• Mitsubishi Electric MS-T/N Series MSO-T65KP Magnetic Starter (65A AC-3, T65 Frame, TH-T65KP 3-Element Thermal)
1 1

Mitsubishi Electric MS-T/N Series MSO-T65KP Magnetic Starter (65A AC-3, T65 Frame, TH-T65KP 3-Element Thermal)

Mitsubishi Electric MS-T/N Series MSO-T65KP Magnetic Starter (65A AC-3, T65 Frame, TH-T65KP 3-Element Thermal)

Mitsubishi Electric MS-T/N series T65-frame non-reversing open-type magnetic starter MSO-T65KP with TH-T65KP 3-element (2E) thermal overload relay providing combined overload and open-phase (single-phasing) protection.

Key features

  • AC-operated, rated 15kW / 65A (AC-3) at 200-220V and 30kW / 65A at 380-440V, Ith 100A
  • Heater designations 15A to 54A (6 steps)
  • Compliant with JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4

Specifications

Frame T65
Type Non-Reversing Magnetic Starter (Open Type)
Poles 3
Operation AC operated
Thermal Relay TH-T65KP (3-element 2E, manual reset)
Protection Overload + Open-phase
AC-3 Capacity 15kW@200-220V / 30kW@380-440V / 30kW@500-550V
AC-3 Current 65A@200-220V / 65A@380-440V / 45A@500-550V
AC-1 Current 100A@200-220V / 100A@380-440V
Thermal Current Ith 100A
Aux Contact 2a2b
Standards JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 15A AC24V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 15A heater, AC24V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 15A AC48V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 15A heater, AC48V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 15A AC100V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 15A heater, AC100V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 15A AC200V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 15A heater, AC200V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 15A AC300V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 15A heater, AC300V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 15A AC400V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 15A heater, AC400V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 15A AC500V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 15A heater, AC500V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 22A AC24V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 22A heater, AC24V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 22A AC48V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 22A heater, AC48V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 22A AC100V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 22A heater, AC100V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 22A AC200V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 22A heater, AC200V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 22A AC300V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 22A heater, AC300V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 22A AC400V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 22A heater, AC400V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 22A AC500V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 22A heater, AC500V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 29A AC24V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 29A heater, AC24V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 29A AC48V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 29A heater, AC48V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 29A AC100V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 29A heater, AC100V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 29A AC200V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 29A heater, AC200V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 29A AC300V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 29A heater, AC300V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 29A AC400V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 29A heater, AC400V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 29A AC500V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 29A heater, AC500V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 35A AC24V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 35A heater, AC24V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 35A AC48V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 35A heater, AC48V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 35A AC100V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 35A heater, AC100V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 35A AC200V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 35A heater, AC200V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 35A AC300V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 35A heater, AC300V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 35A AC400V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 35A heater, AC400V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 35A AC500V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 35A heater, AC500V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 42A AC24V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 42A heater, AC24V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 42A AC48V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 42A heater, AC48V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 42A AC100V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 42A heater, AC100V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 42A AC200V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 42A heater, AC200V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 42A AC300V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 42A heater, AC300V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 42A AC400V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 42A heater, AC400V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 42A AC500V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 42A heater, AC500V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 54A AC24V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 54A heater, AC24V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 54A AC48V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 54A heater, AC48V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 54A AC100V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 54A heater, AC100V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 54A AC200V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 54A heater, AC200V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 54A AC300V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 54A heater, AC300V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 54A AC400V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 54A heater, AC400V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSO-T65KP 54A AC500V MSO-T65KP non-reversing starter with 2E thermal, T65 frame, 54A heater, AC500V coil | Frame: T65 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | Thermal Relay: TH-T65KP (3-element 2E, manual reset) | Protection: Overload + Open-phase | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
Magnetic StartersMitsubishi Electric
42 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric MS-T/N Series MSO-T65KP Magnetic Starter (65A AC-3, T65 Frame, TH-T65KP 3-Element Thermal)

Brand Mitsubishi Electric·Magnetic Starters

Available part numbers (42)

MSO-T65KP 15A AC24V, MSO-T65KP 15A AC48V, MSO-T65KP 15A AC100V, MSO-T65KP 15A AC200V, MSO-T65KP 15A AC300V, MSO-T65KP 15A AC400V, MSO-T65KP 15A AC500V, MSO-T65KP 22A AC24V, MSO-T65KP 22A AC48V, MSO-T65KP 22A AC100V + 32 more — see full table ↓
