Qlight QDML-IOL Multi-Color Programmable LED Work Light with IO-Link

Qlight QDML-IOL Multi-Color Programmable LED Work Light with IO-Link

Multi-color programmable LED light bar with IO-Link communication, available in lengths from 125 mm to 910 mm.

Key features

  • IO-Link V1.1 communication, data transmission rate 38,400 bps (COM2)
  • Plug & play operation via international standard M12 connector
  • Signaling device optimized for Industry 4.0 smart manufacturing
  • 8 preset color modes plus user-defined settings, configurable via IO-Link
  • Supports external trigger mode (3 trigger inputs) and IO-Link mode
  • IP67 protection for use in various environments

Specifications

Voltage DC24V (operating range DC18V-30V, Supply Class 2)
Light colors Red, Green, Yellow, Blue, White, Orange, Pink, custom
Lens color Transparent
Beam angle (FWHM) 120°
Material Housing-Al, Lens-PU
Protection rating IP67
Ambient temperature 0 to +50 °C
Connector M12x1 5-pin
Dimension Width 10 mm, Height 40 mm
Certificates IO-Link, CE, UKCA
Mounting Magnetic holder, mounting bracket
QDML-IOL-125 Length: 125 mm | Power: 3W | Weight: 0.115kg
QDML-IOL-250 Length: 250 mm | Power: 5W | Weight: 0.21kg
QDML-IOL-480 Length: 480 mm | Power: 9.1W | Weight: 0.39kg
QDML-IOL-700 Length: 700 mm | Power: 13.4W | Weight: 0.55kg
QDML-IOL-910 Length: 910 mm | Power: 17.5W | Weight: 0.70kg
LED Work LightsQlight
5 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Qlight QDML-IOL Multi-Color Programmable LED Work Light with IO-Link

Brand Qlight·LED Work Lights

Available part numbers (5)

QDML-IOL-125, QDML-IOL-250, QDML-IOL-480, QDML-IOL-700, QDML-IOL-910

How to order

Send the Qlight part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
QDML-IOL-125Length: 125 mm | Power: 3W | Weight: 0.115kg
QDML-IOL-250Length: 250 mm | Power: 5W | Weight: 0.21kg
QDML-IOL-480Length: 480 mm | Power: 9.1W | Weight: 0.39kg
QDML-IOL-700Length: 700 mm | Power: 13.4W | Weight: 0.55kg
QDML-IOL-910Length: 910 mm | Power: 17.5W | Weight: 0.70kg
