Mitsubishi Electric - US-K Three Pole Solid State Contactor (AC100-240V, 100A to 150A)

Mitsubishi Electric - US-K Three Pole Solid State Contactor (AC100-240V, 100A to 150A)

Mitsubishi Electric MS-T/N series US-K three pole solid state contactor for motor and heater loads at rated voltage AC100-240V, covering rated operational currents 100A to 150A under AC-1 class.

Key features

  • The three pole type is supplied only as a three element type; the two element type is not manufactured
  • Semiconductor switching gives long life in high frequency switching duty with no switching noise and no wearing parts
  • Option units include the drive unit UA-DR1, the reversing unit UA-RE and the power control unit UA-PC
  • Three phase capacity figures assume two or three single pole units combined onto a three phase load
  • Derate the rated operational current above 40 degrees C ambient
  • JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard

Specifications

Type Solid state contactor for motor and heater loads
Main Circuit Configuration 3 pole 3 element type
Rated Voltage AC100-240V
Application Note Three phase capacity figures assume two or three single pole units combined onto a three phase load
Ambient Derating Derate the rated operational current above 40 degrees C ambient
Standards JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
US-K100TE US-K100TE solid state contactor, three pole type, 100A AC-1 | Type: Solid state contactor for motor and heater loads | Main Circuit Configuration: 3 pole 3 element type | Rated Voltage: AC100-240V | Rated Operational Current AC-1 Class: 100A | Heater Capacity: 20kW at 1 phase 200V, 34.6kW at 3 phase 200V | Motor Capacity: 15kW at 3 phase 200V | Application Note: Three phase capacity figures assume two or three single pole units combined onto a three phase load | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
US-K120TE US-K120TE solid state contactor, three pole type, 120A AC-1 | Type: Solid state contactor for motor and heater loads | Main Circuit Configuration: 3 pole 3 element type | Rated Voltage: AC100-240V | Rated Operational Current AC-1 Class: 120A | Heater Capacity: 24kW at 1 phase 200V, 41.5kW at 3 phase 200V | Motor Capacity: 15kW at 3 phase 200V | Application Note: Three phase capacity figures assume two or three single pole units combined onto a three phase load | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
US-K150TE US-K150TE solid state contactor, three pole type, 150A AC-1 | Type: Solid state contactor for motor and heater loads | Main Circuit Configuration: 3 pole 3 element type | Rated Voltage: AC100-240V | Rated Operational Current AC-1 Class: 150A | Heater Capacity: 30kW at 1 phase 200V, 52kW at 3 phase 200V | Motor Capacity: 18.5kW at 3 phase 200V | Application Note: Three phase capacity figures assume two or three single pole units combined onto a three phase load | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
Solid State ContactorsMitsubishi Electric
3 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric - US-K Three Pole Solid State Contactor (AC100-240V, 100A to 150A)

Brand Mitsubishi Electric·Solid State Contactors

Available part numbers (3)

US-K100TE, US-K120TE, US-K150TE

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
US-K100TEUS-K100TE solid state contactor, three pole type, 100A AC-1 | Type: Solid state contactor for motor and heater loads | Main Circuit Configuration: 3 pole 3 element type | Rated Voltage: AC100-240V | Rated Operational Current AC-1 Class: 100A | Heater Capacity: 20kW at 1 phase 200V, 34.6kW at 3 phase 200V | Motor Capacity: 15kW at 3 phase 200V | Application Note: Three phase capacity figures assume two or three single pole units combined onto a three phase load | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
US-K120TEUS-K120TE solid state contactor, three pole type, 120A AC-1 | Type: Solid state contactor for motor and heater loads | Main Circuit Configuration: 3 pole 3 element type | Rated Voltage: AC100-240V | Rated Operational Current AC-1 Class: 120A | Heater Capacity: 24kW at 1 phase 200V, 41.5kW at 3 phase 200V | Motor Capacity: 15kW at 3 phase 200V | Application Note: Three phase capacity figures assume two or three single pole units combined onto a three phase load | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
US-K150TEUS-K150TE solid state contactor, three pole type, 150A AC-1 | Type: Solid state contactor for motor and heater loads | Main Circuit Configuration: 3 pole 3 element type | Rated Voltage: AC100-240V | Rated Operational Current AC-1 Class: 150A | Heater Capacity: 30kW at 1 phase 200V, 52kW at 3 phase 200V | Motor Capacity: 18.5kW at 3 phase 200V | Application Note: Three phase capacity figures assume two or three single pole units combined onto a three phase load | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
