Qlight QN / QN-H Explosion-Proof Electronic Sounder, 118 / 123 dB

Qlight QN / QN-H Explosion-Proof Electronic Sounder, 118 / 123 dB

Flameproof aluminum alarm horn sounder with up to 123 dB output for Zone 1/2.

Key features

  • Explosion-proof alarm horn sounder
  • 25 selectable sounds; volume adjustable
  • Aluminum housing, IP66 fully enclosed
  • Customization: external sound selection (-LC), 2 entries, 3/4" NPT/M20/M25 entry

Specifications

Explosion protection Ex db IIC T6/T5 Gb
Protection rating IP66
Ambient temperature -40 to +70 °C (T5), +55 °C (T6)
Cable entry 1/2" NPT
Housing color Red
Certificates ATEX, IECEx, NEPSI, CCC, KCs
Usage area Zone 1, Zone 2
Transistor input NPN
Materials Housing Al, horn PC
Mounting Wall mount
QN Sound: WS/WP max. 118 dB, WA 116 dB, WV 110-115 dB | Voltage: DC12V-24V (max. 1.15A), AC110V-230V (max. 300mA) | Weight: 5.15-5.17kg
QN-H Sound: WS/WP/WM max. 123 dB, WA 121 dB, WV 115-120 dB | Voltage: DC12V-24V (max. 2.9A), AC110V-230V (max. 470mA) | Weight: 5.15-5.17kg
Explosion-Proof HornsQlight
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Qlight QN / QN-H Explosion-Proof Electronic Sounder, 118 / 123 dB

Brand Qlight·Explosion-Proof Horns

Available part numbers (2)

QN, QN-H

How to order

Send the Qlight part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
QNSound: WS/WP max. 118 dB, WA 116 dB, WV 110-115 dB | Voltage: DC12V-24V (max. 1.15A), AC110V-230V (max. 300mA) | Weight: 5.15-5.17kg
QN-HSound: WS/WP/WM max. 123 dB, WA 121 dB, WV 115-120 dB | Voltage: DC12V-24V (max. 2.9A), AC110V-230V (max. 470mA) | Weight: 5.15-5.17kg
