• Mitsubishi Electric MS-T/N Series MSOD-2xN400 Reversing Magnetic Starter (400A AC-3, N400 Frame, TH-N400RH Thermal)
1 1

Mitsubishi Electric MS-T/N Series MSOD-2xN400 Reversing Magnetic Starter (400A AC-3, N400 Frame, TH-N400RH Thermal)

Mitsubishi Electric MS-T/N Series MSOD-2xN400 Reversing Magnetic Starter (400A AC-3, N400 Frame, TH-N400RH Thermal)

Mitsubishi Electric MS-T/N series N400-frame reversing open-type magnetic starter MSOD-2xN400: DC-operated contactor combined with TH-N400RH 2-element thermal overload relay (manual reset standard).

Key features

  • Rated 110kW / 400A (AC-3) at 200-220V and 200kW / 400A at 380-440V, Ith 450A
  • Heater designations 105A to 330A (6 steps) for overload and open-phase protection matching
  • Compliant with JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4; twin auxiliary contacts for high contact reliability
  • Mechanical interlock fitted as standard for forward/reverse motor switching

Specifications

Frame N400
Type Reversing Magnetic Starter (Open Type)
Poles 3
Operation DC operated
Thermal Relay TH-N400RH (2-element, manual reset)
AC-3 Capacity 110kW@200-220V / 200kW@380-440V / 200kW@500-550V
AC-3 Current 400A@200-220V / 400A@380-440V / 350A@500-550V
AC-1 Current 450A@200-220V / 450A@380-440V
Thermal Current Ith 450A
Aux Contact 3a3b x2
Interlock Mechanical, built-in
Standards JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 105A DC12V MSOD-2xN400 reversing starter, N400 frame, 105A heater, DC12V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 105A DC24V MSOD-2xN400 reversing starter, N400 frame, 105A heater, DC24V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 105A DC48V MSOD-2xN400 reversing starter, N400 frame, 105A heater, DC48V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 105A DC100V MSOD-2xN400 reversing starter, N400 frame, 105A heater, DC100V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 105A DC110V MSOD-2xN400 reversing starter, N400 frame, 105A heater, DC110V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 105A DC125V MSOD-2xN400 reversing starter, N400 frame, 105A heater, DC125V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 105A DC200V MSOD-2xN400 reversing starter, N400 frame, 105A heater, DC200V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 105A DC220V MSOD-2xN400 reversing starter, N400 frame, 105A heater, DC220V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 125A DC12V MSOD-2xN400 reversing starter, N400 frame, 125A heater, DC12V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 125A DC24V MSOD-2xN400 reversing starter, N400 frame, 125A heater, DC24V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 125A DC48V MSOD-2xN400 reversing starter, N400 frame, 125A heater, DC48V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 125A DC100V MSOD-2xN400 reversing starter, N400 frame, 125A heater, DC100V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 125A DC110V MSOD-2xN400 reversing starter, N400 frame, 125A heater, DC110V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 125A DC125V MSOD-2xN400 reversing starter, N400 frame, 125A heater, DC125V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 125A DC200V MSOD-2xN400 reversing starter, N400 frame, 125A heater, DC200V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 125A DC220V MSOD-2xN400 reversing starter, N400 frame, 125A heater, DC220V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 150A DC12V MSOD-2xN400 reversing starter, N400 frame, 150A heater, DC12V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 150A DC24V MSOD-2xN400 reversing starter, N400 frame, 150A heater, DC24V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 150A DC48V MSOD-2xN400 reversing starter, N400 frame, 150A heater, DC48V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 150A DC100V MSOD-2xN400 reversing