Mitsubishi Electric - US-N5SS Solid State Contactor (AC100-240V, 5A AC-1)

Mitsubishi Electric - US-N5SS Solid State Contactor (AC100-240V, 5A AC-1)

Mitsubishi Electric MS-T/N series US-N5SS solid state contactor for motor and heater loads, suited to high frequency switching on conveying lines and similar duty.

Key features

  • Rated voltage AC100-240V with rated operational current 5A under AC-1 class
  • Heater capacity 1kW at 1 phase 200V, 1.7kW at 3 phase 200V and motor capacity 0.4kW at 3 phase 200V
  • Available as a 3 pole 2 element type or, with the TE code, a 3 pole 3 element type
  • Option units include the drive unit UA-DR1, the reversing unit UA-RE and the power control unit UA-PC
  • Derate the rated operational current above 40 degrees C ambient
  • JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard

Specifications

Type Solid state contactor for motor and heater loads
Frame N5SS
Terminal Cover Charged part protection cover
Specification Standard
Rated Voltage AC100-240V
Rated Operational Current AC-1 Class 5A
Heater Capacity 200V 1kW at 1 phase 200V, 1.7kW at 3 phase 200V
Motor Capacity 200V 0.4kW at 3 phase 200V
Ambient Derating Derate the rated operational current above 40 degrees C ambient
Standards JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
US-N5SS US-N5SS solid state contactor, 3 pole 2 element | Type: Solid state contactor for motor and heater loads | Frame: N5SS | Main Circuit Configuration: 3 pole 2 element type | Terminal Cover: Charged part protection cover | Specification: Standard | Rated Voltage: AC100-240V | Rated Operational Current AC-1 Class: 5A | Heater Capacity 200V: 1kW at 1 phase 200V, 1.7kW at 3 phase 200V | Motor Capacity 200V: 0.4kW at 3 phase 200V | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
US-N5SSTE US-N5SS solid state contactor, 3 pole 3 element | Type: Solid state contactor for motor and heater loads | Frame: N5SS | Main Circuit Configuration: 3 pole 3 element type | Terminal Cover: Charged part protection cover | Specification: Standard | Rated Voltage: AC100-240V | Rated Operational Current AC-1 Class: 5A | Heater Capacity 200V: 1kW at 1 phase 200V, 1.7kW at 3 phase 200V | Motor Capacity 200V: 0.4kW at 3 phase 200V | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
Solid State ContactorsMitsubishi Electric
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric - US-N5SS Solid State Contactor (AC100-240V, 5A AC-1)

Brand Mitsubishi Electric·Solid State Contactors

Available part numbers (2)

US-N5SS, US-N5SSTE

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
US-N5SSUS-N5SS solid state contactor, 3 pole 2 element | Type: Solid state contactor for motor and heater loads | Frame: N5SS | Main Circuit Configuration: 3 pole 2 element type | Terminal Cover: Charged part protection cover | Specification: Standard | Rated Voltage: AC100-240V | Rated Operational Current AC-1 Class: 5A | Heater Capacity 200V: 1kW at 1 phase 200V, 1.7kW at 3 phase 200V | Motor Capacity 200V: 0.4kW at 3 phase 200V | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
US-N5SSTEUS-N5SS solid state contactor, 3 pole 3 element | Type: Solid state contactor for motor and heater loads | Frame: N5SS | Main Circuit Configuration: 3 pole 3 element type | Terminal Cover: Charged part protection cover | Specification: Standard | Rated Voltage: AC100-240V | Rated Operational Current AC-1 Class: 5A | Heater Capacity 200V: 1kW at 1 phase 200V, 1.7kW at 3 phase 200V | Motor Capacity 200V: 0.4kW at 3 phase 200V | Ambient Derating: Derate the rated operational current above 40 degrees C ambient | Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard
