• OSG 688206K Coated End Mill
1 1

OSG 688206K Coated End Mill

OSG 688206K Coated End Mill

OSG 688206K Coated End Mill is a coated carbide cutting tool designed for precision milling operations, sourced direct from Korea.

Key features

  • End mills of this type are commonly used in CNC machining centers to profile, slot, and contour ferrous and non-ferrous workpieces across metalworking and tooling applications
311-3509 MPN: 688206K | 4F-3MM(TICN-EMS)(688206K) | Spec: 3 | Flute Length: 10(10) | Overall Length: 55(50) | Product Name: 4-Flute Coating | Shank Diameter: 6
311-3518 MPN: 688207K | 4F-3.5MM (TICN-EMS)(688207K) | Spec: 3.5 | Flute Length: 12 | Overall Length: 60 | Product Name: Coated 4F | Shank Diameter: 8
311-3527 MPN: 688208K | 4F-4MM(TICN-EMS)(688208K) | Spec: 4 | Flute Length: 12 | Overall Length: 60 | Product Name: Coated 4F | Shank Diameter: 8
311-3536 MPN: 688209K | 4F-4.5MM(TICN-EMS)(688209K) | Spec: 4.5 | Flute Length: 15 | Overall Length: 65(60) | Product Name: Coated 4F | Shank Diameter: 8
311-3545 MPN: 688210K | 4F-5MM(TICN-EMS)(688210K) | Spec: 5 | Flute Length: 15 | Overall Length: 65(60) | Product Name: Coated 4F | Shank Diameter: 8
311-3554 MPN: 688211K | 4F-5.5MM (TICN-EMS)(688211K) | Spec: 5.5 | Flute Length: 15 | Overall Length: 65(60) | Product Name: Coated 4F | Shank Diameter: 8
311-3563 MPN: 688212K | 4F-6MM(TICN-EMS)(688212K) | Spec: 6 | Flute Length: 15 | Overall Length: 65(60) | Product Name: Coated 4F | Shank Diameter: 8
311-3572 MPN: 688213K | 4F-6.5MM (TICN-EMS)(688213K) | Spec: 6.5 | Flute Length: 20 | Overall Length: 75(60) | Product Name: Coating 4F | Shank Diameter: 10
311-3581 MPN: 688215K | 4F-7.5MM (TICN-EMS)(688215K) | Spec: 7.5 | Flute Length: 20 | Overall Length: 75(60) | Product Name: Coated 4F | Shank Diameter: 10
311-3590 MPN: 688214K | 4F-7MM(TICN-EMS)(688214K) | Spec: 7 | Flute Length: 20 | Overall Length: 75(60) | Product Name: Coated 4F | Shank Diameter: 10
311-3606 MPN: 688217K | 4F-8.5MM (TICN-EMS)(688217K) | Spec: 8.5 | Flute Length: 25 | Overall Length: 80(70) | Product Name: Coated 4F | Shank Diameter: 10
311-3615 MPN: 688216K | 4F-8MM(TICN-EMS)(688216K) | Spec: 8 | Flute Length: 20 | Overall Length: 75(60) | Product Name: Coated 4F | Shank Diameter: 10
311-3624 MPN: 688219K | 4F-9.5MM (TICN-EMS)(688219K) | Spec: 9.5 | Flute Length: 25 | Overall Length: 80(70) | Product Name: Coating 4F | Shank d: 10
311-3633 MPN: 688218K | 4F-9MM(TICN-EMS)(688218K) | Spec: 9 | Flute Length: 25 | Overall Length: 80(70) | Product Name: Coated 4F | Shank Diameter: 10
311-3642 MPN: 688220K | 4F-10MM(TICN-EMS)(688220K) | Spec: 10 | Flute Length: 25 | Overall Length: 80(70) | Type: Coated 4F | Shank d: 10
311-3651 MPN: 688221K | 4F-11MM(TICN-EMS)(688221K) | Spec: 11 | Flute Length: 30 | Overall Length: 90(80) | Product Name: Coated 4F | Shank Diameter: 12
311-3660 MPN: 688222K | 4F-12MM(TICN-EMS)(688222K) | Spec: 12 | Flute Length: 30 | Overall Length: 90(80) | Product Name: Coated 4F | Shank Diameter: 12
311-3679 MPN: 688223K | 4F-13MM(TICN-EMS)(688223K) | Spec: 13 | Flute Length: 35 | Overall Length: 95(85) | Product Name: Coated 4F | Shank Diameter: 12
311-3688 MPN: 688224K | 4F-14MM(TICN-EMS)(688224K) | Spec: 14 | Flute Length: 35 | Overall Length: 100(90) | Description: Coated 4F | Shank Diameter: 16
311-3697 MPN: 688225K | 4F-15MM(TICN-EMS)(688225K) | Spec: 15 | Flute Length: 40 | Overall Length: 105(95) | Product Name: Coated 4F | Shank Diameter: 16
311-3703 MPN: 688226K | 4F-16MM(TICN-EMS)(688226K) | Spec: 16 | Flute Length: 40 | Overall Length: 105(95) | Product Name: Coating 4F | Shank d: 16
311-3712 MPN: 688227K | 4F-17MM(TICN-EMS)(688227K) | Spec: 17 | Flute Length: 40 | Overall Length: 105(95) | Product Name: Coated 4F | Shank Diameter: 16
311-3721 MPN: 688228K | 4F-18MM(TICN-EMS)(688228K) | Spec: 18 | Flute Length: 40 | Overall Length: 105(95) | Product Name: Coated 4F | Shank Diameter: 16
311-3730 MPN: 688229K | 4F-19MM (TICN-EMS)(688229K) | Spec: 19 | Flute Length: 45 | Overall Length: 115(110) | Product Name: Coated 4F | Shank Diameter: 20
311-3749 MPN: 688230K | 4F-20MM(TICN-EMS)(688230K) | Spec: 20 | Flute Length: 45 | Overall Length: 115(110) | Product Name: Coated 4F | Shank Diameter: 20
311-3758 MPN: 688231K | 4F-21MM(TICN-EMS)(688231K) | Spec: 21 | Flute Length: 45 | Overall Length: 115(110) | Product Name: Coated 4F | Shank Diameter: 20
311-3767 MPN: 688232K | 4F-22MM(TICN-EMS)(688232K) | Spec: 22 | Flute Length: 45 | Overall Length: 115(110) | Product Name: Coated 4F | Shank d: 20
311-3776 MPN: 688233K | 4F-23MM(TICN-EMS)(688233K) | Spec: 23 | Flute Length: 50 | Overall Length: 125(120) | Product Name: Coating 4F | Shank d: 25
311-3785 MPN: 688234K | 4F-24MM(TICN-EMS)(688234K) | Spec: 24 | Flute Length: 50 | Overall Length: 125(120) | Product Name: Coated 4F | Shank Diameter: 25
