24A AC400V MSO-2xT12 reversing starter, T12 frame, 0.24A heater, AC400V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.24A (adjustable 0.2-0.32A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.24A AC500V MSO-2xT12 reversing starter, T12 frame, 0.24A heater, AC500V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.24A (adjustable 0.2-0.32A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.35A AC24V MSO-2xT12 reversing starter, T12 frame, 0.35A heater, AC24V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.35A (adjustable 0.28-0.42A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.35A AC48V MSO-2xT12 reversing starter, T12 frame, 0.35A heater, AC48V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.35A (adjustable 0.28-0.42A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.35A AC100V MSO-2xT12 reversing starter, T12 frame, 0.35A heater, AC100V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.35A (adjustable 0.28-0.42A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.35A AC200V MSO-2xT12 reversing starter, T12 frame, 0.35A heater, AC200V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.35A (adjustable 0.28-0.42A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.35A AC300V MSO-2xT12 reversing starter, T12 frame, 0.35A heater, AC300V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-300V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.35A (adjustable 0.28-0.42A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.35A AC400V MSO-2xT12 reversing starter, T12 frame, 0.35A heater, AC400V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.35A (adjustable 0.28-0.42A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.35A AC500V MSO-2xT12 reversing starter, T12 frame, 0.35A heater, AC500V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.35A (adjustable 0.28-0.42A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.5A AC24V MSO-2xT12 reversing starter, T12 frame, 0.5A heater, AC24V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.5A (adjustable 0.4-0.6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.5A AC48V MSO-2xT12 reversing starter, T12 frame, 0.5A heater, AC48V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.5A (adjustable 0.4-0.6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.5A AC100V MSO-2xT12 reversing starter, T12 frame, 0.5A heater, AC100V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.5A (adjustable 0.4-0.6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.5A AC200V MSO-2xT12 reversing starter, T12 frame, 0.5A heater, AC200V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.5A (adjustable 0.4-0.6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.5A AC300V MSO-2xT12 reversing starter, T12 frame, 0.5A heater, AC300V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-300V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.5A (adjustable 0.4-0.6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.5A AC400V MSO-2xT12 reversing starter, T12 frame, 0.5A heater, AC400V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.5A (adjustable 0.4-0.6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.5A AC500V MSO-2xT12 reversing starter, T12 frame, 0.5A heater, AC500V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.5A (adjustable 0.4-0.6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.7A AC24V MSO-2xT12 reversing starter, T12 frame, 0.7A heater, AC24V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.7A (adjustable 0.55-0.85A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.7A AC48V MSO-2xT12 reversing starter, T12 frame, 0.7A heater, AC48V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.7A (adjustable 0.55-0.85A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.7A AC100V MSO-2xT12 reversing starter, T12 frame, 0.7A heater, AC100V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.7A (adjustable 0.55-0.85A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.7A AC200V MSO-2xT12 reversing starter, T12 frame, 0.7A heater, AC200V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.7A (adjustable 0.55-0.85A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.7A AC300V MSO-2xT12 reversing starter, T12 frame, 0.7A heater, AC300V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-300V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.7A (adjustable 0.55-0.85A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.7A AC400V MSO-2xT12 reversing starter, T12 frame, 0.7A heater, AC400V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.7A (adjustable 0.55-0.85A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.7A AC500V MSO-2xT12 reversing starter, T12 frame, 0.7A heater, AC500V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.7A (adjustable 0.55-0.85A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.9A AC24V MSO-2xT12 reversing starter, T12 frame, 0.9A heater, AC24V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.9A (adjustable 0.7-1.1A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.9A AC48V MSO-2xT12 reversing starter, T12 frame, 0.9A heater, AC48V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.9A (adjustable 0.7-1.1A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.9A AC100V MSO-2xT12 reversing starter, T12 frame, 0.9A heater, AC100V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.9A (adjustable 0.7-1.1A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.9A AC200V MSO-2xT12 reversing starter, T12 frame, 0.9A heater, AC200V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.9A (adjustable 0.7-1.1A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.9A AC300V MSO-2xT12 reversing starter, T12 frame, 0.9A heater, AC300V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-300V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.9A (adjustable 0.7-1.1A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.9A AC400V MSO-2xT12 reversing starter, T12 frame, 0.9A heater, AC400V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.9A (adjustable 0.7-1.1A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 0.9A AC500V MSO-2xT12 reversing starter, T12 frame, 0.9A heater, AC500V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 0.9A (adjustable 0.7-1.1A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 1.3A AC24V MSO-2xT12 reversing starter, T12 frame, 1.3A heater, AC24V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 1.3A (adjustable 1-1.6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 1.3A AC48V MSO-2xT12 reversing starter, T12 frame, 1.3A