Mitsubishi Electric MS-T/N series S-T80FN class 2 heat-resistant magnetic contactor for distribution boards and panelboards of dedicated emergency power receiving equipment.

Key features

  • Retains conduction and insulation function at high temperature during a fire so that power to fire fighting equipment continues, switching and carrying the heat-resistant rated current for 30 minutes under the one seventh fire temperature curve
  • Heat-resistant carrying current 84A, heat-resistant rated current 80A at 220V, 80A at 440V, 75A at 550V under AC-3 class and 84A at 220V, 84A at 440V under AC-1 class, 3a main contacts
  • AC operated coil, durability and outline dimensions the same as the standard product
  • Reversing type S-2XT80FN is available
  • Type approval number 2MC-16174
  • Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981

Specifications

Type Class 2 heat-resistant magnetic contactor for emergency power switchboards
Frame T80
Operation AC operated
Main Contact 3a
Heat Resistant Carrying Current 84A
Heat Resistant Rated Current AC-3 Class 80A at 220V, 80A at 440V, 75A at 550V
Heat Resistant Rated Current AC-1 Class 84A at 220V, 84A at 440V
DC Rated Current at DC48V 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class)
DC Rated Current at DC110V 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class)
DC Rated Current at DC220V 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class)
Durability Same as the standard product
Type Approval Number 2MC-16174
S-T80FN AC24V S-T80FN class 2 heat-resistant contactor, AC24V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: T80 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC24V | Coil Rating: 24V 50/60Hz | Heat Resistant Carrying Current: 84A | Heat Resistant Rated Current AC-3 Class: 80A at 220V, 80A at 440V, 75A at 550V | Heat Resistant Rated Current AC-1 Class: 84A at 220V, 84A at 440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-16174 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XT80FN AC24V S-2XT80FN class 2 heat-resistant contactor, AC24V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: T80 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC24V | Coil Rating: 24V 50/60Hz | Heat Resistant Carrying Current: 84A | Heat Resistant Rated Current AC-3 Class: 80A at 220V, 80A at 440V, 75A at 550V | Heat Resistant Rated Current AC-1 Class: 84A at 220V, 84A at 440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-16174 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-T80FN AC48V S-T80FN class 2 heat-resistant contactor, AC48V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: T80 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC48V | Coil Rating: 48-50V 50/60Hz | Heat Resistant Carrying Current: 84A | Heat Resistant Rated Current AC-3 Class: 80A at 220V, 80A at 440V, 75A at 550V | Heat Resistant Rated Current AC-1 Class: 84A at 220V, 84A at 440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-16174 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XT80FN AC48V S-2XT80FN class 2 heat-resistant contactor, AC48V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: T80 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC48V | Coil Rating: 48-50V 50/60Hz | Heat Resistant Carrying Current: 84A | Heat Resistant Rated Current AC-3 Class: 80A at 220V, 80A at 440V, 75A at 550V | Heat Resistant Rated Current AC-1 Class: 84A at 220V, 84A at 440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-16174 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-T80FN AC100V S-T80FN class 2 heat-resistant contactor, AC100V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: T80 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC100V | Coil Rating: 100-127V 50/60Hz | Heat Resistant Carrying Current: 84A | Heat Resistant Rated Current AC-3 Class: 80A at 220V, 80A at 440V, 75A at 550V | Heat Resistant Rated Current AC-1 Class: 84A at 220V, 84A at 440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-16174 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XT80FN AC100V S-2XT80FN class 2 heat-resistant contactor, AC100V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: T80 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC100V | Coil Rating: 100-127V 50/60Hz | Heat Resistant Carrying Current: 84A | Heat Resistant Rated Current AC-3 Class: 80A at 220V, 80A at 440V, 75A at 550V | Heat Resistant Rated Current AC-1 Class: 84A at 220V, 84A at 440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-16174 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-T80FN AC200V S-T80FN class 2 heat-resistant contactor, AC200V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: T80 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC200V | Coil Rating: 200-240V 50/60Hz | Heat Resistant Carrying Current: 84A | Heat Resistant Rated Current AC-3 Class: 80A