SHC SOP Oil Plug (PF 3/8 to PF 1, M18 to M24)

SHC SOP Oil Plug (PF 3/8 to PF 1, M18 to M24)

SOP plastic oil plugs serve as oil filler plugs with an air vent for gearboxes and small tanks.

Key features

  • Oil filling and air vent
  • Plastic body with O-ring
  • PF and metric threads
  • Max. temperature 80 C

Specifications

Body Plastic
Max. temperature 80 C
Brand SHC
Manufacturer Sejin Hydraulics Mfg. Co. (Korea)
Product type Oil Plug
Series SOP
Source SHC E-Catalog 2018 V1.0, p.30
SOP-10A Thread: PF 3/8 | A: 26 mm | B: 10 mm
SOP-15A Thread: PF 1/2 | A: 29 mm | B: 10 mm
SOP-20A Thread: PF 3/4 | A: 35 mm | B: 15 mm
SOP-25A Thread: PF 1 | A: 40 mm | B: 20 mm
SOP-M18 Thread: M18x1.5 | A: 27 mm | B: 9 mm
SOP-M22 Thread: M22x1.5 | A: 31 mm | B: 9 mm
SOP-M24 Thread: M24x2.0 | A: 35 mm | B: 15 mm
Oil PlugSHC
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SHC SOP Oil Plug (PF 3/8 to PF 1, M18 to M24)

Brand SHC·Oil Plug

Available part numbers (7)

SOP-10A, SOP-15A, SOP-20A, SOP-25A, SOP-M18, SOP-M22, SOP-M24

How to order

Send the SHC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SOP-10AThread: PF 3/8 | A: 26 mm | B: 10 mm
SOP-15AThread: PF 1/2 | A: 29 mm | B: 10 mm
SOP-20AThread: PF 3/4 | A: 35 mm | B: 15 mm
SOP-25AThread: PF 1 | A: 40 mm | B: 20 mm
SOP-M18Thread: M18x1.5 | A: 27 mm | B: 9 mm
SOP-M22Thread: M22x1.5 | A: 31 mm | B: 9 mm
SOP-M24Thread: M24x2.0 | A: 35 mm | B: 15 mm
