• Omron R88L-EC Iron-core Linear Motor (Motor Coil Unit and Magnet Trac)
1 1

Omron R88L-EC Iron-core Linear Motor (Motor Coil Unit and Magnet Trac)

Omron R88L-EC Iron-core Linear Motor (Motor Coil Unit and Magnet Trac)

G5 Series Iron-core Linear Motor.

Key features

  • Motor Coil Unit and Magnet Trac
  • Compatible with R88D-KN[]-ECT-L Servo Drives

Specifications

Series G5 Linear
R88L-EC-FW-0303-ANPC Iron-core coil R88L-EC-FW-0303-ANPC 48 N continuous | Type: Iron-core Motor Coil Unit | Continuous Force: 48 N | Momentary Max Force: 105 N | Series: G5 Linear
R88L-EC-FW-0306-ANPC Iron-core coil R88L-EC-FW-0306-ANPC 96 N continuous | Type: Iron-core Motor Coil Unit | Continuous Force: 96 N | Momentary Max Force: 210 N | Series: G5 Linear
R88L-EC-FW-0606-ANPC Iron-core coil R88L-EC-FW-0606-ANPC 160 N continuous | Type: Iron-core Motor Coil Unit | Continuous Force: 160 N | Momentary Max Force: 400 N | Series: G5 Linear
R88L-EC-FW-0609-ANPC Iron-core coil R88L-EC-FW-0609-ANPC 240 N continuous | Type: Iron-core Motor Coil Unit | Continuous Force: 240 N | Momentary Max Force: 600 N | Series: G5 Linear
R88L-EC-FW-0612-ANPC Iron-core coil R88L-EC-FW-0612-ANPC 320 N continuous | Type: Iron-core Motor Coil Unit | Continuous Force: 320 N | Momentary Max Force: 800 N | Series: G5 Linear
R88L-EC-FW-1112-ANPC Iron-core coil R88L-EC-FW-1112-ANPC 608 N continuous | Type: Iron-core Motor Coil Unit | Continuous Force: 608 N | Momentary Max Force: 1600 N | Series: G5 Linear
R88L-EC-FW-1115-ANPC Iron-core coil R88L-EC-FW-1115-ANPC 760 N continuous | Type: Iron-core Motor Coil Unit | Continuous Force: 760 N | Momentary Max Force: 2000 N | Series: G5 Linear
R88L-EC-FM-03096-A Iron-core magnet trac 96 mm | Type: Iron-core Magnet Trac | Unit Length: 96 mm | Applicable Coil: FW-0303/0306 | Series: G5 Linear
R88L-EC-FM-03144-A Iron-core magnet trac 144 mm | Type: Iron-core Magnet Trac | Unit Length: 144 mm | Applicable Coil: FW-0303/0306 | Series: G5 Linear
R88L-EC-FM-03384-A Iron-core magnet trac 384 mm | Type: Iron-core Magnet Trac | Unit Length: 384 mm | Applicable Coil: FW-0303/0306 | Series: G5 Linear
R88L-EC-FM-06192-A Iron-core magnet trac 192 mm | Type: Iron-core Magnet Trac | Unit Length: 192 mm | Applicable Coil: FW-0606/0609/0612 | Series: G5 Linear
R88L-EC-FM-06288-A Iron-core magnet trac 288 mm | Type: Iron-core Magnet Trac | Unit Length: 288 mm | Applicable Coil: FW-0606/0609/0612 | Series: G5 Linear
R88L-EC-FM-11192-A Iron-core magnet trac 192 mm | Type: Iron-core Magnet Trac | Unit Length: 192 mm | Applicable Coil: FW-1112/1115 | Series: G5 Linear
R88L-EC-FM-11288-A Iron-core magnet trac 288 mm | Type: Iron-core Magnet Trac | Unit Length: 288 mm | Applicable Coil: FW-1112/1115 | Series: G5 Linear
ServomotorsOmron
14 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron R88L-EC Iron-core Linear Motor (Motor Coil Unit and Magnet Trac)

