• Omron R88M-K G5 Servomotor, 3000 r/min, 100/200 VAC, T/S Incremental Encoder, With brake
1 1

Omron R88M-K G5 Servomotor, 3000 r/min, 100/200 VAC, T/S Incremental Encoder, With brake

Omron R88M-K G5 Servomotor, 3000 r/min, 100/200 VAC, T/S Incremental Encoder, With brake

G5 Series AC Servomotor with incremental encoder.

Key features

  • Compatible with R88D-KN[]-ECT Servo Drives

Specifications

Rated Speed 3000 r/min
Power Supply 100/200 VAC
Encoder T/S Incremental
Brake With brake
Series G5
R88M-K05030T-B R88M-K 3000rpm 100/200 VAC 50W Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 50W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K05030T-BS2 R88M-K 3000rpm 100/200 VAC 50W Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 50W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K10030S-B R88M-K 3000rpm 100/200 VAC 100W Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 100W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K10030S-BS2 R88M-K 3000rpm 100/200 VAC 100W Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 100W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K20030S-B R88M-K 3000rpm 100/200 VAC 200W Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 200W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K20030S-BS2 R88M-K 3000rpm 100/200 VAC 200W Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 200W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K40030S-B R88M-K 3000rpm 100/200 VAC 400W Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 400W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K40030S-BS2 R88M-K 3000rpm 100/200 VAC 400W Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 400W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K10030T-B R88M-K 3000rpm 100/200 VAC 50W Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 50W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K10030T-BS2 R88M-K 3000rpm 100/200 VAC 50W Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 50W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K20030T-B R88M-K 3000rpm 100/200 VAC 100W Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 100W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K20030T-BS2 R88M-K 3000rpm 100/200 VAC 100W Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 100W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K40030T-B R88M-K 3000rpm 100/200 VAC 200W Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 200W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K40030T-BS2 R88M-K 3000rpm 100/200 VAC 200W Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 200W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K75030T-B R88M-K 3000rpm 100/200 VAC 400W Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 400W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K75030T-BS2 R88M-K 3000rpm 100/200 VAC 400W Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 400W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K1K030T-B R88M-K 3000rpm 100/200 VAC 750W Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 750W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K1K030T-BS2 R88M-K 3000rpm 100/200 VAC 750W Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 750W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K1K530T-B R88M-K 3000rpm 100/200 VAC 1kW Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 1kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K1K530T-BS2 R88M-K 3000rpm 100/200 VAC 1kW Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 1kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K2K030T-B R88M-K 3000rpm 100/200 VAC 1.5kW Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 1.5kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K2K030T-BS2 R88M-K 3000rpm 100/200 VAC 1.5kW Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 1.5kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K3K030T-B R88M-K 3000rpm 100/200 VAC 2kW Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 2kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K3K030T-BS2 R88M-K 3000rpm 100/200 VAC 2kW Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 2kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K4K030T-B R88M-K 3000rpm 100/200 VAC 3kW Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 3kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K4K030T-BS2 R88M-K 3000rpm 100/200 VAC 3kW Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 3kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K5K030T-B R88M-K 3000rpm 100/200 VAC 4kW Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 4kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K5K030T-BS2 R88M-K 3000rpm 100/200 VAC 4kW Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 4kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
ServomotorsOmron
28 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron R88M-K G5 Servomotor, 3000 r/min, 100/200 VAC, T/S Incremental Encoder, With brake

Brand Omron·Servomotors

Available part numbers (28)

R88M-K05030T-B, R88M-K05030T-BS2, R88M-K10030S-B, R88M-K10030S-BS2, R88M-K20030S-B, R88M-K20030S-BS2, R88M-K40030S-B, R88M-K40030S-BS2, R88M-K10030T-B, R88M-K10030T-BS2 + 18 more — see full table ↓

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
R88M-K05030T-BR88M-K 3000rpm 100/200 VAC 50W Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 50W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K05030T-BS2R88M-K 3000rpm 100/200 VAC 50W Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 50W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K10030S-BR88M-K 3000rpm 100/200 VAC 100W Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 100W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K10030S-BS2R88M-K 3000rpm 100/200 VAC 100W Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 100W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K20030S-BR88M-K 3000rpm 100/200 VAC 200W Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 200W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K20030S-BS2R88M-K 3000rpm 100/200 VAC 200W Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 200W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K40030S-BR88M-K 3000rpm 100/200 VAC 400W Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 400W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K40030S-BS2R88M-K 3000rpm 100/200 VAC 400W Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 400W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K10030T-BR88M-K 3000rpm 100/200 VAC 50W Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 50W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K10030T-BS2R88M-K 3000rpm 100/200 VAC 50W Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 50W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K20030T-BR88M-K 3000rpm 100/200 VAC 100W Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 100W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K20030T-BS2R88M-K 3000rpm 100/200 VAC 100W Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 100W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K40030T-BR88M-K 3000rpm 100/200 VAC 200W Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 200W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K40030T-BS2R88M-K 3000rpm 100/200 VAC 200W Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 200W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K75030T-BR88M-K 3000rpm 100/200 VAC 400W Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 400W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K75030T-BS2R88M-K 3000rpm 100/200 VAC 400W Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 400W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K1K030T-BR88M-K 3000rpm 100/200 VAC 750W Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 750W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K1K030T-BS2R88M-K 3000rpm 100/200 VAC 750W Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 750W | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K1K530T-BR88M-K 3000rpm 100/200 VAC 1kW Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 1kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K1K530T-BS2R88M-K 3000rpm 100/200 VAC 1kW Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 1kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K2K030T-BR88M-K 3000rpm 100/200 VAC 1.5kW Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 1.5kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K2K030T-BS2R88M-K 3000rpm 100/200 VAC 1.5kW Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 1.5kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K3K030T-BR88M-K 3000rpm 100/200 VAC 2kW Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 2kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K3K030T-BS2R88M-K 3000rpm 100/200 VAC 2kW Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 2kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K4K030T-BR88M-K 3000rpm 100/200 VAC 3kW Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 3kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K4K030T-BS2R88M-K 3000rpm 100/200 VAC 3kW Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 3kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
R88M-K5K030T-BR88M-K 3000rpm 100/200 VAC 4kW Straight shaft without key With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 4kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft without key
R88M-K5K030T-BS2R88M-K 3000rpm 100/200 VAC 4kW Straight shaft with key and tap With brake | Rated Speed: 3000 r/min | Power Supply: 100/200 VAC | Rated Output: 4kW | Encoder: T/S Incremental | Brake: With brake | Series: G5 | Shaft: Straight shaft with key and tap
