Siemens SIMATIC ET 200pro Analog I/O Modules (4 AI U/I/RTD/TC, 4 AO)

Siemens SIMATIC ET 200pro Analog I/O Modules (4 AI U/I/RTD/TC, 4 AO)

SIMATIC ET 200pro High Feature analog expansion modules for voltage, current, RTD and thermocouple signals.

Key features

  • 4-channel analog input modules for U, I, RTD and TC
  • 4-channel analog output modules for voltage or current
  • High Feature with channel-specific diagnostics
  • Bus module included; connection module ordered separately
  • M12 compensation connector with Pt100 for TC cold-junction compensation

Specifications

Brand Siemens
Product line SIMATIC ET 200pro
Category Analog expansion modules
Channels 4
Version High Feature
Scope Incl. bus module
Variants listed 7
Source Siemens Catalog ST 70 · 2026, p. 1900
6ES7144-4FF01-0AB0 Type: 4AI U | Signal: Voltage input | Ranges: ±10 V, ±5 V, 0-10 V, 1-5 V
6ES7144-4GF01-0AB0 Type: 4AI I | Signal: Current input | Ranges: ±20 mA, 0-20 mA, 4-20 mA
6ES7144-4JF00-0AB0 Type: 4AI RTD | Signal: Resistance / RTD input | Ranges: Pt100...Pt1000, Ni100...Ni1000
6ES7144-4PF00-0AB0 Type: 4AI TC | Signal: Thermocouple input | Ranges: Types B,E,J,K,L,N,R,S,T; ±80 mV
6ES7145-4FF00-0AB0 Type: 4AO U | Signal: Voltage output | Ranges: ±10 V, 0-10 V, 1-5 V
6ES7145-4GF00-0AB0 Type: 4AO I | Signal: Current output | Ranges: ±20 mA, 0-20 mA, 4-20 mA
6ES7194-4AB00-0AA0 Type: M12 compensation connector | Signal: Accessory | Ranges: Integral Pt100 for CJC
PLC I/O ModulesSiemens
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Siemens SIMATIC ET 200pro Analog I/O Modules (4 AI U/I/RTD/TC, 4 AO)

Brand Siemens·PLC I/O Modules

Available part numbers (7)

6ES7144-4FF01-0AB0, 6ES7144-4GF01-0AB0, 6ES7144-4JF00-0AB0, 6ES7144-4PF00-0AB0, 6ES7145-4FF00-0AB0, 6ES7145-4GF00-0AB0, 6ES7194-4AB00-0AA0

How to order

Send the Siemens part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
6ES7144-4FF01-0AB0Type: 4AI U | Signal: Voltage input | Ranges: ±10 V, ±5 V, 0-10 V, 1-5 V
6ES7144-4GF01-0AB0Type: 4AI I | Signal: Current input | Ranges: ±20 mA, 0-20 mA, 4-20 mA
6ES7144-4JF00-0AB0Type: 4AI RTD | Signal: Resistance / RTD input | Ranges: Pt100...Pt1000, Ni100...Ni1000
6ES7144-4PF00-0AB0Type: 4AI TC | Signal: Thermocouple input | Ranges: Types B,E,J,K,L,N,R,S,T; ±80 mV
6ES7145-4FF00-0AB0Type: 4AO U | Signal: Voltage output | Ranges: ±10 V, 0-10 V, 1-5 V
6ES7145-4GF00-0AB0Type: 4AO I | Signal: Current output | Ranges: ±20 mA, 0-20 mA, 4-20 mA
6ES7194-4AB00-0AA0Type: M12 compensation connector | Signal: Accessory | Ranges: Integral Pt100 for CJC
