Mitsubishi Electric - US-H40 Heater Load Solid State Contactor (AC24-480V, 40A AC-1)

Mitsubishi Electric - US-H40 Heater Load Solid State Contactor (AC24-480V, 40A AC-1)

Mitsubishi Electric MS-T/N series US-H40 solid state contactor dedicated to heater loads, suited to injection moulding machines, semiconductor production equipment and similar applications.

Key features

  • Wide main circuit voltage range AC24-480V with rated operational current 40A under AC-1 class between -10 and 40 degrees C, heater capacity 8kW at 1 phase 200V, 13.8kW at 3 phase 200V, 27.7kW at 3 phase 400V under batch control
  • Semiconductor switching gives long life in high frequency switching duty with no switching noise, no wearing parts and clean operation, and a front operation indicator shows the control input state
  • The DD code selects individual control in place of batch control and the HZ code supplies the unit without a cooling fin
  • A charged part protection cover unit UN-CV501US and the power control unit UA-PC are available as options
  • Derate the rated operational current above 40 degrees C ambient
  • JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable

Specifications

Type Solid state contactor for heater loads
Frame H40
Rated Voltage AC24-480V
Rated Operational Current AC-1 Class 40A at -10 to 40 degrees C
Heater Capacity 8kW at 1 phase 200V, 13.8kW at 3 phase 200V, 27.7kW at 3 phase 400V under batch control
Charged Part Cover Optional unit UN-CV501US
Ambient Derating Derate the rated operational current above 40 degrees C ambient
Standards JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable
US-H40 US-H40 heater load solid state contactor, batch control, standard | Type: Solid state contactor for heater loads | Frame: H40 | Circuit Control Method: Batch control | Specification: Standard | Rated Voltage: AC24-480V | Rated Operational Current AC-1 Class: 40A at -10 to 40 degrees C | Heater Capacity: 8kW at 1 phase 200V, 13.8kW at 3 phase 200V, 27.7kW at 3 phase 400V under batch control | Charged Part Cover: Optional unit UN-CV501US | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable
US-H40HZ US-H40 heater load solid state contactor, batch control, no cooling fin | Type: Solid state contactor for heater loads | Frame: H40 | Circuit Control Method: Batch control | Specification: No cooling fin | Rated Voltage: AC24-480V | Rated Operational Current AC-1 Class: 40A at -10 to 40 degrees C | Heater Capacity: 8kW at 1 phase 200V, 13.8kW at 3 phase 200V, 27.7kW at 3 phase 400V under batch control | Charged Part Cover: Optional unit UN-CV501US | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable
US-H40DD US-H40 heater load solid state contactor, individual control, standard | Type: Solid state contactor for heater loads | Frame: H40 | Circuit Control Method: Individual control | Specification: Standard | Rated Voltage: AC24-480V | Rated Operational Current AC-1 Class: 40A at -10 to 40 degrees C | Heater Capacity: 8kW at 1 phase 200V, 13.8kW at 3 phase 200V, 27.7kW at 3 phase 400V under batch control | Charged Part Cover: Optional unit UN-CV501US | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable
US-H40DDHZ US-H40 heater load solid state contactor, individual control, no cooling fin | Type: Solid state contactor for heater loads | Frame: H40 | Circuit Control Method: Individual control | Specification: No cooling fin | Rated Voltage: AC24-480V | Rated Operational Current AC-1 Class: 40A at -10 to 40 degrees C | Heater Capacity: 8kW at 1 phase 200V, 13.8kW at 3 phase 200V, 27.7kW at 3 phase 400V under batch control | Charged Part Cover: Optional unit UN-CV501US | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable
Solid State ContactorsMitsubishi Electric
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric - US-H40 Heater Load Solid State Contactor (AC24-480V, 40A AC-1)

Brand Mitsubishi Electric·Solid State Contactors

Available part numbers (4)

US-H40, US-H40HZ, US-H40DD, US-H40DDHZ

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
US-H40US-H40 heater load solid state contactor, batch control, standard | Type: Solid state contactor for heater loads | Frame: H40 | Circuit Control Method: Batch control | Specification: Standard | Rated Voltage: AC24-480V | Rated Operational Current AC-1 Class: 40A at -10 to 40 degrees C | Heater Capacity: 8kW at 1 phase 200V, 13.8kW at 3 phase 200V, 27.7kW at 3 phase 400V under batch control | Charged Part Cover: Optional unit UN-CV501US | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable
US-H40HZUS-H40 heater load solid state contactor, batch control, no cooling fin | Type: Solid state contactor for heater loads | Frame: H40 | Circuit Control Method: Batch control | Specification: No cooling fin | Rated Voltage: AC24-480V | Rated Operational Current AC-1 Class: 40A at -10 to 40 degrees C | Heater Capacity: 8kW at 1 phase 200V, 13.8kW at 3 phase 200V, 27.7kW at 3 phase 400V under batch control | Charged Part Cover: Optional unit UN-CV501US | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable
US-H40DDUS-H40 heater load solid state contactor, individual control, standard | Type: Solid state contactor for heater loads | Frame: H40 | Circuit Control Method: Individual control | Specification: Standard | Rated Voltage: AC24-480V | Rated Operational Current AC-1 Class: 40A at -10 to 40 degrees C | Heater Capacity: 8kW at 1 phase 200V, 13.8kW at 3 phase 200V, 27.7kW at 3 phase 400V under batch control | Charged Part Cover: Optional unit UN-CV501US | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable
US-H40DDHZUS-H40 heater load solid state contactor, individual control, no cooling fin | Type: Solid state contactor for heater loads | Frame: H40 | Circuit Control Method: Individual control | Specification: No cooling fin | Rated Voltage: AC24-480V | Rated Operational Current AC-1 Class: 40A at -10 to 40 degrees C | Heater Capacity: 8kW at 1 phase 200V, 13.8kW at 3 phase 200V, 27.7kW at 3 phase 400V under batch control | Charged Part Cover: Optional unit UN-CV501US | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive and TUV certified as standard, CCC is not applicable
