Mitsubishi Electric - US-N40 Solid State Contactor (AC100-480V, 40A AC-1)

Mitsubishi Electric - US-N40 Solid State Contactor (AC100-480V, 40A AC-1)

Mitsubishi Electric MS-T/N series US-N40 solid state contactor for motor and heater loads, suited to high frequency switching on conveying lines and similar duty.

Key features

  • Rated voltage AC100-480V with rated operational current 40A under AC-1 class
  • Heater capacity 8kW at 1 phase 200V, 13.8kW at 3 phase 200V and motor capacity 5.5kW at 3 phase 200V
  • Heater capacity 16kW at 1 phase 400V, 27.7kW at 3 phase 400V and motor capacity 11kW at 3 phase 400V
  • Available as a 3 pole 2 element type or, with the TE code, a 3 pole 3 element type, with the CX code adding a CAN terminal
  • Option units include the drive unit UA-DR1, the reversing unit UA-RE and the power control unit UA-PC
  • Derate the rated operational current above 40 degrees C ambient

Specifications

Type Solid state contactor for motor and heater loads
Frame N40
Specification Standard
Rated Voltage AC100-480V
Rated Operational Current AC-1 Class 40A
Heater Capacity 200V 8kW at 1 phase 200V, 13.8kW at 3 phase 200V
Motor Capacity 200V 5.5kW at 3 phase 200V
Heater Capacity 400V 16kW at 1 phase 400V, 27.7kW at 3 phase 400V
Motor Capacity 400V 11kW at 3 phase 400V
Ambient Derating Derate the rated operational current above 40 degrees C ambient
Standards JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
US-N40 US-N40 solid state contactor, 3 pole 2 element | Type: Solid state contactor for motor and heater loads | Frame: N40 | Main Circuit Configuration: 3 pole 2 element type | Terminal Cover: Charged part protection cover | Specification: Standard | Rated Voltage: AC100-480V | Rated Operational Current AC-1 Class: 40A | Heater Capacity 200V: 8kW at 1 phase 200V, 13.8kW at 3 phase 200V | Motor Capacity 200V: 5.5kW at 3 phase 200V | Heater Capacity 400V: 16kW at 1 phase 400V, 27.7kW at 3 phase 400V | Motor Capacity 400V: 11kW at 3 phase 400V | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
US-N40CX US-N40 solid state contactor, 3 pole 2 element, CAN terminal | Type: Solid state contactor for motor and heater loads | Frame: N40 | Main Circuit Configuration: 3 pole 2 element type | Terminal Cover: CAN terminal | Specification: Standard | Rated Voltage: AC100-480V | Rated Operational Current AC-1 Class: 40A | Heater Capacity 200V: 8kW at 1 phase 200V, 13.8kW at 3 phase 200V | Motor Capacity 200V: 5.5kW at 3 phase 200V | Heater Capacity 400V: 16kW at 1 phase 400V, 27.7kW at 3 phase 400V | Motor Capacity 400V: 11kW at 3 phase 400V | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
US-N40TE US-N40 solid state contactor, 3 pole 3 element | Type: Solid state contactor for motor and heater loads | Frame: N40 | Main Circuit Configuration: 3 pole 3 element type | Terminal Cover: Charged part protection cover | Specification: Standard | Rated Voltage: AC100-480V | Rated Operational Current AC-1 Class: 40A | Heater Capacity 200V: 8kW at 1 phase 200V, 13.8kW at 3 phase 200V | Motor Capacity 200V: 5.5kW at 3 phase 200V | Heater Capacity 400V: 16kW at 1 phase 400V, 27.7kW at 3 phase 400V | Motor Capacity 400V: 11kW at 3 phase 400V | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
US-N40TECX US-N40 solid state contactor, 3 pole 3 element, CAN terminal | Type: Solid state contactor for motor and heater loads | Frame: N40 | Main Circuit Configuration: 3 pole 3 element type | Terminal Cover: CAN terminal | Specification: Standard | Rated Voltage: AC100-480V | Rated Operational Current AC-1 Class: 40A | Heater Capacity 200V: 8kW at 1 phase 200V, 13.8kW at 3 phase 200V | Motor Capacity 200V: 5.5kW at 3 phase 200V | Heater Capacity 400V: 16kW at 1 phase 400V, 27.7kW at 3 phase 400V | Motor Capacity 400V: 11kW at 3 phase 400V | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
Solid State ContactorsMitsubishi Electric
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric - US-N40 Solid State Contactor (AC100-480V, 40A AC-1)

Brand Mitsubishi Electric·Solid State Contactors

Available part numbers (4)

US-N40, US-N40CX, US-N40TE, US-N40TECX

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
US-N40US-N40 solid state contactor, 3 pole 2 element | Type: Solid state contactor for motor and heater loads | Frame: N40 | Main Circuit Configuration: 3 pole 2 element type | Terminal Cover: Charged part protection cover | Specification: Standard | Rated Voltage: AC100-480V | Rated Operational Current AC-1 Class: 40A | Heater Capacity 200V: 8kW at 1 phase 200V, 13.8kW at 3 phase 200V | Motor Capacity 200V: 5.5kW at 3 phase 200V | Heater Capacity 400V: 16kW at 1 phase 400V, 27.7kW at 3 phase 400V | Motor Capacity 400V: 11kW at 3 phase 400V | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
US-N40CXUS-N40 solid state contactor, 3 pole 2 element, CAN terminal | Type: Solid state contactor for motor and heater loads | Frame: N40 | Main Circuit Configuration: 3 pole 2 element type | Terminal Cover: CAN terminal | Specification: Standard | Rated Voltage: AC100-480V | Rated Operational Current AC-1 Class: 40A | Heater Capacity 200V: 8kW at 1 phase 200V, 13.8kW at 3 phase 200V | Motor Capacity 200V: 5.5kW at 3 phase 200V | Heater Capacity 400V: 16kW at 1 phase 400V, 27.7kW at 3 phase 400V | Motor Capacity 400V: 11kW at 3 phase 400V | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
US-N40TEUS-N40 solid state contactor, 3 pole 3 element | Type: Solid state contactor for motor and heater loads | Frame: N40 | Main Circuit Configuration: 3 pole 3 element type | Terminal Cover: Charged part protection cover | Specification: Standard | Rated Voltage: AC100-480V | Rated Operational Current AC-1 Class: 40A | Heater Capacity 200V: 8kW at 1 phase 200V, 13.8kW at 3 phase 200V | Motor Capacity 200V: 5.5kW at 3 phase 200V | Heater Capacity 400V: 16kW at 1 phase 400V, 27.7kW at 3 phase 400V | Motor Capacity 400V: 11kW at 3 phase 400V | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
US-N40TECXUS-N40 solid state contactor, 3 pole 3 element, CAN terminal | Type: Solid state contactor for motor and heater loads | Frame: N40 | Main Circuit Configuration: 3 pole 3 element type | Terminal Cover: CAN terminal | Specification: Standard | Rated Voltage: AC100-480V | Rated Operational Current AC-1 Class: 40A | Heater Capacity 200V: 8kW at 1 phase 200V, 13.8kW at 3 phase 200V | Motor Capacity 200V: 5.5kW at 3 phase 200V | Heater Capacity 400V: 16kW at 1 phase 400V, 27.7kW at 3 phase 400V | Motor Capacity 400V: 11kW at 3 phase 400V | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
