SHC HSV Suction Line Filter (10A to 100A)

HSV suction line filters are installed in the pump suction line outside the tank, allowing element service without draining the reservoir.

Key features

External suction line filter
Ports 3/8 to 4 in
Flow 18 to 1250 L/min
HVID / HEID indicators available

Specifications

Mounting	In-line, outside tank
Brand	SHC
Manufacturer	Sejin Hydraulics Mfg. Co. (Korea)
Product type	Suction Line Filter
Series	HSV
Ordering	By printed part number
Source	SHC E-Catalog 2018 V1.0, p.38

HSV-10A		Port: 3/8 in \| H: 170 mm \| D: 90 mm \| Flow: 18 L/min
HSV-15A		Port: 1/2 in \| H: 170 mm \| D: 90 mm \| Flow: 30 L/min
HSV-20A		Port: 3/4 in \| H: 190 mm \| D: 115 mm \| Flow: 45 L/min
HSV-25A		Port: 1 in \| H: 190 mm \| D: 115 mm \| Flow: 90 L/min
HSV-32A		Port: 1-1/4 in \| H: 257 mm \| D: 140 mm \| Flow: 150 L/min
HSV-40A		Port: 1-1/2 in \| H: 257 mm \| D: 140 mm \| Flow: 205 L/min
HSV-50A		Port: 2 in \| H: 284 mm \| D: 160 mm \| Flow: 320 L/min
HSV-65A		Port: 2-1/2 in \| H: 301 mm \| D: 180 mm \| Flow: 550 L/min
HSV-80A		Port: 3 in \| H: 301 mm \| D: 180 mm \| Flow: 730 L/min
HSV-100A		Port: 4 in \| H: 395 mm \| D: 232 mm \| Flow: 1250 L/min

Suction Line FilterSHC

10 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SHC HSV Suction Line Filter (10A to 100A)

Brand SHC·Suction Line Filter

Available part numbers (10)

HSV-10A, HSV-15A, HSV-20A, HSV-25A, HSV-32A, HSV-40A, HSV-50A, HSV-65A, HSV-80A, HSV-100A

How to order

Send the SHC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