311-3794 MPN: 688235K | 4F-25MM (TICN-EMS)(688235K) | Spec: 25 | Flute Length: 50 | Overall Length: 125(120) | Product Name: Coated 4F | Shank Diameter: 25
311-3800 MPN: 688236K | 4F-26MM (TICN-EMS)(688236K) | Spec: 26 | Flute Length: 50 | Overall Length: 125(120) | Description: Coated 4-Flute | Shank Diameter: 25
311-3819 MPN: 688237K | 4F-27MM (TICN-EMS)(688237K) | Spec: 27 | Flute Length: 55 | Overall Length: 125 | Product Name: Coating 4F | Shank d: 25
311-3828 MPN: 688238K | 4F-28MM (TICN-EMS)(688238K) | Spec: 28 | Flute Length: 55 | Overall Length: 125 | Product Name: Coated 4F | Shank Diameter: 25
311-3846 MPN: 688240K | 4F-30MM (TICN-EMS)(688240K) | Spec: 30 | Flute Length: 55 | Overall Length: 125 | Product Name: Coated 4F | Shank Diameter: 25
311-3855 MPN: 688242K | 4F-32MM (TICN-EMS)(688242K) | Spec: 32 | Flute Length: 60 | Overall Length: 145 | Product Name: Coated 4F | Shank Diameter: 32
311-3873 MPN: 688250K | 4F-40MM(TICN-EMS)(688250K) | Spec: 40 | Flute Length: 65 | Overall Length: 150 | Description: Coated 4-Flute | Shank Diameter: 32
313-8012 MPN: 688205K | 4F-2.5MM(TICN-EMS)(688205K) | Spec: 2.5 | Flute Length: 7(10) | Overall Length: 55(50) | Product Name: Coated 4F | Shank Diameter: 6
313-8049 MPN: 688243K | 4F-33MM(TICN-EMS)(688243K) | Spec: 33 | Flute Length: 60 | Overall Length: 145 | Product Name: Coated 4F | Shank Diameter: 32
313-8216 MPN: 688245K | 4F-35MM(TiCN-EMS)(688245K) | Spec: 35 | Flute Length: 60 | Overall Length: 145 | Product Name: Coated 4F | Shank Diameter: 32
313-8225 MPN: 688246K | 4F-36MM(TICN-EMS)(688246K) | Spec: 36 | Flute Length: 65 | Overall Length: 150 | Product Name: Coated 4F | Shank d: 32
313-8234 MPN: 688247K | 4F-37MM(TICN-EMS)(688247K) | Spec: 37 | Flute Length: 65 | Overall Length: 150 | Product Name: Coated 4F | Shank Diameter: 32
313-8243 MPN: 688248K | 4F-38MM(TICN-EMS)(688248K) | Spec: 38 | Flute Length: 65 | Overall Length: 150 | Product: Coated 4F | Shank Diameter: 32
313-8252 MPN: 688249K | 4F-39MM(TICN-EMS)(688249K) | Spec: 39 | Flute Length: 65 | Overall Length: 150 | Product Name: Coated 4F | Shank d: 32
313-8368 MPN: 688203K | 4F-2MM(TICN-EMS)(688203K) | Spec: 2 | Flute Length: 6 | Overall Length: 55 | Product Name: Coated 4F | Shank Diameter: 6
End MillsOSG
44 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