Brand Omron·Servomotors

Available part numbers (14)

R88L-EC-FW-0303-ANPC, R88L-EC-FW-0306-ANPC, R88L-EC-FW-0606-ANPC, R88L-EC-FW-0609-ANPC, R88L-EC-FW-0612-ANPC, R88L-EC-FW-1112-ANPC, R88L-EC-FW-1115-ANPC, R88L-EC-FM-03096-A, R88L-EC-FM-03144-A, R88L-EC-FM-03384-A + 4 more — see full table ↓

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
R88L-EC-FW-0303-ANPCIron-core coil R88L-EC-FW-0303-ANPC 48 N continuous | Type: Iron-core Motor Coil Unit | Continuous Force: 48 N | Momentary Max Force: 105 N | Series: G5 Linear
R88L-EC-FW-0306-ANPCIron-core coil R88L-EC-FW-0306-ANPC 96 N continuous | Type: Iron-core Motor Coil Unit | Continuous Force: 96 N | Momentary Max Force: 210 N | Series: G5 Linear
R88L-EC-FW-0606-ANPCIron-core coil R88L-EC-FW-0606-ANPC 160 N continuous | Type: Iron-core Motor Coil Unit | Continuous Force: 160 N | Momentary Max Force: 400 N | Series: G5 Linear
R88L-EC-FW-0609-ANPCIron-core coil R88L-EC-FW-0609-ANPC 240 N continuous | Type: Iron-core Motor Coil Unit | Continuous Force: 240 N | Momentary Max Force: 600 N | Series: G5 Linear
R88L-EC-FW-0612-ANPCIron-core coil R88L-EC-FW-0612-ANPC 320 N continuous | Type: Iron-core Motor Coil Unit | Continuous Force: 320 N | Momentary Max Force: 800 N | Series: G5 Linear
R88L-EC-FW-1112-ANPCIron-core coil R88L-EC-FW-1112-ANPC 608 N continuous | Type: Iron-core Motor Coil Unit | Continuous Force: 608 N | Momentary Max Force: 1600 N | Series: G5 Linear
R88L-EC-FW-1115-ANPCIron-core coil R88L-EC-FW-1115-ANPC 760 N continuous | Type: Iron-core Motor Coil Unit | Continuous Force: 760 N | Momentary Max Force: 2000 N | Series: G5 Linear
R88L-EC-FM-03096-AIron-core magnet trac 96 mm | Type: Iron-core Magnet Trac | Unit Length: 96 mm | Applicable Coil: FW-0303/0306 | Series: G5 Linear
R88L-EC-FM-03144-AIron-core magnet trac 144 mm | Type: Iron-core Magnet Trac | Unit Length: 144 mm | Applicable Coil: FW-0303/0306 | Series: G5 Linear
R88L-EC-FM-03384-AIron-core magnet trac 384 mm | Type: Iron-core Magnet Trac | Unit Length: 384 mm | Applicable Coil: FW-0303/0306 | Series: G5 Linear
R88L-EC-FM-06192-AIron-core magnet trac 192 mm | Type: Iron-core Magnet Trac | Unit Length: 192 mm | Applicable Coil: FW-0606/0609/0612 | Series: G5 Linear
R88L-EC-FM-06288-AIron-core magnet trac 288 mm | Type: Iron-core Magnet Trac | Unit Length: 288 mm | Applicable Coil: FW-0606/0609/0612 | Series: G5 Linear
R88L-EC-FM-11192-AIron-core magnet trac 192 mm | Type: Iron-core Magnet Trac | Unit Length: 192 mm | Applicable Coil: FW-1112/1115 | Series: G5 Linear
R88L-EC-FM-11288-AIron-core magnet trac 288 mm | Type: Iron-core Magnet Trac | Unit Length: 288 mm | Applicable Coil: FW-1112/1115 | Series: G5 Linear
