SHC SVT Oil Cooler (vertical, 510 to 10160)

SHC SVT Oil Cooler (vertical, 510 to 10160)

SVT vertical shell-and-tube oil coolers save floor space, with socket or flange connections on the oil and water sides.

Key features

  • Vertical installation
  • Max. working pressure 7 bar
  • Socket / flange oil and water sides
  • 4-pass and all-STS options

Specifications

Max. working pressure 7 bar
Flange JIS 10K
Brand SHC
Manufacturer Sejin Hydraulics Mfg. Co. (Korea)
Product type Oil Cooler
Series SVT
Source SHC E-Catalog 2018 V1.0, p.81
SVT-510-S Connections: Socket oil / socket water | A: 850 mm | Weight: 48 kg
SVT-510-F Connections: Flange oil / flange water | A: 850 mm | Weight: 48 kg
SVT-510-S-WF Connections: Socket oil / flange water | A: 850 mm | Weight: 48 kg
SVT-510-F-WS Connections: Flange oil / socket water | A: 850 mm | Weight: 48 kg
SVT-512-S Connections: Socket oil / socket water | A: 960 mm | Weight: 51 kg
SVT-512-F Connections: Flange oil / flange water | A: 960 mm | Weight: 51 kg
SVT-512-S-WF Connections: Socket oil / flange water | A: 960 mm | Weight: 51 kg
SVT-512-F-WS Connections: Flange oil / socket water | A: 960 mm | Weight: 51 kg
SVT-514-S Connections: Socket oil / socket water | A: 1075 mm | Weight: 54 kg
SVT-514-F Connections: Flange oil / flange water | A: 1075 mm | Weight: 54 kg
SVT-514-S-WF Connections: Socket oil / flange water | A: 1075 mm | Weight: 54 kg
SVT-514-F-WS Connections: Flange oil / socket water | A: 1075 mm | Weight: 54 kg
SVT-516-S Connections: Socket oil / socket water | A: 1195 mm | Weight: 57 kg
SVT-516-F Connections: Flange oil / flange water | A: 1195 mm | Weight: 57 kg
SVT-516-S-WF Connections: Socket oil / flange water | A: 1195 mm | Weight: 57 kg
SVT-516-F-WS Connections: Flange oil / socket water | A: 1195 mm | Weight: 57 kg
SVT-520-S Connections: Socket oil / socket water | A: 1305 mm | Weight: 60 kg
SVT-520-F Connections: Flange oil / flange water | A: 1305 mm | Weight: 60 kg
SVT-520-S-WF Connections: Socket oil / flange water | A: 1305 mm | Weight: 60 kg
SVT-520-F-WS Connections: Flange oil / socket water | A: 1305 mm | Weight: 60 kg
SVT-618-S Connections: Socket oil / socket water | A: 1430 mm | Weight: 63 kg
SVT-618-F Connections: Flange oil / flange water | A: 1430 mm | Weight: 63 kg
SVT-618-S-WF Connections: Socket oil / flange water | A: 1430 mm | Weight: 63 kg
SVT-618-F-WS Connections: Flange oil / socket water | A: 1430 mm | Weight: 63 kg
SVT-620-S Connections: Socket oil / socket water | A: 1043 mm | Weight: 72 kg
SVT-620-F Connections: Flange oil / flange water | A: 1043 mm | Weight: 72 kg
SVT-620-S-WF Connections: Socket oil / flange water | A: 1043 mm | Weight: 72 kg
SVT-620-F-WS Connections: Flange oil / socket water | A: 1043 mm | Weight: 72 kg
SVT-623-S Connections: Socket oil / socket water | A: 1153 mm | Weight: 76 kg
SVT-623-F Connections: Flange oil / flange water | A: 1153 mm | Weight: 76 kg
SVT-623-S-WF Connections: Socket oil / flange water | A: 1153 mm | Weight: 76 kg
SVT-623-F-WS Connections: Flange oil / socket water | A: 1153 mm | Weight: 76 kg
SVT-625-S Connections: Socket oil / socket water | A: 1223 mm | Weight: 78 kg
SVT-625-F Connections: Flange oil / flange water | A: 1223 mm | Weight: 78 kg
SVT-625-S-WF Connections: Socket oil / flange water | A: 1223 mm | Weight: 78 kg
SVT-625-F-WS Connections: Flange oil / socket water | A: 1223 mm | Weight: 78 kg
SVT-627-S Connections: Socket oil / socket water | A: 1298 mm | Weight: 81 kg
SVT-627-F Connections: Flange oil / flange water | A: 1298 mm | Weight: 81 kg
SVT-627-S-WF Connections: Socket oil / flange water | A: 1298 mm | Weight: 81 kg
SVT-627-F-WS Connections: Flange oil / socket water | A: 1298 mm | Weight: 81 kg
SVT-630-S Connections: Socket oil / socket water | A: 1403 mm | Weight: 85 kg
