Mitsubishi Electric - US-H30 Heater Load Solid State Contactor (AC24-480V, 30A AC-1)

Mitsubishi Electric - US-H30 Heater Load Solid State Contactor (AC24-480V, 30A AC-1)

Mitsubishi Electric MS-T/N series US-H30 solid state contactor dedicated to heater loads, suited to injection moulding machines, semiconductor production equipment and similar applications.

Key features

  • Wide main circuit voltage range AC24-480V with rated operational current 30A under AC-1 class between -10 and 40 degrees C, heater capacity 6kW at 1 phase 200V, 10.3kW at 3 phase 200V, 20.7kW at 3 phase 400V under batch control
  • Semiconductor switching gives long life in high frequency switching duty with no switching noise, no wearing parts and clean operation, and a front operation indicator shows the control input state
  • The DD code selects individual control in place of batch control and the HZ code supplies the unit without a cooling fin, while the RM code gives a rail mount only specification and the UF code a reduced width body
  • A charged part protection cover unit UN-CV501US and the power control unit UA-PC are available as options
  • Derate the rated operational current above 40 degrees C ambient
  • JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable

Specifications

Type Solid state contactor for heater loads
Frame H30
Rated Voltage AC24-480V
Rated Operational Current AC-1 Class 30A at -10 to 40 degrees C
Heater Capacity 6kW at 1 phase 200V, 10.3kW at 3 phase 200V, 20.7kW at 3 phase 400V under batch control
Charged Part Cover Optional unit UN-CV501US
Ambient Derating Derate the rated operational current above 40 degrees C ambient
Standards JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable
US-H30 US-H30 heater load solid state contactor, batch control, standard | Type: Solid state contactor for heater loads | Frame: H30 | Circuit Control Method: Batch control | Specification: Standard | Rated Voltage: AC24-480V | Rated Operational Current AC-1 Class: 30A at -10 to 40 degrees C | Heater Capacity: 6kW at 1 phase 200V, 10.3kW at 3 phase 200V, 20.7kW at 3 phase 400V under batch control | Charged Part Cover: Optional unit UN-CV501US | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable
US-H30HZ US-H30 heater load solid state contactor, batch control, no cooling fin | Type: Solid state contactor for heater loads | Frame: H30 | Circuit Control Method: Batch control | Specification: No cooling fin | Rated Voltage: AC24-480V | Rated Operational Current AC-1 Class: 30A at -10 to 40 degrees C | Heater Capacity: 6kW at 1 phase 200V, 10.3kW at 3 phase 200V, 20.7kW at 3 phase 400V under batch control | Charged Part Cover: Optional unit UN-CV501US | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable
US-H30RM US-H30 heater load solid state contactor, batch control, rail mount only | Type: Solid state contactor for heater loads | Frame: H30 | Circuit Control Method: Batch control | Specification: Rail mount only | Rated Voltage: AC24-480V | Rated Operational Current AC-1 Class: 30A at -10 to 40 degrees C | Heater Capacity: 6kW at 1 phase 200V, 10.3kW at 3 phase 200V, 20.7kW at 3 phase 400V under batch control | Charged Part Cover: Optional unit UN-CV501US | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable
US-H30UF US-H30 heater load solid state contactor, batch control, reduced width | Type: Solid state contactor for heater loads | Frame: H30 | Circuit Control Method: Batch control | Specification: Reduced width | Rated Voltage: AC24-480V | Rated Operational Current AC-1 Class: 30A at -10 to 40 degrees C | Heater Capacity: 6kW at 1 phase 200V, 10.3kW at 3 phase 200V, 20.7kW at 3 phase 400V under batch control | Charged Part Cover: Optional unit UN-CV501US | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable
US-H30DD US-H30 heater load solid state contactor, individual control, standard | Type: Solid state contactor for heater loads | Frame: H30 | Circuit Control Method: Individual control | Specification: Standard | Rated Voltage: AC24-480V | Rated Operational Current AC-1 Class: 30A at -10 to 40 degrees C | Heater Capacity: 6kW at 1 phase 200V, 10.3kW at 3 phase 200V, 20.7kW at 3 phase 400V under batch control | Charged Part Cover: Optional unit UN-CV501US | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable
US-H30DDHZ US-H30 heater load solid state contactor, individual control, no cooling fin | Type: Solid state contactor for heater loads | Frame: H30 | Circuit Control Method: Individual control | Specification: No cooling fin | Rated Voltage: AC24-480V | Rated Operational Current AC-1 Class: 30A at -10 to 40 degrees C | Heater Capacity: 6kW at 1 phase 200V, 10.3kW at 3 phase 200V, 20.7kW at 3 phase 400V under batch control | Charged Part Cover: Optional unit UN-CV501US | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable
US-H30DDRM US-H30 heater load solid state contactor, individual control, rail mount only | Type: Solid state contactor for heater loads | Frame: H30 | Circuit Control Method: Individual control | Specification: Rail mount only | Rated Voltage: AC24-480V | Rated Operational Current AC-1 Class: 30A at -10 to 40 degrees C | Heater Capacity: 6kW at 1 phase 200V, 10.3kW at 3 phase 200V, 20.7kW at 3 phase 400V under batch control | Charged Part Cover: Optional unit UN-CV501US | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable
US-H30DDUF US-H30 heater load solid state contactor, individual control, reduced width | Type: Solid state contactor for heater loads | Frame: H30 | Circuit Control Method: Individual control | Specification: Reduced width | Rated Voltage: AC24-480V | Rated Operational Current AC-1 Class: 30A at -10 to 40 degrees C | Heater Capacity: 6kW at 1 phase 200V, 10.3kW at 3 phase 200V, 20.7kW at 3 phase 400V under batch control | Charged Part Cover: Optional unit UN-CV501US | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable
Solid State ContactorsMitsubishi Electric
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric - US-H30 Heater Load Solid State Contactor (AC24-480V, 30A AC-1)

Brand Mitsubishi Electric·Solid State Contactors

Available part numbers (8)

US-H30, US-H30HZ, US-H30RM, US-H30UF, US-H30DD, US-H30DDHZ, US-H30DDRM, US-H30DDUF
