Mitsubishi Electric MS-T/N Series S-N600 / SD-N600 Magnetic Contactor (630A AC-3, N600 Frame)

Mitsubishi Electric MS-T/N Series S-N600 / SD-N600 Magnetic Contactor (630A AC-3, N600 Frame)

Mitsubishi Electric MS-T/N series N600-frame non-reversing magnetic contactor S-N600 / SD-N600, rated 160kW / 630A (AC-3) at 200-220V and 300kW / 630A at 380-440V, conventional thermal current Ith 660A.

Key features

  • Compliant with JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4; twin auxiliary contacts for high contact reliability
  • AC operating coils AC100V-AC500V (S type) and DC coils DC24V-DC200V (SD type)
  • Standard auxiliary contacts: 2a2b

Specifications

Frame N600
Type Non-Reversing Magnetic Contactor
Poles 3
AC-3 Capacity 160kW@200-220V / 300kW@380-440V / 300kW@500-550V
AC-3 Current 630A@200-220V / 630A@380-440V / 500A@500-550V
AC-1 Current 660A@200-220V / 660A@380-440V
Thermal Current Ith 660A
Aux Contact 2a2b
Standards JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N600 AC100V S-N600 non-reversing contactor, N600 frame, AC100V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N600 AC200V S-N600 non-reversing contactor, N600 frame, AC200V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N600 AC300V S-N600 non-reversing contactor, N600 frame, AC300V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N600 AC400V S-N600 non-reversing contactor, N600 frame, AC400V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N600 AC500V S-N600 non-reversing contactor, N600 frame, AC500V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N600 DC24V SD-N600 non-reversing contactor, N600 frame, DC24V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N600 DC48V SD-N600 non-reversing contactor, N600 frame, DC48V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N600 DC100V SD-N600 non-reversing contactor, N600 frame, DC100V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N600 DC125V SD-N600 non-reversing contactor, N600 frame, DC125V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N600 DC200V SD-N600 non-reversing contactor, N600 frame, DC200V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
Magnetic ContactorsMitsubishi Electric
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric MS-T/N Series S-N600 / SD-N600 Magnetic Contactor (630A AC-3, N600 Frame)

Brand Mitsubishi Electric·Magnetic Contactors

Available part numbers (10)

S-N600 AC100V, S-N600 AC200V, S-N600 AC300V, S-N600 AC400V, S-N600 AC500V, SD-N600 DC24V, SD-N600 DC48V, SD-N600 DC100V, SD-N600 DC125V, SD-N600 DC200V

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
S-N600 AC100VS-N600 non-reversing contactor, N600 frame, AC100V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N600 AC200VS-N600 non-reversing contactor, N600 frame, AC200V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N600 AC300VS-N600 non-reversing contactor, N600 frame, AC300V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N600 AC400VS-N600 non-reversing contactor, N600 frame, AC400V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N600 AC500VS-N600 non-reversing contactor, N600 frame, AC500V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N600 DC24VSD-N600 non-reversing contactor, N600 frame, DC24V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N600 DC48VSD-N600 non-reversing contactor, N600 frame, DC48V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N600 DC100VSD-N600 non-reversing contactor, N600 frame, DC100V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N600 DC125VSD-N600 non-reversing contactor, N600 frame, DC125V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N600 DC200VSD-N600 non-reversing contactor, N600 frame, DC200V coil | Frame: N600 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | AC-3 Capacity: 160kW@200-220V / 300kW@380-440V / 300kW@500-550V | AC-3 Current: 630A@200-220V / 630A@380-440V / 500A@500-550V | AC-1 Current: 660A@200-220V / 660A@380-440V | Thermal Current Ith: 660A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