SVT-630-F Connections: Flange oil / flange water | A: 1403 mm | Weight: 85 kg
SVT-630-S-WF Connections: Socket oil / flange water | A: 1403 mm | Weight: 85 kg
SVT-630-F-WS Connections: Flange oil / socket water | A: 1403 mm | Weight: 85 kg
SVT-840-S Connections: Socket oil / socket water | A: 1215 mm | Weight: 140 kg
SVT-840-F Connections: Flange oil / flange water | A: 1215 mm | Weight: 140 kg
SVT-840-S-WF Connections: Socket oil / flange water | A: 1215 mm | Weight: 140 kg
SVT-840-F-WS Connections: Flange oil / socket water | A: 1215 mm | Weight: 140 kg
SVT-850-S Connections: Socket oil / socket water | A: 1315 mm | Weight: 150 kg
SVT-850-F Connections: Flange oil / flange water | A: 1315 mm | Weight: 150 kg
SVT-850-S-WF Connections: Socket oil / flange water | A: 1315 mm | Weight: 150 kg
SVT-850-F-WS Connections: Flange oil / socket water | A: 1315 mm | Weight: 150 kg
SVT-860-S Connections: Socket oil / socket water | A: 1615 mm | Weight: 160 kg
SVT-860-F Connections: Flange oil / flange water | A: 1615 mm | Weight: 160 kg
SVT-860-S-WF Connections: Socket oil / flange water | A: 1615 mm | Weight: 160 kg
SVT-860-F-WS Connections: Flange oil / socket water | A: 1615 mm | Weight: 160 kg
SVT-870-S Connections: Socket oil / socket water | A: 1835 mm | Weight: 175 kg
SVT-870-F Connections: Flange oil / flange water | A: 1835 mm | Weight: 175 kg
SVT-870-S-WF Connections: Socket oil / flange water | A: 1835 mm | Weight: 175 kg
SVT-870-F-WS Connections: Flange oil / socket water | A: 1835 mm | Weight: 175 kg
SVT-880-S Connections: Socket oil / socket water | A: 2045 mm | Weight: 190 kg
SVT-880-F Connections: Flange oil / flange water | A: 2045 mm | Weight: 190 kg
SVT-880-S-WF Connections: Socket oil / flange water | A: 2045 mm | Weight: 190 kg
SVT-880-F-WS Connections: Flange oil / socket water | A: 2045 mm | Weight: 190 kg
SVT-1080-S Connections: Socket oil / socket water | A: 1320 mm | Weight: 210 kg
SVT-1080-F Connections: Flange oil / flange water | A: 1320 mm | Weight: 210 kg
SVT-1080-S-WF Connections: Socket oil / flange water | A: 1320 mm | Weight: 210 kg
SVT-1080-F-WS Connections: Flange oil / socket water | A: 1320 mm | Weight: 210 kg
SVT-1090-S Connections: Socket oil / socket water | A: 1440 mm | Weight: 225 kg
SVT-1090-F Connections: Flange oil / flange water | A: 1440 mm | Weight: 225 kg
SVT-1090-S-WF Connections: Socket oil / flange water | A: 1440 mm | Weight: 225 kg
SVT-1090-F-WS Connections: Flange oil / socket water | A: 1440 mm | Weight: 225 kg
SVT-10100-S Connections: Socket oil / socket water | A: 1550 mm | Weight: 235 kg
SVT-10100-F Connections: Flange oil / flange water | A: 1550 mm | Weight: 235 kg
SVT-10100-S-WF Connections: Socket oil / flange water | A: 1550 mm | Weight: 235 kg
SVT-10100-F-WS Connections: Flange oil / socket water | A: 1550 mm | Weight: 235 kg
SVT-10120-S Connections: Socket oil / socket water | A: 1790 mm | Weight: 260 kg
SVT-10120-F Connections: Flange oil / flange water | A: 1790 mm | Weight: 260 kg
SVT-10120-S-WF Connections: Socket oil / flange water | A: 1790 mm | Weight: 260 kg
SVT-10120-F-WS Connections: Flange oil / socket water | A: 1790 mm | Weight: 260 kg
SVT-10140-S Connections: Socket oil / socket water | A: 2030 mm | Weight: 280 kg
SVT-10140-F Connections: Flange oil / flange water | A: 2030 mm | Weight: 280 kg
SVT-10140-S-WF Connections: Socket oil / flange water | A: 2030 mm | Weight: 280 kg
SVT-10140-F-WS Connections: Flange oil / socket water | A: 2030 mm | Weight: 280 kg
SVT-10160-S Connections: Socket oil / socket water | A: 2270 mm | Weight: 310 kg
SVT-10160-F Connections: Flange oil / flange water | A: 2270 mm | Weight: 310 kg
SVT-10160-S-WF Connections: Socket oil / flange water | A: 2270 mm | Weight: 310 kg
SVT-10160-F-WS Connections: Flange oil / socket water | A: 2270 mm | Weight: 310 kg
