Mitsubishi Electric MS-T/N Series S-N220 / SD-N220 Magnetic Contactor (220A AC-3, N220 Frame)

Mitsubishi Electric MS-T/N Series S-N220 / SD-N220 Magnetic Contactor (220A AC-3, N220 Frame)

Mitsubishi Electric MS-T/N series N220-frame non-reversing magnetic contactor S-N220 / SD-N220, rated 55kW / 220A (AC-3) at 200-220V and 110kW / 220A at 380-440V, conventional thermal current Ith 260A.

Key features

  • Compliant with JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4; twin auxiliary contacts for high contact reliability
  • AC operating coils AC48V-AC500V (S type) and DC coils DC12V-DC220V (SD type)
  • Standard auxiliary contacts: 2a2b

Specifications

Frame N220
Type Non-Reversing Magnetic Contactor
Poles 3
AC-3 Capacity 55kW@200-220V / 110kW@380-440V / 132kW@500-550V
AC-3 Current 220A@200-220V / 220A@380-440V / 200A@500-550V
AC-1 Current 260A@200-220V / 260A@380-440V
Thermal Current Ith 260A
Aux Contact 2a2b
Standards JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N220 AC48V S-N220 non-reversing contactor, N220 frame, AC48V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N220 AC100V S-N220 non-reversing contactor, N220 frame, AC100V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N220 AC200V S-N220 non-reversing contactor, N220 frame, AC200V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N220 AC300V S-N220 non-reversing contactor, N220 frame, AC300V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N220 AC400V S-N220 non-reversing contactor, N220 frame, AC400V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N220 AC500V S-N220 non-reversing contactor, N220 frame, AC500V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N220 DC12V SD-N220 non-reversing contactor, N220 frame, DC12V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N220 DC24V SD-N220 non-reversing contactor, N220 frame, DC24V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N220 DC48V SD-N220 non-reversing contactor, N220 frame, DC48V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N220 DC100V SD-N220 non-reversing contactor, N220 frame, DC100V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N220 DC110V SD-N220 non-reversing contactor, N220 frame, DC110V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N220 DC125V SD-N220 non-reversing contactor, N220 frame, DC125V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N220 DC200V SD-N220 non-reversing contactor, N220 frame, DC200V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N220 DC220V SD-N220 non-reversing contactor, N220 frame, DC220V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
Magnetic ContactorsMitsubishi Electric
14 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric MS-T/N Series S-N220 / SD-N220 Magnetic Contactor (220A AC-3, N220 Frame)

Brand Mitsubishi Electric·Magnetic Contactors

Available part numbers (14)

S-N220 AC48V, S-N220 AC100V, S-N220 AC200V, S-N220 AC300V, S-N220 AC400V, S-N220 AC500V, SD-N220 DC12V, SD-N220 DC24V, SD-N220 DC48V, SD-N220 DC100V + 4 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
S-N220 AC48VS-N220 non-reversing contactor, N220 frame, AC48V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC48V (48-50V 50/60Hz) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N220 AC100VS-N220 non-reversing contactor, N220 frame, AC100V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N220 AC200VS-N220 non-reversing contactor, N220 frame, AC200V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N220 AC300VS-N220 non-reversing contactor, N220 frame, AC300V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N220 AC400VS-N220 non-reversing contactor, N220 frame, AC400V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N220 AC500VS-N220 non-reversing contactor, N220 frame, AC500V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N220 DC12VSD-N220 non-reversing contactor, N220 frame, DC12V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC12V (DC12V) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N220 DC24VSD-N220 non-reversing contactor, N220 frame, DC24V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N220 DC48VSD-N220 non-reversing contactor, N220 frame, DC48V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N220 DC100VSD-N220 non-reversing contactor, N220 frame, DC100V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N220 DC110VSD-N220 non-reversing contactor, N220 frame, DC110V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC110V (DC110V) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N220 DC125VSD-N220 non-reversing contactor, N220 frame, DC125V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N220 DC200VSD-N220 non-reversing contactor, N220 frame, DC200V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N220 DC220VSD-N220 non-reversing contactor, N220 frame, DC220V coil | Frame: N220 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC220V (DC220V) | AC-3 Capacity: 55kW@200-220V / 110kW@380-440V / 132kW@500-550V | AC-3 Current: 220A@200-220V / 220A@380-440V / 200A@500-550V | AC-1 Current: 260A@200-220V / 260A@380-440V | Thermal Current Ith: 260A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
