SUNGIL SATP-2GT Timing Pulley (Side Clamp, SC)

SUNGIL SATP-2GT Timing Pulley (Side Clamp, SC)

High-strength aluminum alloy 2GT timing pulleys with an integral slit side-clamp hub, tightened by a single SCM435 fastening screw for quick, keyless shaft mounting.

Key features

  • Side-clamp hub fastened with one SCM435 screw
  • Quick installation and removal without set screws
  • High-strength aluminum alloy body, white anodized
  • Keyway machining available on request (K + b size)
  • Compact hub dimensions for space-limited drives

Specifications

Tooth profile 2GT, pitch 2 mm
Clamping method SC (side clamp)
Body material High strength aluminum alloy
Fastening screw SCM435, black oxide
No. of teeth 27-72
Belt width codes BW040 (4 mm), BW060 (6 mm)
Standard bores (d) see table mm
Surface treatment WA white anodizing
Keyway Available (K + b size)
Ordering code SATP-2GT-NT__-BW___-SC-(d)-(K_)-WA
Source SUNGIL Catalogue (EN), Timing Pulley section
SATP-2GT-NT27-BW040-SC PCD: 17.2 mm | OD: 16.7 mm | Hub D x L: 10x6 mm | Screw: M1.6 | Bore d: 3 mm
SATP-2GT-NT27-BW060-SC PCD: 17.2 mm | OD: 16.7 mm | Hub D x L: 10x6 mm | Screw: M1.6 | Bore d: 3 mm
SATP-2GT-NT28-BW040-SC PCD: 17.8 mm | OD: 17.3 mm | Hub D x L: 10x6 mm | Screw: M1.6 | Bore d: 3 mm
SATP-2GT-NT28-BW060-SC PCD: 17.8 mm | OD: 17.3 mm | Hub D x L: 10x6 mm | Screw: M1.6 | Bore d: 3 mm
SATP-2GT-NT29-BW040-SC PCD: 18.5 mm | OD: 18 mm | Hub D x L: 10x6 mm | Screw: M1.6 | Bore d: 3 mm
SATP-2GT-NT29-BW060-SC PCD: 18.5 mm | OD: 18 mm | Hub D x L: 10x6 mm | Screw: M1.6 | Bore d: 3 mm
SATP-2GT-NT30-BW040-SC PCD: 19.1 mm | OD: 18.6 mm | Hub D x L: 12x7 mm | Screw: M2 | Bore d: 3 ~ 5 mm
SATP-2GT-NT30-BW060-SC PCD: 19.1 mm | OD: 18.6 mm | Hub D x L: 12x7 mm | Screw: M2 | Bore d: 3 ~ 5 mm
SATP-2GT-NT32-BW040-SC PCD: 20.4 mm | OD: 19.9 mm | Hub D x L: 12x7 mm | Screw: M2 | Bore d: 3 ~ 5 mm
SATP-2GT-NT32-BW060-SC PCD: 20.4 mm | OD: 19.9 mm | Hub D x L: 12x7 mm | Screw: M2 | Bore d: 3 ~ 5 mm