heater, AC48V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 1.3A (adjustable 1-1.6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 1.3A AC100V MSO-2xT12 reversing starter, T12 frame, 1.3A heater, AC100V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 1.3A (adjustable 1-1.6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 1.3A AC200V MSO-2xT12 reversing starter, T12 frame, 1.3A heater, AC200V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 1.3A (adjustable 1-1.6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 1.3A AC300V MSO-2xT12 reversing starter, T12 frame, 1.3A heater, AC300V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-300V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 1.3A (adjustable 1-1.6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 1.3A AC400V MSO-2xT12 reversing starter, T12 frame, 1.3A heater, AC400V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 1.3A (adjustable 1-1.6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 1.3A AC500V MSO-2xT12 reversing starter, T12 frame, 1.3A heater, AC500V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 1.3A (adjustable 1-1.6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 1.7A AC24V MSO-2xT12 reversing starter, T12 frame, 1.7A heater, AC24V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 1.7A (adjustable 1.4-2A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 1.7A AC48V MSO-2xT12 reversing starter, T12 frame, 1.7A heater, AC48V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 1.7A (adjustable 1.4-2A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 1.7A AC100V MSO-2xT12 reversing starter, T12 frame, 1.7A heater, AC100V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 1.7A (adjustable 1.4-2A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 1.7A AC200V MSO-2xT12 reversing starter, T12 frame, 1.7A heater, AC200V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 1.7A (adjustable 1.4-2A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 1.7A AC300V MSO-2xT12 reversing starter, T12 frame, 1.7A heater, AC300V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-300V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 1.7A (adjustable 1.4-2A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 1.7A AC400V MSO-2xT12 reversing starter, T12 frame, 1.7A heater, AC400V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 1.7A (adjustable 1.4-2A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 1.7A AC500V MSO-2xT12 reversing starter, T12 frame, 1.7A heater, AC500V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 1.7A (adjustable 1.4-2A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 2.1A AC24V MSO-2xT12 reversing starter, T12 frame, 2.1A heater, AC24V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 2.1A (adjustable 1.7-2.5A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 2.1A AC48V MSO-2xT12 reversing starter, T12 frame, 2.1A heater, AC48V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 2.1A (adjustable 1.7-2.5A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 2.1A AC100V MSO-2xT12 reversing starter, T12 frame, 2.1A heater, AC100V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 2.1A (adjustable 1.7-2.5A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 2.1A AC200V MSO-2xT12 reversing starter, T12 frame, 2.1A heater, AC200V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 2.1A (adjustable 1.7-2.5A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 2.1A AC300V MSO-2xT12 reversing starter, T12 frame, 2.1A heater, AC300V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-300V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 2.1A (adjustable 1.7-2.5A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 2.1A AC400V MSO-2xT12 reversing starter, T12 frame, 2.1A heater, AC400V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 2.1A (adjustable 1.7-2.5A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 2.1A AC500V MSO-2xT12 reversing starter, T12 frame, 2.1A heater, AC500V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 2.1A (adjustable 1.7-2.5A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 2.5A AC24V MSO-2xT12 reversing starter, T12 frame, 2.5A heater, AC24V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 2.5A (adjustable 2-3A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 2.5A AC48V MSO-2xT12 reversing starter, T12 frame, 2.5A heater, AC48V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 2.5A (adjustable 2-3A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 2.5A AC100V MSO-2xT12 reversing starter, T12 frame, 2.5A heater, AC100V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 2.5A (adjustable 2-3A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 2.5A AC200V MSO-2xT12 reversing starter, T12 frame, 2.5A heater, AC200V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 2.5A (adjustable 2-3A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 2.5A AC300V MSO-2xT12 reversing starter, T12 frame, 2.5A heater, AC300V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-300V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 2.5A (adjustable 2-3A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 2.5A AC400V MSO-2xT12 reversing starter, T12 frame, 2.5A heater, AC400V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 2.5A (adjustable 2-3A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 2.5A AC500V MSO-2xT12 reversing starter, T12 frame, 2.5A heater, AC500V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 2.5A (adjustable 2-3A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 3.6A AC24V MSO-2xT12 reversing starter, T12 frame, 3.6A heater, AC24V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 3.6A (adjustable 2.8-4.4A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 3.6A AC48V MSO-2xT12 reversing starter, T12 frame, 3.6A heater, AC48V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 3.6A (adjustable 2.8-4.4A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 3.6A AC100V MSO-2xT12 reversing starter, T12 frame, 3.6A heater, AC100V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 3.6A (adjustable 2.8-4.4A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 3.6A AC200V MSO-2xT12 reversing starter, T12 frame, 3.6A heater, AC200V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 3.6A (adjustable 2.8-4.4A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 3.6A AC300V MSO-2xT12 reversing starter, T12 frame, 3.6A heater, AC300V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-300V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 