Mitsubishi Electric UN-YG, UT/UN-YD Short-Circuiting Conductor Kits (3-Pole and 2-Pole)

Mitsubishi Electric UN-YG, UT/UN-YD Short-Circuiting Conductor Kits (3-Pole and 2-Pole)

Mitsubishi Electric UN-YG 3-pole and UT/UN-YD 2-pole short-circuiting conductor kits for MS-T/N magnetic contactor main circuit terminals.

Key features

  • Two conductors are required to form a 3-pole parallel circuit (YG) or 3-pole series circuit (YD)
  • YG21 to YG80 and YD21 to YD80 mount directly on the contactor terminals; larger sizes require arc box removal during installation
  • When used on the power supply side, install after coil wiring
  • Not combinable with UN-CZ live-part protective covers
UN-YG21 3-pole short-circuiting conductor UN-YG21, frame T21, T25, T32 | Type: 3-pole short-circuiting | Applicable Frame: T21, T25, T32 | Note: 2 conductors per parallel circuit
UN-YG25 3-pole short-circuiting conductor UN-YG25, frame T35, T50, N38, N48 | Type: 3-pole short-circuiting | Applicable Frame: T35, T50, N38, N48 | Note: 2 conductors per parallel circuit
UN-YG50 3-pole short-circuiting conductor UN-YG50, frame T65, T80 | Type: 3-pole short-circuiting | Applicable Frame: T65, T80 | Note: 2 conductors per parallel circuit
UN-YG80 3-pole short-circuiting conductor UN-YG80, frame T100, N125 | Type: 3-pole short-circuiting | Applicable Frame: T100, N125 | Note: 2 conductors per parallel circuit
UN-YG150 3-pole short-circuiting conductor UN-YG150, frame N150 | Type: 3-pole short-circuiting | Applicable Frame: N150 | Note: 2 conductors per parallel circuit
UN-YG220 3-pole short-circuiting conductor UN-YG220, frame N180, N220 | Type: 3-pole short-circuiting | Applicable Frame: N180, N220 | Note: 2 conductors per parallel circuit
UN-YG300 3-pole short-circuiting conductor UN-YG300, frame N300, N400 | Type: 3-pole short-circuiting | Applicable Frame: N300, N400 | Note: 2 conductors per parallel circuit
UT-YD20 2-pole short-circuiting conductor UT-YD20, frame T10, T12, T20 | Type: 2-pole short-circuiting | Applicable Frame: T10, T12, T20 | Note: 2 conductors per series circuit
UN-YD21 2-pole short-circuiting conductor UN-YD21, frame T21, T25, T32 | Type: 2-pole short-circuiting | Applicable Frame: T21, T25, T32 | Note: 2 conductors per series circuit
UN-YD25 2-pole short-circuiting conductor UN-YD25, frame T35, T50, N38, N48 | Type: 2-pole short-circuiting | Applicable Frame: T35, T50, N38, N48 | Note: 2 conductors per series circuit
UN-YD50 2-pole short-circuiting conductor UN-YD50, frame T65, T80 | Type: 2-pole short-circuiting | Applicable Frame: T65, T80 | Note: 2 conductors per series circuit
UN-YD80 2-pole short-circuiting conductor UN-YD80, frame T100, N125 | Type: 2-pole short-circuiting | Applicable Frame: T100, N125 | Note: 2 conductors per series circuit
UN-YD150 2-pole short-circuiting conductor UN-YD150, frame N150 | Type: 2-pole short-circuiting | Applicable Frame: N150 | Note: 2 conductors per series circuit
UN-YD220 2-pole short-circuiting conductor UN-YD220, frame N180, N220 | Type: 2-pole short-circuiting | Applicable Frame: N180, N220 | Note: 2 conductors per series circuit
UN-YD300 2-pole short-circuiting conductor UN-YD300, frame N300, N400 | Type: 2-pole short-circuiting | Applicable Frame: N300, N400 | Note: 2 conductors per series circuit
AccessoriesMitsubishi Electric
15 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric UN-YG, UT/UN-YD Short-Circuiting Conductor Kits (3-Pole and 2-Pole)

Brand Mitsubishi Electric·Accessories

Available part numbers (15)

UN-YG21, UN-YG25, UN-YG50, UN-YG80, UN-YG150, UN-YG220, UN-YG300, UT-YD20, UN-YD21, UN-YD25 + 5 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
UN-YG213-pole short-circuiting conductor UN-YG21, frame T21, T25, T32 | Type: 3-pole short-circuiting | Applicable Frame: T21, T25, T32 | Note: 2 conductors per parallel circuit
UN-YG253-pole short-circuiting conductor UN-YG25, frame T35, T50, N38, N48 | Type: 3-pole short-circuiting | Applicable Frame: T35, T50, N38, N48 | Note: 2 conductors per parallel circuit
UN-YG503-pole short-circuiting conductor UN-YG50, frame T65, T80 | Type: 3-pole short-circuiting | Applicable Frame: T65, T80 | Note: 2 conductors per parallel circuit
UN-YG803-pole short-circuiting conductor UN-YG80, frame T100, N125 | Type: 3-pole short-circuiting | Applicable Frame: T100, N125 | Note: 2 conductors per parallel circuit
UN-YG1503-pole short-circuiting conductor UN-YG150, frame N150 | Type: 3-pole short-circuiting | Applicable Frame: N150 | Note: 2 conductors per parallel circuit
UN-YG2203-pole short-circuiting conductor UN-YG220, frame N180, N220 | Type: 3-pole short-circuiting | Applicable Frame: N180, N220 | Note: 2 conductors per parallel circuit
UN-YG3003-pole short-circuiting conductor UN-YG300, frame N300, N400 | Type: 3-pole short-circuiting | Applicable Frame: N300, N400 | Note: 2 conductors per parallel circuit
UT-YD202-pole short-circuiting conductor UT-YD20, frame T10, T12, T20 | Type: 2-pole short-circuiting | Applicable Frame: T10, T12, T20 | Note: 2 conductors per series circuit
UN-YD212-pole short-circuiting conductor UN-YD21, frame T21, T25, T32 | Type: 2-pole short-circuiting | Applicable Frame: T21, T25, T32 | Note: 2 conductors per series circuit
UN-YD252-pole short-circuiting conductor UN-YD25, frame T35, T50, N38, N48 | Type: 2-pole short-circuiting | Applicable Frame: T35, T50, N38, N48 | Note: 2 conductors per series circuit
UN-YD502-pole short-circuiting conductor UN-YD50, frame T65, T80 | Type: 2-pole short-circuiting | Applicable Frame: T65, T80 | Note: 2 conductors per series circuit
UN-YD802-pole short-circuiting conductor UN-YD80, frame T100, N125 | Type: 2-pole short-circuiting | Applicable Frame: T100, N125 | Note: 2 conductors per series circuit
UN-YD1502-pole short-circuiting conductor UN-YD150, frame N150 | Type: 2-pole short-circuiting | Applicable Frame: N150 | Note: 2 conductors per series circuit
UN-YD2202-pole short-circuiting conductor UN-YD220, frame N180, N220 | Type: 2-pole short-circuiting | Applicable Frame: N180, N220 | Note: 2 conductors per series circuit
UN-YD3002-pole short-circuiting conductor UN-YD300, frame N300, N400 | Type: 2-pole short-circuiting | Applicable Frame: N300, N400 | Note: 2 conductors per series circuit