SATP-2GT-NT34-BW040-SC PCD: 21.7 mm | OD: 21.1 mm | Hub D x L: 14x7 mm | Screw: M2 | Bore d: 3 ~ 6 mm
SATP-2GT-NT34-BW060-SC PCD: 21.7 mm | OD: 21.1 mm | Hub D x L: 14x7 mm | Screw: M2 | Bore d: 3 ~ 6 mm
SATP-2GT-NT36-BW040-SC PCD: 22.9 mm | OD: 22.4 mm | Hub D x L: 14x7 mm | Screw: M2 | Bore d: 3 ~ 6 mm
SATP-2GT-NT36-BW060-SC PCD: 22.9 mm | OD: 22.4 mm | Hub D x L: 14x7 mm | Screw: M2 | Bore d: 3 ~ 6 mm
SATP-2GT-NT38-BW040-SC PCD: 24.2 mm | OD: 23.7 mm | Hub D x L: 18x7.5 mm | Screw: M2 | Bore d: 3 ~ 8 mm
SATP-2GT-NT38-BW060-SC PCD: 24.2 mm | OD: 23.7 mm | Hub D x L: 18x7.5 mm | Screw: M2 | Bore d: 3 ~ 8 mm
SATP-2GT-NT40-BW040-SC PCD: 25.5 mm | OD: 25 mm | Hub D x L: 18x7.5 mm | Screw: M2 | Bore d: 3 ~ 8 mm
SATP-2GT-NT40-BW060-SC PCD: 25.5 mm | OD: 25 mm | Hub D x L: 18x7.5 mm | Screw: M2 | Bore d: 3 ~ 8 mm
SATP-2GT-NT44-BW040-SC PCD: 28 mm | OD: 27.5 mm | Hub D x L: 20x7.5 mm | Screw: M2 | Bore d: 5 ~ 10 mm
SATP-2GT-NT44-BW060-SC PCD: 28 mm | OD: 27.5 mm | Hub D x L: 20x7.5 mm | Screw: M2 | Bore d: 5 ~ 10 mm
SATP-2GT-NT48-BW040-SC PCD: 30.6 mm | OD: 30.1 mm | Hub D x L: 20x7.5 mm | Screw: M2 | Bore d: 5 ~ 10 mm
SATP-2GT-NT48-BW060-SC PCD: 30.6 mm | OD: 30.1 mm | Hub D x L: 20x7.5 mm | Screw: M2 | Bore d: 5 ~ 10 mm
SATP-2GT-NT50-BW040-SC PCD: 31.8 mm | OD: 31.3 mm | Hub D x L: 20x7.5 mm | Screw: M2 | Bore d: 5 ~ 10 mm
SATP-2GT-NT50-BW060-SC PCD: 31.8 mm | OD: 31.3 mm | Hub D x L: 20x7.5 mm | Screw: M2 | Bore d: 5 ~ 10 mm
SATP-2GT-NT60-BW040-SC PCD: 38.2 mm | OD: 37.7 mm | Hub D x L: 30x11 mm | Screw: M3 | Bore d: 8 ~ 14 mm
SATP-2GT-NT60-BW060-SC PCD: 38.2 mm | OD: 37.7 mm | Hub D x L: 30x11 mm | Screw: M3 | Bore d: 8 ~ 14 mm
SATP-2GT-NT72-BW040-SC PCD: 45.8 mm | OD: 45.3 mm | Hub D x L: 38x14.3 mm | Screw: M4 | Bore d: 8 ~ 20 mm
SATP-2GT-NT72-BW060-SC PCD: 45.8 mm | OD: 45.3 mm | Hub D x L: 38x14.3 mm | Screw: M4 | Bore d: 8 ~ 20 mm
Timing PulleySUNGIL
28 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SUNGIL SATP-2GT Timing Pulley (Side Clamp, SC)

