Woonyoung General Transformer WY2224-AP Series (220 V to 24 V)

Woonyoung General Transformer WY2224-AP Series (220 V to 24 V)

Economical single-phase isolation transformer with AC 220 V input and AC 24 V output, with an LED indicating that power is applied.

Key features

  • Power indicator LED
  • Single tap for economical general use
  • CE certified
  • Insulation class B

Specifications

Phase Single phase
Type WT (terminal block)
Primary (V) 0-220
Secondary (V) 0-24-(E)
Insulation class B
WY2224-40AP Capacity: 40 VA | Secondary current (A): 1.6 | Dimensions W x H x D (mm): 79 x 89 x 83 | Weight (kg): 1.31
WY2224-60AP Capacity: 60 VA | Secondary current (A): 2.5 | Dimensions W x H x D (mm): 79 x 89 x 88 | Weight (kg): 1.65
WY2224-80AP Capacity: 80 VA | Secondary current (A): 3.3 | Dimensions W x H x D (mm): 89 x 98 x 105 | Weight (kg): 2.30
WY2224-100AP Capacity: 100 VA | Secondary current (A): 4 | Dimensions W x H x D (mm): 98 x 106 x 105 | Weight (kg): 2.59
WY2224-150AP Capacity: 150 VA | Secondary current (A): 6 | Dimensions W x H x D (mm): 112 x 106 x 105 | Weight (kg): 3.45
WY2224-200AP Capacity: 200 VA | Secondary current (A): 8 | Dimensions W x H x D (mm): 112 x 114 x 110 | Weight (kg): 3.60
WY2224-300AP Capacity: 300 VA | Secondary current (A): 12.5 | Dimensions W x H x D (mm): 121 x 122 x 114 | Weight (kg): 4.97
WY2224-500AP Capacity: 500 VA | Secondary current (A): 20 | Dimensions W x H x D (mm): 140 x 140 x 126 | Weight (kg): 7.10
WY2224-750AP Capacity: 750 VA | Secondary current (A): 30 | Dimensions W x H x D (mm): 160 x 162 x 146 | Weight (kg): 10.70
WY2224-1KAP Capacity: 1 kVA | Secondary current (A): 40 | Dimensions W x H x D (mm): 160 x 160 x 157 | Weight (kg): 12.30
WY2224-1.5KAP Capacity: 1.5 kVA | Secondary current (A): 60 | Dimensions W x H x D (mm): 185 x 188 x 151 | Weight (kg): 17.00
WY2224-2KAP Capacity: 2 kVA | Secondary current (A): 80 | Dimensions W x H x D (mm): 185 x 188 x 171 | Weight (kg): 20.10
Control TransformersWoonyoung
12 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Woonyoung General Transformer WY2224-AP Series (220 V to 24 V)

Brand Woonyoung·Control Transformers

Available part numbers (12)

WY2224-40AP, WY2224-60AP, WY2224-80AP, WY2224-100AP, WY2224-150AP, WY2224-200AP, WY2224-300AP, WY2224-500AP, WY2224-750AP, WY2224-1KAP + 2 more — see full table ↓

How to order

Send the Woonyoung part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
WY2224-40APCapacity: 40 VA | Secondary current (A): 1.6 | Dimensions W x H x D (mm): 79 x 89 x 83 | Weight (kg): 1.31
WY2224-60APCapacity: 60 VA | Secondary current (A): 2.5 | Dimensions W x H x D (mm): 79 x 89 x 88 | Weight (kg): 1.65
WY2224-80APCapacity: 80 VA | Secondary current (A): 3.3 | Dimensions W x H x D (mm): 89 x 98 x 105 | Weight (kg): 2.30
WY2224-100APCapacity: 100 VA | Secondary current (A): 4 | Dimensions W x H x D (mm): 98 x 106 x 105 | Weight (kg): 2.59
WY2224-150APCapacity: 150 VA | Secondary current (A): 6 | Dimensions W x H x D (mm): 112 x 106 x 105 | Weight (kg): 3.45
WY2224-200APCapacity: 200 VA | Secondary current (A): 8 | