Mitsubishi Electric MS-T/N Series MSOD-2xT65 Reversing Magnetic Starter (65A AC-3, T65 Frame, TH-T65 Thermal)

Mitsubishi Electric MS-T/N Series MSOD-2xT65 Reversing Magnetic Starter (65A AC-3, T65 Frame, TH-T65 Thermal)

Mitsubishi Electric MS-T/N series T65-frame reversing open-type magnetic starter MSOD-2xT65: DC-operated contactor combined with TH-T65 2-element thermal overload relay (manual reset standard).

Key features

  • Rated 15kW / 65A (AC-3) at 200-220V and 30kW / 65A at 380-440V, Ith 100A
  • Heater designations 15A to 54A (6 steps) for overload and open-phase protection matching
  • Compliant with JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4; twin auxiliary contacts for high contact reliability
  • Mechanical interlock fitted as standard for forward/reverse motor switching

Specifications

Frame T65
Type Reversing Magnetic Starter (Open Type)
Poles 3
Operation DC operated
Thermal Relay TH-T65 (2-element, manual reset)
AC-3 Capacity 15kW@200-220V / 30kW@380-440V / 30kW@500-550V
AC-3 Current 65A@200-220V / 65A@380-440V / 45A@500-550V
AC-1 Current 100A@200-220V / 100A@380-440V
Thermal Current Ith 100A
Aux Contact 2a2b x2
Interlock Mechanical, built-in
Standards JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 15A DC12V MSOD-2xT65 reversing starter, T65 frame, 15A heater, DC12V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 15A DC24V MSOD-2xT65 reversing starter, T65 frame, 15A heater, DC24V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 15A DC48V MSOD-2xT65 reversing starter, T65 frame, 15A heater, DC48V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 15A DC100V MSOD-2xT65 reversing starter, T65 frame, 15A heater, DC100V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 15A DC110V MSOD-2xT65 reversing starter, T65 frame, 15A heater, DC110V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 15A DC125V MSOD-2xT65 reversing starter, T65 frame, 15A heater, DC125V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 15A DC200V MSOD-2xT65 reversing starter, T65 frame, 15A heater, DC200V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 15A DC220V MSOD-2xT65 reversing starter, T65 frame, 15A heater, DC220V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 22A DC12V MSOD-2xT65 reversing starter, T65 frame, 22A heater, DC12V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 22A DC24V MSOD-2xT65 reversing starter, T65 frame, 22A heater, DC24V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 22A DC48V MSOD-2xT65 reversing starter, T65 frame, 22A heater, DC48V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 22A DC100V MSOD-2xT65 reversing starter, T65 frame, 22A heater, DC100V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 22A DC110V MSOD-2xT65 reversing starter, T65 frame, 22A heater, DC110V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 22A DC125V MSOD-2xT65 reversing starter, T65 frame, 22A heater, DC125V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 22A DC200V MSOD-2xT65 reversing starter, T65 frame, 22A heater, DC200V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 22A DC220V MSOD-2xT65 reversing starter, T65 frame, 22A heater, DC220V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 29A DC12V MSOD-2xT65 reversing starter, T65 frame, 29A heater, DC12V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 29A DC24V MSOD-2xT65 reversing starter, T65 frame, 29A heater, DC24V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 29A DC48V MSOD-2xT65 reversing starter, T65 frame, 29A heater, DC48V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 29A DC100V MSOD-2xT65 reversing starter, T65 frame, 29A