Brand SUNGIL·Timing Pulley

Available part numbers (28)

SATP-2GT-NT27-BW040-SC, SATP-2GT-NT27-BW060-SC, SATP-2GT-NT28-BW040-SC, SATP-2GT-NT28-BW060-SC, SATP-2GT-NT29-BW040-SC, SATP-2GT-NT29-BW060-SC, SATP-2GT-NT30-BW040-SC, SATP-2GT-NT30-BW060-SC, SATP-2GT-NT32-BW040-SC, SATP-2GT-NT32-BW060-SC + 18 more — see full table ↓

How to order

Send the SUNGIL part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SATP-2GT-NT27-BW040-SCPCD: 17.2 mm | OD: 16.7 mm | Hub D x L: 10x6 mm | Screw: M1.6 | Bore d: 3 mm
SATP-2GT-NT27-BW060-SCPCD: 17.2 mm | OD: 16.7 mm | Hub D x L: 10x6 mm | Screw: M1.6 | Bore d: 3 mm
SATP-2GT-NT28-BW040-SCPCD: 17.8 mm | OD: 17.3 mm | Hub D x L: 10x6 mm | Screw: M1.6 | Bore d: 3 mm
SATP-2GT-NT28-BW060-SCPCD: 17.8 mm | OD: 17.3 mm | Hub D x L: 10x6 mm | Screw: M1.6 | Bore d: 3 mm
SATP-2GT-NT29-BW040-SCPCD: 18.5 mm | OD: 18 mm | Hub D x L: 10x6 mm | Screw: M1.6 | Bore d: 3 mm
SATP-2GT-NT29-BW060-SCPCD: 18.5 mm | OD: 18 mm | Hub D x L: 10x6 mm | Screw: M1.6 | Bore d: 3 mm
SATP-2GT-NT30-BW040-SCPCD: 19.1 mm | OD: 18.6 mm | Hub D x L: 12x7 mm | Screw: M2 | Bore d: 3 ~ 5 mm
SATP-2GT-NT30-BW060-SCPCD: 19.1 mm | OD: 18.6 mm | Hub D x L: 12x7 mm | Screw: M2 | Bore d: 3 ~ 5 mm
SATP-2GT-NT32-BW040-SCPCD: 20.4 mm | OD: 19.9 mm | Hub D x L: 12x7 mm | Screw: M2 | Bore d: 3 ~ 5 mm
SATP-2GT-NT32-BW060-SCPCD: 20.4 mm | OD: 19.9 mm | Hub D x L: 12x7 mm | Screw: M2 | Bore d: 3 ~ 5 mm
SATP-2GT-NT34-BW040-SCPCD: 21.7 mm | OD: 21.1 mm | Hub D x L: 14x7 mm | Screw: M2 | Bore d: 3 ~ 6 mm
SATP-2GT-NT34-BW060-SCPCD: 21.7 mm | OD: 21.1 mm | Hub D x L: 14x7 mm | Screw: M2 | Bore d: 3 ~ 6 mm
SATP-2GT-NT36-BW040-SCPCD: 22.9 mm | OD: 22.4 mm | Hub D x L: 14x7 mm | Screw: M2 | Bore d: 3 ~ 6 mm
SATP-2GT-NT36-BW060-SCPCD: 22.9 mm | OD: 22.4 mm | Hub D x L: 14x7 mm | Screw: M2 | Bore d: 3 ~ 6 mm
SATP-2GT-NT38-BW040-SCPCD: 24.2 mm | OD: 23.7 mm | Hub D x L: 18x7.5 mm | Screw: M2 | Bore d: 3 ~ 8 mm
SATP-2GT-NT38-BW060-SCPCD: 24.2 mm | OD: 23.7 mm | Hub D x L: 18x7.5 mm | Screw: M2 | Bore d: 3 ~ 8 mm
SATP-2GT-NT40-BW040-SCPCD: 25.5 mm | OD: 25 mm | Hub D x L: 18x7.5 mm | Screw: M2 | Bore d: 3 ~ 8 mm
SATP-2GT-NT40-BW060-SCPCD: 25.5 mm | OD: 25 mm | Hub D x L: 18x7.5 mm | Screw: M2 | Bore d: 3 ~ 8 mm
SATP-2GT-NT44-BW040-SCPCD: 28 mm | OD: 27.5 mm | Hub D x L: 20x7.5 mm | Screw: M2 | Bore d: 5 ~ 10 mm
SATP-2GT-NT44-BW060-SCPCD: 28 mm | OD: 27.5 mm | Hub D x L: 20x7.5 mm | Screw: M2 | Bore d: 5 ~ 10 mm
SATP-2GT-NT48-BW040-SCPCD: 30.6 mm | OD: 30.1 mm | Hub D x L: 20x7.5 mm | Screw: M2 | Bore d: 5 ~ 10 mm
SATP-2GT-NT48-BW060-SCPCD: 30.6 mm | OD: 30.1 mm | Hub D x L: 20x7.5 mm | Screw: M2 | Bore d: 5 ~ 10 mm
SATP-2GT-NT50-BW040-SCPCD: 31.8 mm | OD: 31.3 mm | Hub D x L: 20x7.5 mm | Screw: M2 | Bore d: 5 ~ 10 mm
SATP-2GT-NT50-BW060-SCPCD: 31.8 mm | OD: 31.3 mm | Hub D x L: 20x7.5 mm | Screw: M2 | Bore d: 5 ~ 10 mm
SATP-2GT-NT60-BW040-SCPCD: 38.2 mm | OD: 37.7 mm | Hub D x L: 30x11 mm | Screw: M3 | Bore d: 8 ~ 14 mm
SATP-2GT-NT60-BW060-SCPCD: 38.2 mm | OD: 37.7 mm | Hub D x L: 30x11 mm | Screw: M3 | Bore d: 8 ~ 14 mm
SATP-2GT-NT72-BW040-SCPCD: 45.8 mm | OD: 45.3 mm | Hub D x L: 38x14.3 mm | Screw: M4 | Bore d: 8 ~ 20 mm
SATP-2GT-NT72-BW060-SCPCD: 45.8 mm | OD: 45.3 mm | Hub D x L: 38x14.3 mm | Screw: M4 | Bore d: 8 ~ 20 mm
