Mitsubishi Electric UN-TL Thermal Relay Trip Indicator Lamps

Mitsubishi Electric UN-TL LED trip indicator lamps display the tripped state of TH thermal overload relays and mount directly on the relay.

Key features

Three sizes by relay frame (UN-TL12 for TH-T18, UN-TL20 for TH-T25/T50, UN-TL60 for TH-T65/T100 and TH-N120 to N600) with rated voltages AC24V/DC24V, AC100-127V, and AC200-240V; power consumption 0.18 to 0.2W
UN-TL60 cannot be combined with TH-N120TAHZ

UN-TL12 DC24V		Trip indicator lamp UN-TL12, DC24V \| Voltage Designation: DC24V \| Rated Voltage: AC24V/DC24V \| Power Consumption: 0.2W \| Applicable Thermal Relay: TH-T18
UN-TL12 AC100V		Trip indicator lamp UN-TL12, AC100V \| Voltage Designation: AC100V \| Rated Voltage: AC100-127V \| Power Consumption: 0.18W \| Applicable Thermal Relay: TH-T18
UN-TL12 AC200V		Trip indicator lamp UN-TL12, AC200V \| Voltage Designation: AC200V \| Rated Voltage: AC200-240V \| Power Consumption: 0.2W \| Applicable Thermal Relay: TH-T18
UN-TL20 DC24V		Trip indicator lamp UN-TL20, DC24V \| Voltage Designation: DC24V \| Rated Voltage: AC24V/DC24V \| Power Consumption: 0.2W \| Applicable Thermal Relay: TH-T25/T50
UN-TL20 AC100V		Trip indicator lamp UN-TL20, AC100V \| Voltage Designation: AC100V \| Rated Voltage: AC100-127V \| Power Consumption: 0.18W \| Applicable Thermal Relay: TH-T25/T50
UN-TL20 AC200V		Trip indicator lamp UN-TL20, AC200V \| Voltage Designation: AC200V \| Rated Voltage: AC200-240V \| Power Consumption: 0.2W \| Applicable Thermal Relay: TH-T25/T50
UN-TL60 DC24V		Trip indicator lamp UN-TL60, DC24V \| Voltage Designation: DC24V \| Rated Voltage: AC24V/DC24V \| Power Consumption: 0.2W \| Applicable Thermal Relay: TH-T65/T100, TH-N120 to N600
UN-TL60 AC100V		Trip indicator lamp UN-TL60, AC100V \| Voltage Designation: AC100V \| Rated Voltage: AC100-127V \| Power Consumption: 0.18W \| Applicable Thermal Relay: TH-T65/T100, TH-N120 to N600
UN-TL60 AC200V		Trip indicator lamp UN-TL60, AC200V \| Voltage Designation: AC200V \| Rated Voltage: AC200-240V \| Power Consumption: 0.2W \| Applicable Thermal Relay: TH-T65/T100, TH-N120 to N600

AccessoriesMitsubishi Electric

9 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric UN-TL Thermal Relay Trip Indicator Lamps

Brand Mitsubishi Electric·Accessories

Available part numbers (9)

UN-TL12 DC24V, UN-TL12 AC100V, UN-TL12 AC200V, UN-TL20 DC24V, UN-TL20 AC100V, UN-TL20 AC200V, UN-TL60 DC24V, UN-TL60 AC100V, UN-TL60 AC200V

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

	Product code	Spec
	UN-TL12 DC24V	Trip indicator lamp UN-TL12, DC24V \| Voltage Designation: DC24V \| Rated Voltage: AC24V/DC24V \| Power Consumption: 0.2W \| Applicable Thermal Relay: TH-T18
	UN-TL12 AC100V	Trip indicator lamp UN-TL12, AC100V \| Voltage Designation: AC100V \| Rated Voltage: AC100-127V \| Power Consumption: 0.18W \| Applicable Thermal Relay: TH-T18
	UN-TL12 AC200V	Trip indicator lamp UN-TL12, AC200V \| Voltage Designation: AC200V \| Rated Voltage: AC200-240V \| Power Consumption: 0.2W \| Applicable Thermal Relay: TH-T18
	UN-TL20 DC24V	Trip indicator lamp UN-TL20, DC24V \| Voltage Designation: DC24V \| Rated Voltage: AC24V/DC24V \| Power Consumption: 0.2W \| Applicable Thermal Relay: TH-T25/T50
	UN-TL20 AC100V	Trip indicator lamp UN-TL20, AC100V \| Voltage Designation: AC100V \| Rated Voltage: AC100-127V \| Power Consumption: 0.18W \| Applicable Thermal Relay: TH-T25/T50
	UN-TL20 AC200V	Trip indicator lamp UN-TL20, AC200V \| Voltage Designation: AC200V \| Rated Voltage: AC200-240V \| Power Consumption: 0.2W \| Applicable Thermal Relay: TH-T25/T50
	UN-TL60 DC24V	Trip indicator lamp UN-TL60, DC24V \| Voltage Designation: DC24V \| Rated Voltage: AC24V/DC24V \| Power Consumption: 0.2W \| Applicable Thermal Relay: TH-T65/T100, TH-N120 to N600
	UN-TL60 AC100V	Trip indicator lamp UN-TL60, AC100V \| Voltage Designation: AC100V \| Rated Voltage: AC100-127V \| Power Consumption: 0.18W \| Applicable Thermal Relay: TH-T65/T100, TH-N120 to N600
	UN-TL60 AC200V	Trip indicator lamp UN-TL60, AC200V \| Voltage Designation: AC200V \| Rated Voltage: AC200-240V \| Power Consumption: 0.2W \| Applicable Thermal Relay: TH-T65/T100, TH-N120 to N600