OSG 688206K Coated End Mill

Brand OSG·End Mills

Available part numbers (44)

311-3509, 311-3518, 311-3527, 311-3536, 311-3545, 311-3554, 311-3563, 311-3572, 311-3581, 311-3590 + 34 more — see full table ↓

How to order

Send the OSG part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
311-3509MPN: 688206K | 4F-3MM(TICN-EMS)(688206K) | Spec: 3 | Flute Length: 10(10) | Overall Length: 55(50) | Product Name: 4-Flute Coating | Shank Diameter: 6
311-3518MPN: 688207K | 4F-3.5MM (TICN-EMS)(688207K) | Spec: 3.5 | Flute Length: 12 | Overall Length: 60 | Product Name: Coated 4F | Shank Diameter: 8
311-3527MPN: 688208K | 4F-4MM(TICN-EMS)(688208K) | Spec: 4 | Flute Length: 12 | Overall Length: 60 | Product Name: Coated 4F | Shank Diameter: 8
311-3536MPN: 688209K | 4F-4.5MM(TICN-EMS)(688209K) | Spec: 4.5 | Flute Length: 15 | Overall Length: 65(60) | Product Name: Coated 4F | Shank Diameter: 8
311-3545MPN: 688210K | 4F-5MM(TICN-EMS)(688210K) | Spec: 5 | Flute Length: 15 | Overall Length: 65(60) | Product Name: Coated 4F | Shank Diameter: 8
311-3554MPN: 688211K | 4F-5.5MM (TICN-EMS)(688211K) | Spec: 5.5 | Flute Length: 15 | Overall Length: 65(60) | Product Name: Coated 4F | Shank Diameter: 8
311-3563MPN: 688212K | 4F-6MM(TICN-EMS)(688212K) | Spec: 6 | Flute Length: 15 | Overall Length: 65(60) | Product Name: Coated 4F | Shank Diameter: 8
311-3572MPN: 688213K | 4F-6.5MM (TICN-EMS)(688213K) | Spec: 6.5 | Flute Length: 20 | Overall Length: 75(60) | Product Name: Coating 4F | Shank Diameter: 10
311-3581MPN: 688215K | 4F-7.5MM (TICN-EMS)(688215K) | Spec: 7.5 | Flute Length: 20 | Overall Length: 75(60) | Product Name: Coated 4F | Shank Diameter: 10
311-3590MPN: 688214K | 4F-7MM(TICN-EMS)(688214K) | Spec: 7 | Flute Length: 20 | Overall Length: 75(60) | Product Name: Coated 4F | Shank Diameter: 10
311-3606MPN: 688217K | 4F-8.5MM (TICN-EMS)(688217K) | Spec: 8.5 | Flute Length: 25 | Overall Length: 80(70) | Product Name: Coated 4F | Shank Diameter: 10
311-3615MPN: 688216K | 4F-8MM(TICN-EMS)(688216K) | Spec: 8 | Flute Length: 20 | Overall Length: 75(60) | Product Name: Coated 4F | Shank Diameter: 10
311-3624MPN: 688219K | 4F-9.5MM (TICN-EMS)(688219K) | Spec: 9.5 | Flute Length: 25 | Overall Length: 80(70) | Product Name: Coating 4F | Shank d: 10
311-3633MPN: 688218K | 4F-9MM(TICN-EMS)(688218K) | Spec: 9 | Flute Length: 25 | Overall Length: 80(70) | Product Name: Coated 4F | Shank Diameter: 10
311-3642MPN: 688220K | 4F-10MM(TICN-EMS)(688220K) | Spec: 10 | Flute Length: 25 | Overall Length: 80(70) | Type: Coated 4F | Shank d: 10
311-3651MPN: 688221K | 4F-11MM(TICN-EMS)(688221K) | Spec: 11 | Flute Length: 30 | Overall Length: 90(80) | Product Name: Coated 4F | Shank Diameter: 12
311-3660MPN: 688222K | 4F-12MM(TICN-EMS)(688222K) | Spec: 12 | Flute Length: 30 | Overall Length: 90(80) | Product Name: Coated 4F | Shank Diameter: 12
311-3679MPN: 688223K | 4F-13MM(TICN-EMS)(688223K) | Spec: 13 | Flute Length: 35 | Overall Length: 95(85) | Product Name: Coated 4F | Shank Diameter: 12
311-3688MPN: 688224K | 4F-14MM(TICN-EMS)(688224K) | Spec: 14 | Flute Length: 35 | Overall Length: 100(90) | Description: Coated 4F | Shank Diameter: 16
311-3697MPN: 688225K | 4F-15MM(TICN-EMS)(688225K) | Spec: 15 | Flute Length: 40 | Overall Length: 105(95) | Product Name: Coated 4F | Shank Diameter: 16
311-3703MPN: 688226K | 4F-16MM(TICN-EMS)(688226K) | Spec: 16 | Flute Length: 40 | Overall Length: 105(95) | Product Name: Coating 4F | Shank d: 16