starter, N400 frame, 150A heater, DC100V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 150A DC110V MSOD-2xN400 reversing starter, N400 frame, 150A heater, DC110V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 150A DC125V MSOD-2xN400 reversing starter, N400 frame, 150A heater, DC125V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 150A DC200V MSOD-2xN400 reversing starter, N400 frame, 150A heater, DC200V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 150A DC220V MSOD-2xN400 reversing starter, N400 frame, 150A heater, DC220V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 180A DC12V MSOD-2xN400 reversing starter, N400 frame, 180A heater, DC12V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 180A DC24V MSOD-2xN400 reversing starter, N400 frame, 180A heater, DC24V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 180A DC48V MSOD-2xN400 reversing starter, N400 frame, 180A heater, DC48V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 180A DC100V MSOD-2xN400 reversing starter, N400 frame, 180A heater, DC100V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 180A DC110V MSOD-2xN400 reversing starter, N400 frame, 180A heater, DC110V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 180A DC125V MSOD-2xN400 reversing starter, N400 frame, 180A heater, DC125V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 180A DC200V MSOD-2xN400 reversing starter, N400 frame, 180A heater, DC200V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 180A DC220V MSOD-2xN400 reversing starter, N400 frame, 180A heater, DC220V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 250A DC12V MSOD-2xN400 reversing starter, N400 frame, 250A heater, DC12V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 250A DC24V MSOD-2xN400 reversing starter, N400 frame, 250A heater, DC24V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 250A DC48V MSOD-2xN400 reversing starter, N400 frame, 250A heater, DC48V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 250A DC100V MSOD-2xN400 reversing starter, N400 frame, 250A heater, DC100V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 250A DC110V MSOD-2xN400 reversing starter, N400 frame, 250A heater, DC110V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 250A DC125V MSOD-2xN400 reversing starter, N400 frame, 250A heater, DC125V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 250A DC200V MSOD-2xN400 reversing starter, N400 frame, 250A heater, DC200V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 250A DC220V MSOD-2xN400 reversing starter, N400 frame, 250A heater, DC220V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 330A DC12V MSOD-2xN400 reversing starter, N400 frame, 330A heater, DC12V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 330A DC24V MSOD-2xN400 reversing starter, N400 frame, 330A heater, DC24V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 330A DC48V MSOD-2xN400 reversing starter, N400 frame, 330A heater, DC48V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 330A DC100V MSOD-2xN400 reversing starter, N400 frame, 330A heater, DC100V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 330A DC110V MSOD-2xN400 reversing starter, N400 frame, 330A heater, DC110V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 330A DC125V MSOD-2xN400 reversing starter, N400 frame, 330A heater, DC125V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 330A DC200V MSOD-2xN400 reversing starter, N400 frame, 330A heater, DC200V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 330A DC220V MSOD-2xN400 reversing starter, N400 frame, 330A heater, DC220V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
Magnetic StartersMitsubishi Electric
48 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric MS-T/N Series MSOD-2xN400 Reversing Magnetic Starter (400A AC-3, N400 Frame, TH-N400RH Thermal)

