Mitsubishi Electric MS-T/N Series MSO-2xT80 Reversing Magnetic Starter (80A AC-3, T80 Frame, TH-T100 Thermal)

Mitsubishi Electric MS-T/N Series MSO-2xT80 Reversing Magnetic Starter (80A AC-3, T80 Frame, TH-T100 Thermal)

Mitsubishi Electric MS-T/N series T80-frame reversing open-type magnetic starter MSO-2xT80: AC-operated contactor combined with TH-T100 2-element thermal overload relay (manual reset standard).

Key features

  • Rated 19kW / 80A (AC-3) at 200-220V and 37kW / 80A at 380-440V, Ith 120A
  • Heater designations 67A to 67A (1 steps) for overload and open-phase protection matching
  • Compliant with JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4; twin auxiliary contacts for high contact reliability
  • Mechanical interlock fitted as standard for forward/reverse motor switching

Specifications

Frame T80
Type Reversing Magnetic Starter (Open Type)
Poles 3
Operation AC operated
Thermal Relay TH-T100 (2-element, manual reset)
Heater 67A (adjustable 54-80A)
AC-3 Capacity 19kW@200-220V / 37kW@380-440V / 45kW@500-550V
AC-3 Current 80A@200-220V / 80A@380-440V / 75A@500-550V
AC-1 Current 120A@200-220V / 120A@380-440V
Thermal Current Ith 120A
Aux Contact 2a2b x2
Interlock Mechanical, built-in
MSO-2xT80 67A AC24V MSO-2xT80 reversing starter, T80 frame, 67A heater, AC24V coil | Frame: T80 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT80 67A AC48V MSO-2xT80 reversing starter, T80 frame, 67A heater, AC48V coil | Frame: T80 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT80 67A AC100V MSO-2xT80 reversing starter, T80 frame, 67A heater, AC100V coil | Frame: T80 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT80 67A AC200V MSO-2xT80 reversing starter, T80 frame, 67A heater, AC200V coil | Frame: T80 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT80 67A AC300V MSO-2xT80 reversing starter, T80 frame, 67A heater, AC300V coil | Frame: T80 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT80 67A AC400V MSO-2xT80 reversing starter, T80 frame, 67A heater, AC400V coil | Frame: T80 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT80 67A AC500V MSO-2xT80 reversing starter, T80 frame, 67A heater, AC500V coil | Frame: T80 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
Magnetic StartersMitsubishi Electric
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric MS-T/N Series MSO-2xT80 Reversing Magnetic Starter (80A AC-3, T80 Frame, TH-T100 Thermal)

Brand Mitsubishi Electric·Magnetic Starters

Available part numbers (7)

MSO-2xT80 67A AC24V, MSO-2xT80 67A AC48V, MSO-2xT80 67A AC100V, MSO-2xT80 67A AC200V, MSO-2xT80 67A AC300V, MSO-2xT80 67A AC400V, MSO-2xT80 67A AC500V

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MSO-2xT80 67A AC24VMSO-2xT80 reversing starter, T80 frame, 67A heater, AC24V coil | Frame: T80 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT80 67A AC48VMSO-2xT80 reversing starter, T80 frame, 67A heater, AC48V coil | Frame: T80 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT80 67A AC100VMSO-2xT80 reversing starter, T80 frame, 67A heater, AC100V coil | Frame: T80 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT80 67A AC200VMSO-2xT80 reversing starter, T80 frame, 67A heater, AC200V coil | Frame: T80 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT80 67A AC300VMSO-2xT80 reversing starter, T80 frame, 67A heater, AC300V coil | Frame: T80 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT80 67A AC400VMSO-2xT80 reversing starter, T80 frame, 67A heater, AC400V coil | Frame: T80 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-2xT80 67A AC500VMSO-2xT80 reversing starter, T80 frame, 67A heater, AC500V coil | Frame: T80 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
