WIDIN EB302140W Carbide Ball End Mill

WIDIN EB302140W Carbide Ball End Mill

WIDIN EB302140W Carbide Ball End Mill is a solid carbide cutting tool designed for precision milling of contoured and 3D surfaces, sourced direct from Korea.

Key features

  • Ball end mills of this type are widely used in mold and die machining, aerospace component finishing, and general CNC profiling where curved geometries and smooth surface finishes are required
386-6373 MPN: EB302140W | 2F*14MM(EB302140) | Spec: 14 | Cutting Length: 28 | Number of Flutes: 2 | Overall Length: 98 | Shank Length: 60 | Shank Diameter: 16
386-6391 MPN: EB302150W | 2F*15MM(EB302150) | Spec: 15 | Cutting Length: 28 | Number of Flutes: 2F | Overall Length: 98 | Shank length: 60 | Shank Diameter: 16
386-6407 MPN: EB302160W | 2F*16MM(EB302160) | Spec: 16 | Cutting Length: 28 | Number of Flutes: 2F | Overall Length: 98 | Shank length: 60 | Shank Diameter: 16
386-6425 MPN: EB302170W | 2F*17MM(EB302170) | Spec: 17 | Cutting Length: 32 | Number of Flutes: 2F | Overall Length: 115 | Shank length: 70 | Shank Diameter: 20
386-6434 MPN: EB302180W | 2F*18MM(EB302180) | Spec: 18 | Cutting Length: 32 | Number of Flutes: 2F | Overall Length: 115 | Shank length: 70 | Shank Diameter: 20
386-6461 MPN: EB302200W | 2F*20MM(EB302200) | Spec: 20 | Cutting Length: 32 | Number of Flutes: 2F | Overall Length: 115 | Shank length: 70 | Shank Diameter: 20
386-6522 MPN: EB302240W | 2F*24MM(EB302240) | Spec: 24 | Cutting Length: 40 | Number of Flutes: 2F | Overall Length: 140 | Shank length: 85 | Shank Diameter: 25
386-6540 MPN: EB302250W | 2F*25MM(EB302250) | Spec: 25 | Cutting Length: 40 | Number of Flutes: 2F | Overall Length: 140 | Shank length: 85 | Shank Diameter: 25
386-6559 MPN: EB302260W | 2F*26MM(EB302260) | Spec: 26 | Cutting Length: 40 | Number of Flutes: 2F | Overall Length: 140 | Shank length: 85 | Shank Diameter: 25
386-6577 MPN: EB302280W | 2F*28MM(EB302280) | Spec: 28 | Cutting Length: 40 | Number of Flutes: 2F | Overall Length: 140 | Shank length: 85 | Shank Diameter: 25
386-6586 MPN: EB302300W | 2F*30MM(EB302300) | Spec: 30 | Cutting Length: 50 | Number of Flutes: 2F | Overall Length: 150 | Shank length: 85 | Shank Diameter: 32
386-6601 MPN: EB302320W | 2F*32MM(EB302320) | Spec: 32 | Cutting Length: 50 | Number of Flutes: 2 | Overall Length: 150 | Shank Length: 85 | Shank Diameter: 32
386-6610 MPN: EB302350W | 2F*35MM(EB302350) | Spec: 35 | Cutting Length: 50 | Number of Flutes: 2 | Overall Length: 150 | Shank Length: 85 | Shank Diameter: 32
386-6629 MPN: EB302400W | 2F*40MM(EB302400W) | Spec: 40 | Cutting Length: 55 | Number of Flutes: 2F | Overall Length: 155 | Shank length: 85 | Shank Diameter: 32
386-6638 MPN: EB302450W | 2F*45MM(EB302450) | Spec: 45 | Cutting Length: 63 | Number of Flutes: 2F | Overall Length: 160 | Shank length: 85 | Shank Diameter: 32
End MillsWIDIN
15 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

WIDIN EB302140W Carbide Ball End Mill

Brand WIDIN·End Mills

Available part numbers (15)

386-6373, 386-6391, 386-6407, 386-6425, 386-6434, 386-6461, 386-6522, 386-6540, 386-6559, 386-6577 + 5 more — see full table ↓

How to order

Send the WIDIN part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
386-6373MPN: EB302140W | 2F*14MM(EB302140) | Spec: 14 | Cutting Length: 28 | Number of Flutes: 2 | Overall Length: 98 | Shank Length: 60 | Shank Diameter: 16
386-6391MPN: EB302150W | 2F*15MM(EB302150) | Spec: 15 | Cutting Length: 28 | Number of Flutes: 2F | Overall Length: 98 | Shank length: 60 | Shank Diameter: 16
386-6407MPN: EB302160W | 2F*16MM(EB302160) | Spec: 16 | Cutting Length: 28 | Number of Flutes: 2F | Overall Length: 98 | Shank length: 60 | Shank Diameter: 16
386-6425MPN: EB302170W | 2F*17MM(EB302170) | Spec: 17 | Cutting Length: 32 | Number of Flutes: 2F | Overall Length: 115 | Shank length: 70 | Shank Diameter: 20
386-6434MPN: EB302180W | 2F*18MM(EB302180) | Spec: 18 | Cutting Length: 32 | Number of Flutes: 2F | Overall Length: 115 | Shank length: 70 | Shank Diameter: 20
386-6461MPN: EB302200W | 2F*20MM(EB302200) | Spec: 20 | Cutting Length: 32 | Number of Flutes: 2F | Overall Length: 115 | Shank length: 70 | Shank Diameter: 20
386-6522MPN: EB302240W | 2F*24MM(EB302240) | Spec: 24 | Cutting Length: 40 | Number of Flutes: 2F | Overall Length: 140 | Shank length: 85 | Shank Diameter: 25
386-6540MPN: EB302250W | 2F*25MM(EB302250) | Spec: 25 | Cutting Length: 40 | Number of Flutes: 2F | Overall Length: 140 | Shank length: 85 | Shank Diameter: 25
386-6559MPN: EB302260W | 2F*26MM(EB302260) | Spec: 26 | Cutting Length: 40 | Number of Flutes: 2F | Overall Length: 140 | Shank length: 85 | Shank Diameter: 25
386-6577MPN: EB302280W | 2F*28MM(EB302280) | Spec: 28 | Cutting Length: 40 | Number of Flutes: 2F | Overall Length: 140 | Shank length: 85 | Shank Diameter: 25
386-6586MPN: EB302300W | 2F*30MM(EB302300) | Spec: 30 | Cutting Length: 50 | Number of Flutes: 2F | Overall Length: 150 | Shank length: 85 | Shank Diameter: 32
386-6601MPN: EB302320W | 2F*32MM(EB302320) | Spec: 32 | Cutting Length: 50 | Number of Flutes: 2 | Overall Length: 150 | Shank Length: 85 | Shank Diameter: 32
386-6610MPN: EB302350W | 2F*35MM(EB302350) | Spec: 35 | Cutting Length: 50 | Number of Flutes: 2 | Overall Length: 150 | Shank Length: 85 | Shank Diameter: 32
386-6629MPN: EB302400W | 2F*40MM(EB302400W) | Spec: 40 | Cutting Length: 55 | Number of Flutes: 2F | Overall Length: 155 | Shank length: 85 | Shank Diameter: 32
386-6638MPN: EB302450W | 2F*45MM(EB302450) | Spec: 45 | Cutting Length: 63 | Number of Flutes: 2F | Overall Length: 160 | Shank length: 85 | Shank Diameter: 32

Need a different model, or a part not listed here? Send us your parts list →
