SHC SNAB Air Breather (PT 1/4 to PT 2)

SHC SNAB Air Breather (PT 1/4 to PT 2)

SNAB air breathers are compact threaded breathers for hydraulic tanks and gearboxes, filtering air entering the reservoir.

Key features

  • Compact threaded breather
  • PT 1/4 to PT 2 sizes
  • Air flow 0.06 to 2.0 m3/min
  • Simple screw-in installation

Specifications

Mounting Threaded on tank top
Connection PT 1/4 to PT 2
Brand SHC
Manufacturer Sejin Hydraulics Mfg. Co. (Korea)
Product type Air Breather
Series SNAB
Source SHC E-Catalog 2018 V1.0, p.12
SNAB-02 Thread: PT 1/4 | D: 48 mm | H: 55 mm | Air flow: 0.06 m3/min
SNAB-03 Thread: PT 3/8 | D: 48 mm | H: 64 mm | Air flow: 0.10 m3/min
SNAB-04 Thread: PT 1/2 | D: 76 mm | H: 80 mm | Air flow: 0.15 m3/min
SNAB-06 Thread: PT 3/4 | D: 76 mm | H: 80 mm | Air flow: 0.20 m3/min
SNAB-08 Thread: PT 1 | D: 100 mm | H: 95 mm | Air flow: 0.40 m3/min
SNAB-10 Thread: PT 1-1/4 | D: 100 mm | H: 95 mm | Air flow: 0.65 m3/min
SNAB-12 Thread: PT 1-1/2 | D: 100 mm | H: 95 mm | Air flow: 0.90 m3/min
SNAB-16 Thread: PT 2 | D: 100 mm | H: 95 mm | Air flow: 2.00 m3/min
Air BreatherSHC
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SHC SNAB Air Breather (PT 1/4 to PT 2)

Brand SHC·Air Breather

Available part numbers (8)

SNAB-02, SNAB-03, SNAB-04, SNAB-06, SNAB-08, SNAB-10, SNAB-12, SNAB-16

How to order

Send the SHC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SNAB-02Thread: PT 1/4 | D: 48 mm | H: 55 mm | Air flow: 0.06 m3/min
SNAB-03Thread: PT 3/8 | D: 48 mm | H: 64 mm | Air flow: 0.10 m3/min
SNAB-04Thread: PT 1/2 | D: 76 mm | H: 80 mm | Air flow: 0.15 m3/min
SNAB-06Thread: PT 3/4 | D: 76 mm | H: 80 mm | Air flow: 0.20 m3/min
SNAB-08Thread: PT 1 | D: 100 mm | H: 95 mm | Air flow: 0.40 m3/min
SNAB-10Thread: PT 1-1/4 | D: 100 mm | H: 95 mm | Air flow: 0.65 m3/min
SNAB-12Thread: PT 1-1/2 | D: 100 mm | H: 95 mm | Air flow: 0.90 m3/min
SNAB-16Thread: PT 2 | D: 100 mm | H: 95 mm | Air flow: 2.00 m3/min
