SHC SAP Air Breather (PT 3/8 to PT 10, flanged to 250A)

SAP air breathers fit hydraulic reservoir tops to filter incoming air; threaded, internal-thread and KS 5K flanged versions cover small to very large tanks.

Key features

Threaded SAP, internal-thread SAP-I and flanged SAP-F versions
Air flow from 0.08 to 18 m3/min
Sizes from PT 3/8 to PT 10 and 100A to 250A flange
Compact plastic SAP-03S-PP model available

Specifications

Mounting	Tank top
Connection	PT thread or KS 5K flange
Air flow	0.08 to 18 m3/min
Brand	SHC
Manufacturer	Sejin Hydraulics Mfg. Co. (Korea)
Product type	Air Breather
Source	SHC E-Catalog 2018 V1.0, p.11

SAP-03S-PP		Type: SAP \| Connection: PT 3/8 \| D: 50 mm \| H: 60 mm \| Air flow: 0.08 m3/min
SAP-03		Type: SAP \| Connection: PT 3/8 \| D: 76 mm \| H: 64 mm \| Air flow: 0.10 m3/min
SAP-04		Type: SAP \| Connection: PT 1/2 \| D: 76 mm \| H: 78 mm \| Air flow: 0.15 m3/min
SAP-06		Type: SAP \| Connection: PT 3/4 \| D: 76 mm \| H: 83 mm \| Air flow: 0.20 m3/min
SAP-08		Type: SAP \| Connection: PT 1 \| D: 100 mm \| H: 88 mm \| Air flow: 0.40 m3/min
SAP-10		Type: SAP \| Connection: PT 1-1/4 \| D: 100 mm \| H: 100 mm \| Air flow: 0.65 m3/min
SAP-12		Type: SAP \| Connection: PT 1-1/2 \| D: 116 mm \| H: 112 mm \| Air flow: 0.90 m3/min
SAP-16		Type: SAP \| Connection: PT 2 \| D: 131 mm \| H: 116 mm \| Air flow: 2.00 m3/min
SAP-20		Type: SAP \| Connection: PT 2-1/2 \| D: 174 mm \| H: 125 mm \| Air flow: 4.00 m3/min
SAP-24		Type: SAP \| Connection: PT 3 \| D: 174 mm \| H: 125 mm \| Air flow: 4.00 m3/min
SAP-32		Type: SAP \| Connection: PT 4 \| D: 222 mm \| H: 155 mm \| Air flow: 6.00 m3/min
SAP-40		Type: SAP \| Connection: PT 5 \| D: 270 mm \| H: 265 mm \| Air flow: 10.00 m3/min
SAP-48		Type: SAP \| Connection: PT 6 \| D: 330 mm \| H: 265 mm \| Air flow: 10.00 m3/min
SAP-64		Type: SAP \| Connection: PT 8 \| D: 330 mm \| H: 290 mm \| Air flow: 14.00 m3/min
SAP-80		Type: SAP \| Connection: PT 10 \| D: 370 mm \| H: 335 mm \| Air flow: 18.00 m3/min
SAP-I-32-SA		Type: SAP-I \| Connection: PT 4 \| D: 222 mm \| H: 155 mm \| Air flow: 6.00 m3/min
SAP-I-40-SA		Type: SAP-I \| Connection: PT 5 \| D: 270 mm \| H: 265 mm \| Air flow: 10.00 m3/min
SAP-I-48-SA		Type: SAP-I \| Connection: PT 6 \| D: 330 mm \| H: 265 mm \| Air flow: 10.00 m3/min
SAP-I-64-SA		Type: SAP-I \| Connection: PT 8 \| D: 330 mm \| H: 265 mm \| Air flow: 14.00 m3/min
SAP-I-80-SA		Type: SAP-I \| Connection: PT 10 \| D: 370 mm \| H: 335 mm \| Air flow: 18.00 m3/min
SAP-F-32		Type: SAP-F \| Connection: KS 5K 100A flange \| D: 330 mm \| H: 335 mm \| Air flow: 6.00 m3/min
SAP-F-40		Type: SAP-F \| Connection: KS 5K 125A flange \| D: 330 mm \| H: 335 mm \| Air flow: 10.00 m3/min
SAP-F-48		Type: SAP-F \| Connection: KS 5K 150A flange \| D: 330 mm \| H: 335 mm \| Air flow: 10.00 m3/min
SAP-F-64		Type: SAP-F \| Connection: KS 5K 200A flange \| D: 370 mm \| H: 375 mm \| Air flow: 14.00 m3/min
SAP-F-80		Type: SAP-F \| Connection: KS 5K 250A flange \| D: 460 mm \| H: 405 mm \| Air flow: 18.00 m3/min

Air BreatherSHC

25 product codes available in this family