heater, DC100V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 29A DC110V MSOD-2xT65 reversing starter, T65 frame, 29A heater, DC110V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 29A DC125V MSOD-2xT65 reversing starter, T65 frame, 29A heater, DC125V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 29A DC200V MSOD-2xT65 reversing starter, T65 frame, 29A heater, DC200V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 29A DC220V MSOD-2xT65 reversing starter, T65 frame, 29A heater, DC220V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 35A DC12V MSOD-2xT65 reversing starter, T65 frame, 35A heater, DC12V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 35A DC24V MSOD-2xT65 reversing starter, T65 frame, 35A heater, DC24V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 35A DC48V MSOD-2xT65 reversing starter, T65 frame, 35A heater, DC48V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 35A DC100V MSOD-2xT65 reversing starter, T65 frame, 35A heater, DC100V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 35A DC110V MSOD-2xT65 reversing starter, T65 frame, 35A heater, DC110V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 35A DC125V MSOD-2xT65 reversing starter, T65 frame, 35A heater, DC125V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 35A DC200V MSOD-2xT65 reversing starter, T65 frame, 35A heater, DC200V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 35A DC220V MSOD-2xT65 reversing starter, T65 frame, 35A heater, DC220V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 42A DC12V MSOD-2xT65 reversing starter, T65 frame, 42A heater, DC12V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 42A DC24V MSOD-2xT65 reversing starter, T65 frame, 42A heater, DC24V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 42A DC48V MSOD-2xT65 reversing starter, T65 frame, 42A heater, DC48V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 42A DC100V MSOD-2xT65 reversing starter, T65 frame, 42A heater, DC100V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 42A DC110V MSOD-2xT65 reversing starter, T65 frame, 42A heater, DC110V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 42A DC125V MSOD-2xT65 reversing starter, T65 frame, 42A heater, DC125V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 42A DC200V MSOD-2xT65 reversing starter, T65 frame, 42A heater, DC200V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 42A DC220V MSOD-2xT65 reversing starter, T65 frame, 42A heater, DC220V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 54A DC12V MSOD-2xT65 reversing starter, T65 frame, 54A heater, DC12V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 54A DC24V MSOD-2xT65 reversing starter, T65 frame, 54A heater, DC24V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 54A DC48V MSOD-2xT65 reversing starter, T65 frame, 54A heater, DC48V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 54A DC100V MSOD-2xT65 reversing starter, T65 frame, 54A heater, DC100V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 54A DC110V MSOD-2xT65 reversing starter, T65 frame, 54A heater, DC110V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 54A DC125V MSOD-2xT65 reversing starter, T65 frame, 54A heater, DC125V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 54A DC200V MSOD-2xT65 reversing starter, T65 frame, 54A heater, DC200V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 54A DC220V MSOD-2xT65 reversing starter, T65 frame, 54A heater, DC220V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
Magnetic StartersMitsubishi Electric
48 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric MS-T/N Series MSOD-2xT65 Reversing Magnetic Starter (65A AC-3, T65 Frame, TH-T65 Thermal)