at 220V, 80A at 440V, 75A at 550V | Heat Resistant Rated Current AC-1 Class: 84A at 220V, 84A at 440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-16174 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XT80FN AC200V S-2XT80FN class 2 heat-resistant contactor, AC200V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: T80 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC200V | Coil Rating: 200-240V 50/60Hz | Heat Resistant Carrying Current: 84A | Heat Resistant Rated Current AC-3 Class: 80A at 220V, 80A at 440V, 75A at 550V | Heat Resistant Rated Current AC-1 Class: 84A at 220V, 84A at 440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-16174 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-T80FN AC300V S-T80FN class 2 heat-resistant contactor, AC300V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: T80 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC300V | Coil Rating: 260-350V 50/60Hz | Heat Resistant Carrying Current: 84A | Heat Resistant Rated Current AC-3 Class: 80A at 220V, 80A at 440V, 75A at 550V | Heat Resistant Rated Current AC-1 Class: 84A at 220V, 84A at 440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-16174 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XT80FN AC300V S-2XT80FN class 2 heat-resistant contactor, AC300V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: T80 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC300V | Coil Rating: 260-350V 50/60Hz | Heat Resistant Carrying Current: 84A | Heat Resistant Rated Current AC-3 Class: 80A at 220V, 80A at 440V, 75A at 550V | Heat Resistant Rated Current AC-1 Class: 84A at 220V, 84A at 440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-16174 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-T80FN AC400V S-T80FN class 2 heat-resistant contactor, AC400V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: T80 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC400V | Coil Rating: 380-440V 50/60Hz | Heat Resistant Carrying Current: 84A | Heat Resistant Rated Current AC-3 Class: 80A at 220V, 80A at 440V, 75A at 550V | Heat Resistant Rated Current AC-1 Class: 84A at 220V, 84A at 440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-16174 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XT80FN AC400V S-2XT80FN class 2 heat-resistant contactor, AC400V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: T80 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC400V | Coil Rating: 380-440V 50/60Hz | Heat Resistant Carrying Current: 84A | Heat Resistant Rated Current AC-3 Class: 80A at 220V, 80A at 440V, 75A at 550V | Heat Resistant Rated Current AC-1 Class: 84A at 220V, 84A at 440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-16174 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-T80FN AC500V S-T80FN class 2 heat-resistant contactor, AC500V coil, non-reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: T80 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b | Coil Designation: AC500V | Coil Rating: 460-550V 50/60Hz | Heat Resistant Carrying Current: 84A | Heat Resistant Rated Current AC-3 Class: 80A at 220V, 80A at 440V, 75A at 550V | Heat Resistant Rated Current AC-1 Class: 84A at 220V, 84A at 440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-16174 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
S-2XT80FN AC500V S-2XT80FN class 2 heat-resistant contactor, AC500V coil, reversing | Type: Class 2 heat-resistant magnetic contactor for emergency power switchboards | Frame: T80 | Configuration: Reversing | Operation: AC operated | Main Contact: 3a | Aux Contact: 2a2b x2 | Coil Designation: AC500V | Coil Rating: 460-550V 50/60Hz | Heat Resistant Carrying Current: 84A | Heat Resistant Rated Current AC-3 Class: 80A at 220V, 80A at 440V, 75A at 550V | Heat Resistant Rated Current AC-1 Class: 84A at 220V, 84A at 440V | DC Rated Current at DC48V: 40A 2-pole series, 60A 3-pole series (DC2 and DC4 class), 65A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC110V: 20A 2-pole series, 50A 3-pole series (DC2 and DC4 class), 50A 2-pole series, 80A 3-pole series (DC1 class) | DC Rated Current at DC220V: 5A 2-pole series, 20A 3-pole series (DC2 and DC4 class), 20A 2-pole series, 60A 3-pole series (DC1 class) | Durability: Same as the standard product | Type Approval Number: 2MC-16174 | Heat Performance: Class 2 heat resistance, switches and carries the heat-resistant rated current for 30 minutes without failure under the one seventh fire temperature curve | Certification: Certified by the Japan Electrical Manufacturers Association of Distribution Control Systems to Fire and Disaster Management Agency Notification No.10 of 1981 | Selection: For emergency power circuits keep the load current within the heat-resistant rated current and select wire sized for at least the load current divided by 0.7 at normal temperature
