• WIDIN EB304140W Carbide Ball End Mill
1 1

WIDIN EB304140W Carbide Ball End Mill

WIDIN EB304140W Carbide Ball End Mill

WIDIN EB304140W Carbide Ball End Mill is a solid carbide cutting tool designed for precision milling of contoured surfaces and complex 3D profiles, sourced direct from Korea.

Key features

  • Ball end mills of this type are widely used in mold and die machining, aerospace component finishing, and general CNC work where smooth curved surfaces and accurate radius profiles are required
386-6656 MPN: EB304140W | 4F*14MM(EB304140) | Spec: 14 | Cutting Length: 28 | Number of Flutes: 4F | Overall Length: 98 | Shank length: 60 | Shank Diameter: 16
386-6665 MPN: EB304150W | 4F*15MM(EB304150) | Spec: 15 | Cutting Length: 28 | Number of Flutes: 4F | Overall Length: 98 | Shank length: 60 | Shank Diameter: 16
386-6674 MPN: EB304160W | 4F*16MM(EB304160) | Spec: 16 | Cutting Length: 28 | Number of Flutes: 4F | Overall Length: 98 | Shank length: 60 | Shank Diameter: 16
386-6683 MPN: EB304170W | 4F*17MM(EB304170) | Spec: 17 | Cutting Length: 32 | Number of Flutes: 4F | Overall Length: 115 | Shank length: 70 | Shank Diameter: 20
386-6692 MPN: EB304180W | 4F*18MM(EB304180) | Spec: 18 | Cutting Length: 32 | Number of Flutes: 4F | Overall Length: 115 | Shank length: 70 | Shank Diameter: 20
386-6717 MPN: EB304200W | 4F*20MM(EB304200) | Spec: 20 | Cutting Length: 32 | Number of Flutes: 4F | Overall Length: 115 | Shank length: 70 | Shank Diameter: 20
386-6780 MPN: EB304250W | 4F*25MM(EB304250) | Spec: 25 | Cutting Length: 40 | Number of Flutes: 4F | Overall Length: 140 | Shank length: 85 | Shank Diameter: 25
386-6814 MPN: EB304280W | 4F*28MM(EB304280) | Spec: 28 | Cutting Length: 40 | Number of Flutes: 4F | Overall Length: 140 | Shank length: 85 | Shank Diameter: 25
386-6823 MPN: EB304300W | 4F*30MM(EB304300) | Spec: 30 | Cutting Length: 50 | Number of Flutes: 4F | Overall Length: 150 | Shank length: 85 | Shank Diameter: 32
386-6832 MPN: EB304320W | 4F*32MM(EB304320) | Spec: 32 | Cutting Length: 50 | Number of Flutes: 4F | Overall Length: 150 | Shank length: 85 | Shank Diameter: 32
386-6841 MPN: EB304350W | 4F*35MM(EB304350) | Spec: 35 | Cutting Length: 50 | Number of Flutes: 4F | Overall Length: 150 | Shank length: 85 | Shank Diameter: 32
386-6911 MPN: EB304450W | 4F*45MM(EB304450) | Spec: 45 | Cutting Length: 63 | Number of Flutes: 4 | Overall Length: 160 | Shank Length: 85 | Shank Diameter: 32
386-6939 MPN: EB304500W | 4F*50MM(EB304500) | Spec: 50 | Cutting Length: 63 | Number of Flutes: 4F | Overall Length: 160 | Shank length: 85 | Shank Diameter: 32
End MillsWIDIN
13 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

WIDIN EB304140W Carbide Ball End Mill

Brand WIDIN·End Mills

Available part numbers (13)

386-6656, 386-6665, 386-6674, 386-6683, 386-6692, 386-6717, 386-6780, 386-6814, 386-6823, 386-6832 + 3 more — see full table ↓

How to order

Send the WIDIN part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
386-6656MPN: EB304140W | 4F*14MM(EB304140) | Spec: 14 | Cutting Length: 28 | Number of Flutes: 4F | Overall Length: 98 | Shank length: 60 | Shank Diameter: 16
386-6665MPN: EB304150W | 4F*15MM(EB304150) | Spec: 15 | Cutting Length: 28 | Number of Flutes: 4F | Overall Length: 98 | Shank length: 60 | Shank Diameter: 16
386-6674MPN: EB304160W | 4F*16MM(EB304160) | Spec: 16 | Cutting Length: 28 | Number of Flutes: 4F | Overall Length: 98 | Shank length: 60 | Shank Diameter: 16
386-6683MPN: EB304170W | 4F*17MM(EB304170) | Spec: 17 | Cutting Length: 32 | Number of Flutes: 4F | Overall Length: 115 | Shank length: 70 | Shank Diameter: 20
386-6692MPN: EB304180W | 4F*18MM(EB304180) | Spec: 18 | Cutting Length: 32 | Number of Flutes: 4F | Overall Length: 115 | Shank length: 70 | Shank Diameter: 20
386-6717MPN: EB304200W | 4F*20MM(EB304200) | Spec: 20 | Cutting Length: 32 | Number of Flutes: 4F | Overall Length: 115 | Shank length: 70 | Shank Diameter: 20
386-6780MPN: EB304250W | 4F*25MM(EB304250) | Spec: 25 | Cutting Length: 40 | Number of Flutes: 4F | Overall Length: 140 | Shank length: 85 | Shank Diameter: 25
386-6814MPN: EB304280W | 4F*28MM(EB304280) | Spec: 28 | Cutting Length: 40 | Number of Flutes: 4F | Overall Length: 140 | Shank length: 85 | Shank Diameter: 25
386-6823MPN: EB304300W | 4F*30MM(EB304300) | Spec: 30 | Cutting Length: 50 | Number of Flutes: 4F | Overall Length: 150 | Shank length: 85 | Shank Diameter: 32
386-6832MPN: EB304320W | 4F*32MM(EB304320) | Spec: 32 | Cutting Length: 50 | Number of Flutes: 4F | Overall Length: 150 | Shank length: 85 | Shank Diameter: 32
386-6841MPN: EB304350W | 4F*35MM(EB304350) | Spec: 35 | Cutting Length: 50 | Number of Flutes: 4F | Overall Length: 150 | Shank length: 85 | Shank Diameter: 32
386-6911MPN: EB304450W | 4F*45MM(EB304450) | Spec: 45 | Cutting Length: 63 | Number of Flutes: 4 | Overall Length: 160 | Shank Length: 85 | Shank Diameter: 32
386-6939MPN: EB304500W | 4F*50MM(EB304500) | Spec: 50 | Cutting Length: 63 | Number of Flutes: 4F | Overall Length: 160 | Shank length: 85 | Shank Diameter: 32