Brand Mitsubishi Electric·Magnetic Starters

Available part numbers (48)

MSOD-2xT65 15A DC12V, MSOD-2xT65 15A DC24V, MSOD-2xT65 15A DC48V, MSOD-2xT65 15A DC100V, MSOD-2xT65 15A DC110V, MSOD-2xT65 15A DC125V, MSOD-2xT65 15A DC200V, MSOD-2xT65 15A DC220V, MSOD-2xT65 22A DC12V, MSOD-2xT65 22A DC24V + 38 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MSOD-2xT65 15A DC12VMSOD-2xT65 reversing starter, T65 frame, 15A heater, DC12V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 15A DC24VMSOD-2xT65 reversing starter, T65 frame, 15A heater, DC24V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 15A DC48VMSOD-2xT65 reversing starter, T65 frame, 15A heater, DC48V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 15A DC100VMSOD-2xT65 reversing starter, T65 frame, 15A heater, DC100V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 15A DC110VMSOD-2xT65 reversing starter, T65 frame, 15A heater, DC110V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 15A DC125VMSOD-2xT65 reversing starter, T65 frame, 15A heater, DC125V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 15A DC200VMSOD-2xT65 reversing starter, T65 frame, 15A heater, DC200V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 15A DC220VMSOD-2xT65 reversing starter, T65 frame, 15A heater, DC220V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 15A (adjustable 12-18A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 22A DC12VMSOD-2xT65 reversing starter, T65 frame, 22A heater, DC12V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 22A DC24VMSOD-2xT65 reversing starter, T65 frame, 22A heater, DC24V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 22A DC48VMSOD-2xT65 reversing starter, T65 frame, 22A heater, DC48V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 22A DC100VMSOD-2xT65 reversing starter, T65 frame, 22A heater, DC100V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 22A DC110VMSOD-2xT65 reversing starter, T65 frame, 22A heater, DC110V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 22A DC125VMSOD-2xT65 reversing starter, T65 frame, 22A heater, DC125V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 22A DC200VMSOD-2xT65 reversing starter, T65 frame, 22A heater, DC200V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 22A DC220VMSOD-2xT65 reversing starter, T65 frame, 22A heater, DC220V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 22A (adjustable 18-26A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 29A DC12VMSOD-2xT65 reversing starter, T65 frame, 29A heater, DC12V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 29A DC24VMSOD-2xT65 reversing starter, T65 frame, 29A heater, DC24V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 29A DC48VMSOD-2xT65 reversing starter, T65 frame, 29A heater, DC48V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 29A DC100VMSOD-2xT65 reversing starter, T65 frame, 29A heater, DC100V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 29A DC110VMSOD-2xT65 reversing starter, T65 frame, 29A heater, DC110V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 29A DC125VMSOD-2xT65 reversing starter, T65 frame, 29A heater, DC125V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 29A DC200VMSOD-2xT65 reversing starter, T65 frame, 29A heater, DC200V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 29A DC220VMSOD-2xT65 reversing starter, T65 frame, 29A heater, DC220V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 29A (adjustable 24-34A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 35A DC12VMSOD-2xT65 reversing starter, T65 frame, 35A heater, DC12V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 35A DC24VMSOD-2xT65 reversing starter, T65 frame, 35A heater, DC24V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 35A DC48VMSOD-2xT65 reversing starter, T65 frame, 35A heater, DC48V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 35A DC100VMSOD-2xT65 reversing starter, T65 frame, 35A heater, DC100V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 35A DC110VMSOD-2xT65 reversing starter, T65 frame, 35A heater, DC110V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 35A DC125VMSOD-2xT65 reversing starter, T65 frame, 35A heater, DC125V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 35A DC200VMSOD-2xT65 reversing starter, T65 frame, 35A heater, DC200V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 35A DC220VMSOD-2xT65 reversing starter, T65 frame, 35A heater, DC220V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 35A (adjustable 30-40A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 42A DC12VMSOD-2xT65 reversing starter, T65 frame, 42A heater, DC12V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 42A DC24VMSOD-2xT65 reversing starter, T65 frame, 42A heater, DC24V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 42A DC48VMSOD-2xT65 reversing starter, T65 frame, 42A heater, DC48V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 42A DC100VMSOD-2xT65 reversing starter, T65 frame, 42A heater, DC100V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 42A DC110VMSOD-2xT65 reversing starter, T65 frame, 42A heater, DC110V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 42A DC125VMSOD-2xT65 reversing starter, T65 frame, 42A heater, DC125V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 42A DC200VMSOD-2xT65 reversing starter, T65 frame, 42A heater, DC200V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 42A DC220VMSOD-2xT65 reversing starter, T65 frame, 42A heater, DC220V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 42A (adjustable 34-50A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 54A DC12VMSOD-2xT65 reversing starter, T65 frame, 54A heater, DC12V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 54A DC24VMSOD-2xT65 reversing starter, T65 frame, 54A heater, DC24V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 54A DC48VMSOD-2xT65 reversing starter, T65 frame, 54A heater, DC48V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 54A DC100VMSOD-2xT65 reversing starter, T65 frame, 54A heater, DC100V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 54A DC110VMSOD-2xT65 reversing starter, T65 frame, 54A heater, DC110V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 54A DC125VMSOD-2xT65 reversing starter, T65 frame, 54A heater, DC125V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 54A DC200VMSOD-2xT65 reversing starter, T65 frame, 54A heater, DC200V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-2xT65 54A DC220VMSOD-2xT65 reversing starter, T65 frame, 54A heater, DC220V coil | Frame: T65 | Type: Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-T65 (2-element, manual reset) | Heater: 54A (adjustable 43-65A) | AC-3 Capacity: 15kW@200-220V / 30kW@380-440V / 30kW@500-550V | AC-3 Current: 65A@200-220V / 65A@380-440V / 45A@500-550V | AC-1 Current: 100A@200-220V / 100A@380-440V | Thermal Current Ith: 100A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4

Need a different model, or a part not listed here? Send us your parts list →
