Mitsubishi Electric MS-T/N Series S-2xT25 Reversing Magnetic Contactor (26A AC-3, T25 Frame)

Mitsubishi Electric MS-T/N Series S-2xT25 Reversing Magnetic Contactor (26A AC-3, T25 Frame)

Mitsubishi Electric MS-T/N series T25-frame reversing magnetic contactor S-2xT25, rated 5.5kW / 26A (AC-3) at 200-220V and 11kW / 25A at 380-440V, conventional thermal current Ith 32A.

Key features

  • Compliant with JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4; twin auxiliary contacts for high contact reliability
  • AC operating coils AC24V-AC500V (S type)
  • Mechanical interlock fitted as standard for forward/reverse motor switching

Specifications

Frame T25
Type Reversing Magnetic Contactor
Poles 3
Operation AC operated
AC-3 Capacity 5.5kW@200-220V / 11kW@380-440V / 11kW@500-550V
AC-3 Current 26A@200-220V / 25A@380-440V / 20A@500-550V
AC-1 Current 32A@200-220V / 32A@380-440V
Thermal Current Ith 32A
Aux Contact 2a2b x2
Interlock Mechanical, built-in
Standards JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-2xT25 AC24V S-2xT25 reversing contactor, T25 frame, AC24V coil | Frame: T25 | Type: Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | AC-3 Capacity: 5.5kW@200-220V / 11kW@380-440V / 11kW@500-550V | AC-3 Current: 26A@200-220V / 25A@380-440V / 20A@500-550V | AC-1 Current: 32A@200-220V / 32A@380-440V | Thermal Current Ith: 32A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-2xT25 AC48V S-2xT25 reversing contactor, T25 frame, AC48V coil | Frame: T25 | Type: Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | AC-3 Capacity: 5.5kW@200-220V / 11kW@380-440V / 11kW@500-550V | AC-3 Current: 26A@200-220V / 25A@380-440V / 20A@500-550V | AC-1 Current: 32A@200-220V / 32A@380-440V | Thermal Current Ith: 32A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-2xT25 AC100V S-2xT25 reversing contactor, T25 frame, AC100V coil | Frame: T25 | Type: Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | AC-3 Capacity: 5.5kW@200-220V / 11kW@380-440V / 11kW@500-550V | AC-3 Current: 26A@200-220V / 25A@380-440V / 20A@500-550V | AC-1 Current: 32A@200-220V / 32A@380-440V | Thermal Current Ith: 32A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-2xT25 AC200V S-2xT25 reversing contactor, T25 frame, AC200V coil | Frame: T25 | Type: Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | AC-3 Capacity: 5.5kW@200-220V / 11kW@380-440V / 11kW@500-550V | AC-3 Current: 26A@200-220V / 25A@380-440V / 20A@500-550V | AC-1 Current: 32A@200-220V / 32A@380-440V | Thermal Current Ith: 32A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-2xT25 AC300V S-2xT25 reversing contactor, T25 frame, AC300V coil | Frame: T25 | Type: Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC300V (260-300V 50/60Hz) | AC-3 Capacity: 5.5kW@200-220V / 11kW@380-440V / 11kW@500-550V | AC-3 Current: 26A@200-220V / 25A@380-440V / 20A@500-550V | AC-1 Current: 32A@200-220V / 32A@380-440V | Thermal Current Ith: 32A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-2xT25 AC400V S-2xT25 reversing contactor, T25 frame, AC400V coil | Frame: T25 | Type: Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | AC-3 Capacity: 5.5kW@200-220V / 11kW@380-440V / 11kW@500-550V | AC-3 Current: 26A@200-220V / 25A@380-440V / 20A@500-550V | AC-1 Current: 32A@200-220V / 32A@380-440V | Thermal Current Ith: 32A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-2xT25 AC500V S-2xT25 reversing contactor, T25 frame, AC500V coil | Frame: T25 | Type: Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | AC-3 Capacity: 5.5kW@200-220V / 11kW@380-440V / 11kW@500-550V | AC-3 Current: 26A@200-220V / 25A@380-440V / 20A@500-550V | AC-1 Current: 32A@200-220V / 32A@380-440V | Thermal Current Ith: 32A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
Magnetic ContactorsMitsubishi Electric
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric MS-T/N Series S-2xT25 Reversing Magnetic Contactor (26A AC-3, T25 Frame)

