Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| NTSS-30 | Shank: BT30 | L (mm): 95 | l1 (mm): 65 | l2 (mm): 80 | l3 (mm): 7.5 | l4 (mm): 33 | H (mm): 100 | W (mm): 58 | Package weight (kg): 1 | Stock: Yes | ||
| NTSS-40 | Shank: BT40 | L (mm): 118 | l1 (mm): 77 | l2 (mm): 99 | l3 (mm): 9.2 | l4 (mm): 44 | H (mm): 130 | W (mm): 75 | Package weight (kg): 1.7 | Stock: Yes | ||
| NTSS-50 | Shank: BT50 | L (mm): 275 | l1 (mm): 113 | l2 (mm): 20 | l3 (mm): 24 | l4 (mm): 105 | H (mm): 200 | W (mm): 150 | Package weight (kg): 11.4 | Stock: Yes | ||
| NTSS-HSK63A | Shank: HSK63A | L (mm): 106 | l1 (mm): 11 | l2 (mm): 11 | l3 (mm): 50 | l4 (mm): 9 | H (mm): 160 | W (mm): 106 | Package weight (kg): 4.1 | Stock: Yes |
Need a different model, or a part not listed here? Send us your parts list →