3.6A (adjustable 2.8-4.4A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 3.6A AC400V MSO-2xT12 reversing starter, T12 frame, 3.6A heater, AC400V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 3.6A (adjustable 2.8-4.4A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 3.6A AC500V MSO-2xT12 reversing starter, T12 frame, 3.6A heater, AC500V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 3.6A (adjustable 2.8-4.4A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 5A AC24V MSO-2xT12 reversing starter, T12 frame, 5A heater, AC24V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 5A (adjustable 4-6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 5A AC48V MSO-2xT12 reversing starter, T12 frame, 5A heater, AC48V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 5A (adjustable 4-6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 5A AC100V MSO-2xT12 reversing starter, T12 frame, 5A heater, AC100V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 5A (adjustable 4-6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 5A AC200V MSO-2xT12 reversing starter, T12 frame, 5A heater, AC200V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 5A (adjustable 4-6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 5A AC300V MSO-2xT12 reversing starter, T12 frame, 5A heater, AC300V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-300V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 5A (adjustable 4-6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 5A AC400V MSO-2xT12 reversing starter, T12 frame, 5A heater, AC400V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 5A (adjustable 4-6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 5A AC500V MSO-2xT12 reversing starter, T12 frame, 5A heater, AC500V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 5A (adjustable 4-6A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 6.6A AC24V MSO-2xT12 reversing starter, T12 frame, 6.6A heater, AC24V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 6.6A (adjustable 5.2-8A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 6.6A AC48V MSO-2xT12 reversing starter, T12 frame, 6.6A heater, AC48V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 6.6A (adjustable 5.2-8A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 6.6A AC100V MSO-2xT12 reversing starter, T12 frame, 6.6A heater, AC100V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 6.6A (adjustable 5.2-8A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 6.6A AC200V MSO-2xT12 reversing starter, T12 frame, 6.6A heater, AC200V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 6.6A (adjustable 5.2-8A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 6.6A AC300V MSO-2xT12 reversing starter, T12 frame, 6.6A heater, AC300V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-300V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 6.6A (adjustable 5.2-8A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 6.6A AC400V MSO-2xT12 reversing starter, T12 frame, 6.6A heater, AC400V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 6.6A (adjustable 5.2-8A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 6.6A AC500V MSO-2xT12 reversing starter, T12 frame, 6.6A heater, AC500V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 6.6A (adjustable 5.2-8A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 9A AC24V MSO-2xT12 reversing starter, T12 frame, 9A heater, AC24V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 9A (adjustable 7-11A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 9A AC48V MSO-2xT12 reversing starter, T12 frame, 9A heater, AC48V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 9A (adjustable 7-11A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 9A AC100V MSO-2xT12 reversing starter, T12 frame, 9A heater, AC100V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 9A (adjustable 7-11A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 9A AC200V MSO-2xT12 reversing starter, T12 frame, 9A heater, AC200V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 9A (adjustable 7-11A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 9A AC300V MSO-2xT12 reversing starter, T12 frame, 9A heater, AC300V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-300V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 9A (adjustable 7-11A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 9A AC400V MSO-2xT12 reversing starter, T12 frame, 9A heater, AC400V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 9A (adjustable 7-11A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 9A AC500V MSO-2xT12 reversing starter, T12 frame, 9A heater, AC500V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 9A (adjustable 7-11A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 11A AC24V MSO-2xT12 reversing starter, T12 frame, 11A heater, AC24V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 11A (adjustable 9-13A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 11A AC48V MSO-2xT12 reversing starter, T12 frame, 11A heater, AC48V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 11A (adjustable 9-13A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 11A AC100V MSO-2xT12 reversing starter, T12 frame, 11A heater, AC100V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 11A (adjustable 9-13A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 11A AC200V MSO-2xT12 reversing starter, T12 frame, 11A heater, AC200V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 11A (adjustable 9-13A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 11A AC300V MSO-2xT12 reversing starter, T12 frame, 11A heater, AC300V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-300V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 11A (adjustable 9-13A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 11A AC400V MSO-2xT12 reversing starter, T12 frame, 11A heater, AC400V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 11A (adjustable 9-13A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT12 11A AC500V MSO-2xT12 reversing starter, T12 frame, 11A heater, AC500V coil | Frame: T12 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T18 (2-element, manual reset) | Heater: 11A (adjustable 9-13A) | AC-3 Capacity: 2.7kW@200-220V / 4kW@380-440V / 5.5kW@500-550V | AC-3 Current: 13A@200-220V / 9A@380-440V / 9A@500-550V | AC-1 Current: 20A@200-220V / 13A@380-440V | Thermal Current Ith: 20A | Aux Contact: 1a1b x2 + 2b (interlock unit b-contact) | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