Brand Mitsubishi Electric·Magnetic Contactors

Available part numbers (7)

S-2xT25 AC24V, S-2xT25 AC48V, S-2xT25 AC100V, S-2xT25 AC200V, S-2xT25 AC300V, S-2xT25 AC400V, S-2xT25 AC500V

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
S-2xT25 AC24VS-2xT25 reversing contactor, T25 frame, AC24V coil | Frame: T25 | Type: Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC24V (24V 50/60Hz) | AC-3 Capacity: 5.5kW@200-220V / 11kW@380-440V / 11kW@500-550V | AC-3 Current: 26A@200-220V / 25A@380-440V / 20A@500-550V | AC-1 Current: 32A@200-220V / 32A@380-440V | Thermal Current Ith: 32A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-2xT25 AC48VS-2xT25 reversing contactor, T25 frame, AC48V coil | Frame: T25 | Type: Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | AC-3 Capacity: 5.5kW@200-220V / 11kW@380-440V / 11kW@500-550V | AC-3 Current: 26A@200-220V / 25A@380-440V / 20A@500-550V | AC-1 Current: 32A@200-220V / 32A@380-440V | Thermal Current Ith: 32A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-2xT25 AC100VS-2xT25 reversing contactor, T25 frame, AC100V coil | Frame: T25 | Type: Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | AC-3 Capacity: 5.5kW@200-220V / 11kW@380-440V / 11kW@500-550V | AC-3 Current: 26A@200-220V / 25A@380-440V / 20A@500-550V | AC-1 Current: 32A@200-220V / 32A@380-440V | Thermal Current Ith: 32A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-2xT25 AC200VS-2xT25 reversing contactor, T25 frame, AC200V coil | Frame: T25 | Type: Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | AC-3 Capacity: 5.5kW@200-220V / 11kW@380-440V / 11kW@500-550V | AC-3 Current: 26A@200-220V / 25A@380-440V / 20A@500-550V | AC-1 Current: 32A@200-220V / 32A@380-440V | Thermal Current Ith: 32A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-2xT25 AC300VS-2xT25 reversing contactor, T25 frame, AC300V coil | Frame: T25 | Type: Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC300V (260-300V 50/60Hz) | AC-3 Capacity: 5.5kW@200-220V / 11kW@380-440V / 11kW@500-550V | AC-3 Current: 26A@200-220V / 25A@380-440V / 20A@500-550V | AC-1 Current: 32A@200-220V / 32A@380-440V | Thermal Current Ith: 32A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-2xT25 AC400VS-2xT25 reversing contactor, T25 frame, AC400V coil | Frame: T25 | Type: Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | AC-3 Capacity: 5.5kW@200-220V / 11kW@380-440V / 11kW@500-550V | AC-3 Current: 26A@200-220V / 25A@380-440V / 20A@500-550V | AC-1 Current: 32A@200-220V / 32A@380-440V | Thermal Current Ith: 32A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-2xT25 AC500VS-2xT25 reversing contactor, T25 frame, AC500V coil | Frame: T25 | Type: Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | AC-3 Capacity: 5.5kW@200-220V / 11kW@380-440V / 11kW@500-550V | AC-3 Current: 26A@200-220V / 25A@380-440V / 20A@500-550V | AC-1 Current: 32A@200-220V / 32A@380-440V | Thermal Current Ith: 32A | Aux Contact: 2a2b x2 | Interlock: Mechanical, built-in | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
