Mitsubishi Electric MS-T/N Series MSO-N400 Magnetic Starter (400A AC-3, N400 Frame, TH-N400RH Thermal)

Mitsubishi Electric MS-T/N Series MSO-N400 Magnetic Starter (400A AC-3, N400 Frame, TH-N400RH Thermal)

Mitsubishi Electric MS-T/N series N400-frame non-reversing open-type magnetic starter MSO-N400: AC-operated contactor combined with TH-N400RH 2-element thermal overload relay (manual reset standard).

Key features

  • Rated 110kW / 400A (AC-3) at 200-220V and 200kW / 400A at 380-440V, Ith 450A
  • Heater designations 105A to 330A (6 steps) for overload and open-phase protection matching
  • Compliant with JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4; twin auxiliary contacts for high contact reliability

Specifications

Frame N400
Type Non-Reversing Magnetic Starter (Open Type)
Poles 3
Operation AC operated
Thermal Relay TH-N400RH (2-element, manual reset)
AC-3 Capacity 110kW@200-220V / 200kW@380-440V / 200kW@500-550V
AC-3 Current 400A@200-220V / 400A@380-440V / 350A@500-550V
AC-1 Current 450A@200-220V / 450A@380-440V
Thermal Current Ith 450A
Aux Contact 2a2b
Standards JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 105A AC48V MSO-N400 non-reversing starter, N400 frame, 105A heater, AC48V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 105A AC100V MSO-N400 non-reversing starter, N400 frame, 105A heater, AC100V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 105A AC200V MSO-N400 non-reversing starter, N400 frame, 105A heater, AC200V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 105A AC300V MSO-N400 non-reversing starter, N400 frame, 105A heater, AC300V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 105A AC400V MSO-N400 non-reversing starter, N400 frame, 105A heater, AC400V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 105A AC500V MSO-N400 non-reversing starter, N400 frame, 105A heater, AC500V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 125A AC48V MSO-N400 non-reversing starter, N400 frame, 125A heater, AC48V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 125A AC100V MSO-N400 non-reversing starter, N400 frame, 125A heater, AC100V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 125A AC200V MSO-N400 non-reversing starter, N400 frame, 125A heater, AC200V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 125A AC300V MSO-N400 non-reversing starter, N400 frame, 125A heater, AC300V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 125A AC400V MSO-N400 non-reversing starter, N400 frame, 125A heater, AC400V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 125A AC500V MSO-N400 non-reversing starter, N400 frame, 125A heater, AC500V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 150A AC48V MSO-N400 non-reversing starter, N400 frame, 150A heater, AC48V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 150A AC100V MSO-N400 non-reversing starter, N400 frame, 150A heater, AC100V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 150A AC200V MSO-N400 non-reversing starter, N400 frame, 150A heater, AC200V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 150A AC300V MSO-N400 non-reversing starter, N400 frame, 150A heater, AC300V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 150A AC400V MSO-N400 non-reversing starter, N400 frame, 150A heater, AC400V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 150A AC500V MSO-N400 non-reversing starter, N400 frame, 150A heater, AC500V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 180A AC48V MSO-N400 non-reversing starter, N400 frame, 180A heater, AC48V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 180A AC100V MSO-N400 non-reversing starter, N400 frame, 180A heater, AC100V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 180A AC200V MSO-N400 non-reversing starter, N400 frame, 180A heater, AC200V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 180A AC300V MSO-N400 non-reversing starter, N400 frame, 180A heater, AC300V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 180A AC400V MSO-N400 non-reversing starter, N400 frame, 180A heater, AC400V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 180A AC500V MSO-N400 non-reversing starter, N400 frame, 180A heater, AC500V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 250A AC48V MSO-N400 non-reversing starter, N400 frame, 250A heater, AC48V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 250A AC100V MSO-N400 non-reversing starter, N400 frame, 250A heater, AC100V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 250A AC200V MSO-N400 non-reversing starter, N400 frame, 250A heater, AC200V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 250A AC300V MSO-N400 non-reversing starter, N400 frame, 250A heater, AC300V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 250A AC400V MSO-N400 non-reversing starter, N400 frame, 250A heater, AC400V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 250A AC500V MSO-N400 non-reversing starter, N400 frame, 250A heater, AC500V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 330A AC48V MSO-N400 non-reversing starter, N400 frame, 330A heater, AC48V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 330A AC100V MSO-N400 non-reversing starter, N400 frame, 330A heater, AC100V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 330A AC200V MSO-N400 non-reversing starter, N400 frame, 330A heater, AC200V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 330A AC300V MSO-N400 non-reversing starter, N400 frame, 330A heater, AC300V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 330A AC400V MSO-N400 non-reversing starter, N400 frame, 330A heater, AC400V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-N400 330A AC500V MSO-N400 non-reversing starter, N400 frame, 330A heater, AC500V coil | Frame: N400 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
Magnetic StartersMitsubishi Electric
36 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric MS-T/N Series MSO-N400 Magnetic Starter (400A AC-3, N400 Frame, TH-N400RH Thermal)

Brand Mitsubishi Electric·Magnetic Starters

Available part numbers (36)

MSO-N400 105A AC48V, MSO-N400 105A AC100V, MSO-N400 105A AC200V, MSO-N400 105A AC300V, MSO-N400 105A AC400V, MSO-N400 105A AC500V, MSO-N400 125A AC48V, MSO-N400 125A AC100V, MSO-N400 125A AC200V, MSO-N400 125A AC300V + 26 more — see full table ↓