Brand Mitsubishi Electric·Magnetic Starters

Available part numbers (48)

MSOD-2xN400 105A DC12V, MSOD-2xN400 105A DC24V, MSOD-2xN400 105A DC48V, MSOD-2xN400 105A DC100V, MSOD-2xN400 105A DC110V, MSOD-2xN400 105A DC125V, MSOD-2xN400 105A DC200V, MSOD-2xN400 105A DC220V, MSOD-2xN400 125A DC12V, MSOD-2xN400 125A DC24V + 38 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MSOD-2xN400 105A DC12VMSOD-2xN400 reversing starter, N400 frame, 105A heater, DC12V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 105A DC24VMSOD-2xN400 reversing starter, N400 frame, 105A heater, DC24V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 105A DC48VMSOD-2xN400 reversing starter, N400 frame, 105A heater, DC48V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 105A DC100VMSOD-2xN400 reversing starter, N400 frame, 105A heater, DC100V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 105A DC110VMSOD-2xN400 reversing starter, N400 frame, 105A heater, DC110V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 105A DC125VMSOD-2xN400 reversing starter, N400 frame, 105A heater, DC125V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 105A DC200VMSOD-2xN400 reversing starter, N400 frame, 105A heater, DC200V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 105A DC220VMSOD-2xN400 reversing starter, N400 frame, 105A heater, DC220V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 105A (adjustable 85-125A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 125A DC12VMSOD-2xN400 reversing starter, N400 frame, 125A heater, DC12V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 125A DC24VMSOD-2xN400 reversing starter, N400 frame, 125A heater, DC24V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 125A DC48VMSOD-2xN400 reversing starter, N400 frame, 125A heater, DC48V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 125A DC100VMSOD-2xN400 reversing starter, N400 frame, 125A heater, DC100V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 125A DC110VMSOD-2xN400 reversing starter, N400 frame, 125A heater, DC110V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 125A DC125VMSOD-2xN400 reversing starter, N400 frame, 125A heater, DC125V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 125A DC200VMSOD-2xN400 reversing starter, N400 frame, 125A heater, DC200V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 125A DC220VMSOD-2xN400 reversing starter, N400 frame, 125A heater, DC220V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 125A (adjustable 100-150A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 150A DC12VMSOD-2xN400 reversing starter, N400 frame, 150A heater, DC12V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 150A DC24VMSOD-2xN400 reversing starter, N400 frame, 150A heater, DC24V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 150A DC48VMSOD-2xN400 reversing starter, N400 frame, 150A heater, DC48V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 150A DC100VMSOD-2xN400 reversing starter, N400 frame, 150A heater, DC100V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 150A DC110VMSOD-2xN400 reversing starter, N400 frame, 150A heater, DC110V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 150A DC125VMSOD-2xN400 reversing starter, N400 frame, 150A heater, DC125V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 150A DC200VMSOD-2xN400 reversing starter, N400 frame, 150A heater, DC200V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 150A DC220VMSOD-2xN400 reversing starter, N400 frame, 150A heater, DC220V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 150A (adjustable 120-180A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 180A DC12VMSOD-2xN400 reversing starter, N400 frame, 180A heater, DC12V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 180A DC24VMSOD-2xN400 reversing starter, N400 frame, 180A heater, DC24V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 180A DC48VMSOD-2xN400 reversing starter, N400 frame, 180A heater, DC48V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 180A DC100VMSOD-2xN400 reversing starter, N400 frame, 180A heater, DC100V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 180A DC110VMSOD-2xN400 reversing starter, N400 frame, 180A heater, DC110V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 180A DC125VMSOD-2xN400 reversing starter, N400 frame, 180A heater, DC125V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 180A DC200VMSOD-2xN400 reversing starter, N400 frame, 180A heater, DC200V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 180A DC220VMSOD-2xN400 reversing starter, N400 frame, 180A heater, DC220V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 180A (adjustable 140-220A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 250A DC12VMSOD-2xN400 reversing starter, N400 frame, 250A heater, DC12V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 250A DC24VMSOD-2xN400 reversing starter, N400 frame, 250A heater, DC24V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 250A DC48VMSOD-2xN400 reversing starter, N400 frame, 250A heater, DC48V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 250A DC100VMSOD-2xN400 reversing starter, N400 frame, 250A heater, DC100V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 250A DC110VMSOD-2xN400 reversing starter, N400 frame, 250A heater, DC110V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 250A DC125VMSOD-2xN400 reversing starter, N400 frame, 250A heater, DC125V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 250A DC200VMSOD-2xN400 reversing starter, N400 frame, 250A heater, DC200V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 250A DC220VMSOD-2xN400 reversing starter, N400 frame, 250A heater, DC220V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 250A (adjustable 200-300A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 330A DC12VMSOD-2xN400 reversing starter, N400 frame, 330A heater, DC12V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 330A DC24VMSOD-2xN400 reversing starter, N400 frame, 330A heater, DC24V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 330A DC48VMSOD-2xN400 reversing starter, N400 frame, 330A heater, DC48V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 330A DC100VMSOD-2xN400 reversing starter, N400 frame, 330A heater, DC100V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 330A DC110VMSOD-2xN400 reversing starter, N400 frame, 330A heater, DC110V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 330A DC125VMSOD-2xN400 reversing starter, N400 frame, 330A heater, DC125V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 330A DC200VMSOD-2xN400 reversing starter, N400 frame, 330A heater, DC200V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xN400 330A DC220VMSOD-2xN400 reversing starter, N400 frame, 330A heater, DC220V coil | Frame: N400 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-N400RH (2-element, manual reset) | Heater: 330A (adjustable 260-400A) | AC-3 Capacity: 110kW@200-220V / 200kW@380-440V / 200kW@500-550V | AC-3 Current: 400A@200-220V / 400A@380-440V / 350A@500-550V | AC-1 Current: 450A@200-220V / 450A@380-440V | Thermal Current Ith: 450A | Aux Contact: 3a3b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