311-3712MPN: 688227K | 4F-17MM(TICN-EMS)(688227K) | Spec: 17 | Flute Length: 40 | Overall Length: 105(95) | Product Name: Coated 4F | Shank Diameter: 16
311-3721MPN: 688228K | 4F-18MM(TICN-EMS)(688228K) | Spec: 18 | Flute Length: 40 | Overall Length: 105(95) | Product Name: Coated 4F | Shank Diameter: 16
311-3730MPN: 688229K | 4F-19MM (TICN-EMS)(688229K) | Spec: 19 | Flute Length: 45 | Overall Length: 115(110) | Product Name: Coated 4F | Shank Diameter: 20
311-3749MPN: 688230K | 4F-20MM(TICN-EMS)(688230K) | Spec: 20 | Flute Length: 45 | Overall Length: 115(110) | Product Name: Coated 4F | Shank Diameter: 20
311-3758MPN: 688231K | 4F-21MM(TICN-EMS)(688231K) | Spec: 21 | Flute Length: 45 | Overall Length: 115(110) | Product Name: Coated 4F | Shank Diameter: 20
311-3767MPN: 688232K | 4F-22MM(TICN-EMS)(688232K) | Spec: 22 | Flute Length: 45 | Overall Length: 115(110) | Product Name: Coated 4F | Shank d: 20
311-3776MPN: 688233K | 4F-23MM(TICN-EMS)(688233K) | Spec: 23 | Flute Length: 50 | Overall Length: 125(120) | Product Name: Coating 4F | Shank d: 25
311-3785MPN: 688234K | 4F-24MM(TICN-EMS)(688234K) | Spec: 24 | Flute Length: 50 | Overall Length: 125(120) | Product Name: Coated 4F | Shank Diameter: 25
311-3794MPN: 688235K | 4F-25MM (TICN-EMS)(688235K) | Spec: 25 | Flute Length: 50 | Overall Length: 125(120) | Product Name: Coated 4F | Shank Diameter: 25
311-3800MPN: 688236K | 4F-26MM (TICN-EMS)(688236K) | Spec: 26 | Flute Length: 50 | Overall Length: 125(120) | Description: Coated 4-Flute | Shank Diameter: 25
311-3819MPN: 688237K | 4F-27MM (TICN-EMS)(688237K) | Spec: 27 | Flute Length: 55 | Overall Length: 125 | Product Name: Coating 4F | Shank d: 25
311-3828MPN: 688238K | 4F-28MM (TICN-EMS)(688238K) | Spec: 28 | Flute Length: 55 | Overall Length: 125 | Product Name: Coated 4F | Shank Diameter: 25
311-3846MPN: 688240K | 4F-30MM (TICN-EMS)(688240K) | Spec: 30 | Flute Length: 55 | Overall Length: 125 | Product Name: Coated 4F | Shank Diameter: 25
311-3855MPN: 688242K | 4F-32MM (TICN-EMS)(688242K) | Spec: 32 | Flute Length: 60 | Overall Length: 145 | Product Name: Coated 4F | Shank Diameter: 32
311-3873MPN: 688250K | 4F-40MM(TICN-EMS)(688250K) | Spec: 40 | Flute Length: 65 | Overall Length: 150 | Description: Coated 4-Flute | Shank Diameter: 32
313-8012MPN: 688205K | 4F-2.5MM(TICN-EMS)(688205K) | Spec: 2.5 | Flute Length: 7(10) | Overall Length: 55(50) | Product Name: Coated 4F | Shank Diameter: 6
313-8049MPN: 688243K | 4F-33MM(TICN-EMS)(688243K) | Spec: 33 | Flute Length: 60 | Overall Length: 145 | Product Name: Coated 4F | Shank Diameter: 32
313-8216MPN: 688245K | 4F-35MM(TiCN-EMS)(688245K) | Spec: 35 | Flute Length: 60 | Overall Length: 145 | Product Name: Coated 4F | Shank Diameter: 32
313-8225MPN: 688246K | 4F-36MM(TICN-EMS)(688246K) | Spec: 36 | Flute Length: 65 | Overall Length: 150 | Product Name: Coated 4F | Shank d: 32
313-8234MPN: 688247K | 4F-37MM(TICN-EMS)(688247K) | Spec: 37 | Flute Length: 65 | Overall Length: 150 | Product Name: Coated 4F | Shank Diameter: 32
313-8243MPN: 688248K | 4F-38MM(TICN-EMS)(688248K) | Spec: 38 | Flute Length: 65 | Overall Length: 150 | Product: Coated 4F | Shank Diameter: 32
313-8252MPN: 688249K | 4F-39MM(TICN-EMS)(688249K) | Spec: 39 | Flute Length: 65 | Overall Length: 150 | Product Name: Coated 4F | Shank d: 32
313-8368MPN: 688203K | 4F-2MM(TICN-EMS)(688203K) | Spec: 2 | Flute Length: 6 | Overall Length: 55 | Product Name: Coated 4F | Shank Diameter: 6
