Mitsubishi Electric MS-T/N Series S-N800 / SD-N800 Magnetic Contactor (800A AC-3, N800 Frame)

Mitsubishi Electric MS-T/N Series S-N800 / SD-N800 Magnetic Contactor (800A AC-3, N800 Frame)

Mitsubishi Electric MS-T/N series N800-frame non-reversing magnetic contactor S-N800 / SD-N800, rated 200kW / 800A (AC-3) at 200-220V and 400kW / 800A at 380-440V, conventional thermal current Ith 800A.

Key features

  • Compliant with JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4; twin auxiliary contacts for high contact reliability
  • AC operating coils AC100V-AC500V (S type) and DC coils DC24V-DC200V (SD type)
  • Standard auxiliary contacts: 2a2b

Specifications

Frame N800
Type Non-Reversing Magnetic Contactor
Poles 3
AC-3 Capacity 200kW@200-220V / 400kW@380-440V / 400kW@500-550V
AC-3 Current 800A@200-220V / 800A@380-440V / 720A@500-550V
AC-1 Current 800A@200-220V / 800A@380-440V
Thermal Current Ith 800A
Aux Contact 2a2b
Standards JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N800 AC100V S-N800 non-reversing contactor, N800 frame, AC100V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N800 AC200V S-N800 non-reversing contactor, N800 frame, AC200V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N800 AC300V S-N800 non-reversing contactor, N800 frame, AC300V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N800 AC400V S-N800 non-reversing contactor, N800 frame, AC400V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N800 AC500V S-N800 non-reversing contactor, N800 frame, AC500V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N800 DC24V SD-N800 non-reversing contactor, N800 frame, DC24V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N800 DC48V SD-N800 non-reversing contactor, N800 frame, DC48V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N800 DC100V SD-N800 non-reversing contactor, N800 frame, DC100V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N800 DC125V SD-N800 non-reversing contactor, N800 frame, DC125V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N800 DC200V SD-N800 non-reversing contactor, N800 frame, DC200V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
Magnetic ContactorsMitsubishi Electric
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric MS-T/N Series S-N800 / SD-N800 Magnetic Contactor (800A AC-3, N800 Frame)

Brand Mitsubishi Electric·Magnetic Contactors

Available part numbers (10)

S-N800 AC100V, S-N800 AC200V, S-N800 AC300V, S-N800 AC400V, S-N800 AC500V, SD-N800 DC24V, SD-N800 DC48V, SD-N800 DC100V, SD-N800 DC125V, SD-N800 DC200V

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
S-N800 AC100VS-N800 non-reversing contactor, N800 frame, AC100V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC100V (100-127V 50/60Hz) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N800 AC200VS-N800 non-reversing contactor, N800 frame, AC200V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC200V (200-240V 50/60Hz) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N800 AC300VS-N800 non-reversing contactor, N800 frame, AC300V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC300V (260-350V 50/60Hz) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N800 AC400VS-N800 non-reversing contactor, N800 frame, AC400V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC400V (380-440V 50/60Hz) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
S-N800 AC500VS-N800 non-reversing contactor, N800 frame, AC500V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: AC operated | Coil: AC500V (460-550V 50/60Hz) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N800 DC24VSD-N800 non-reversing contactor, N800 frame, DC24V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC24V (DC24V) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N800 DC48VSD-N800 non-reversing contactor, N800 frame, DC48V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC48V (DC48V) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N800 DC100VSD-N800 non-reversing contactor, N800 frame, DC100V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC100V (DC100V) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N800 DC125VSD-N800 non-reversing contactor, N800 frame, DC125V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC125V (DC120-125V) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
SD-N800 DC200VSD-N800 non-reversing contactor, N800 frame, DC200V coil | Frame: N800 | Type: Non-Reversing Magnetic Contactor | Poles: 3 | Operation: DC operated | Coil: DC200V (DC200V) | AC-3 Capacity: 200kW@200-220V / 400kW@380-440V / 400kW@500-550V | AC-3 Current: 800A@200-220V / 800A@380-440V / 720A@500-550V | AC-1 Current: 800A@200-220V / 800A@380-440V | Thermal Current Ith: 800A | Aux Contact: 2a2b | Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4
