Mitsubishi Electric MS-T/N Series MSOD-T80 Magnetic Starter (80A AC-3, T80 Frame, TH-T100 Thermal)

Mitsubishi Electric MS-T/N Series MSOD-T80 Magnetic Starter (80A AC-3, T80 Frame, TH-T100 Thermal)

Mitsubishi Electric MS-T/N series T80-frame non-reversing open-type magnetic starter MSOD-T80: DC-operated contactor combined with TH-T100 2-element thermal overload relay (manual reset standard).

Key features

  • Rated 19kW / 80A (AC-3) at 200-220V and 37kW / 80A at 380-440V, Ith 120A
  • Heater designations 67A to 67A (1 steps) for overload and open-phase protection matching
  • Compliant with JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4; twin auxiliary contacts for high contact reliability

Specifications

Frame T80
Type Non-Reversing Magnetic Starter (Open Type)
Poles 3
Operation DC operated
Thermal Relay TH-T100 (2-element, manual reset)
Heater 67A (adjustable 54-80A)
AC-3 Capacity 19kW@200-220V / 37kW@380-440V / 45kW@500-550V
AC-3 Current 80A@200-220V / 80A@380-440V / 75A@500-550V
AC-1 Current 120A@200-220V / 120A@380-440V
Thermal Current Ith 120A
Aux Contact 2a2b
Standards JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-T80 67A DC12V MSOD-T80 non-reversing starter, T80 frame, 67A heater, DC12V coil | Frame: T80 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-T80 67A DC24V MSOD-T80 non-reversing starter, T80 frame, 67A heater, DC24V coil | Frame: T80 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-T80 67A DC48V MSOD-T80 non-reversing starter, T80 frame, 67A heater, DC48V coil | Frame: T80 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-T80 67A DC100V MSOD-T80 non-reversing starter, T80 frame, 67A heater, DC100V coil | Frame: T80 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-T80 67A DC110V MSOD-T80 non-reversing starter, T80 frame, 67A heater, DC110V coil | Frame: T80 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-T80 67A DC125V MSOD-T80 non-reversing starter, T80 frame, 67A heater, DC125V coil | Frame: T80 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-T80 67A DC200V MSOD-T80 non-reversing starter, T80 frame, 67A heater, DC200V coil | Frame: T80 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-T80 67A DC220V MSOD-T80 non-reversing starter, T80 frame, 67A heater, DC220V coil | Frame: T80 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
Magnetic StartersMitsubishi Electric
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric MS-T/N Series MSOD-T80 Magnetic Starter (80A AC-3, T80 Frame, TH-T100 Thermal)

Brand Mitsubishi Electric·Magnetic Starters

Available part numbers (8)

MSOD-T80 67A DC12V, MSOD-T80 67A DC24V, MSOD-T80 67A DC48V, MSOD-T80 67A DC100V, MSOD-T80 67A DC110V, MSOD-T80 67A DC125V, MSOD-T80 67A DC200V, MSOD-T80 67A DC220V

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MSOD-T80 67A DC12VMSOD-T80 non-reversing starter, T80 frame, 67A heater, DC12V coil | Frame: T80 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-T80 67A DC24VMSOD-T80 non-reversing starter, T80 frame, 67A heater, DC24V coil | Frame: T80 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-T80 67A DC48VMSOD-T80 non-reversing starter, T80 frame, 67A heater, DC48V coil | Frame: T80 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-T80 67A DC100VMSOD-T80 non-reversing starter, T80 frame, 67A heater, DC100V coil | Frame: T80 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-T80 67A DC110VMSOD-T80 non-reversing starter, T80 frame, 67A heater, DC110V coil | Frame: T80 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-T80 67A DC125VMSOD-T80 non-reversing starter, T80 frame, 67A heater, DC125V coil | Frame: T80 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-T80 67A DC200VMSOD-T80 non-reversing starter, T80 frame, 67A heater, DC200V coil | Frame: T80 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
MSOD-T80 67A DC220VMSOD-T80 non-reversing starter, T80 frame, 67A heater, DC220V coil | Frame: T80 | Type: Non-Reversing Magnetic Starter (Open Type) | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | Thermal Relay: TH-T100 (2-element, manual reset) | Heater: 67A (adjustable 54-80A) | AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V | AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V | AC-1 Current: 120A@200-220V / 120A@380-440V | Thermal Current Ith: 120A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4

Need a different model, or a part not listed here? Send us your parts list →
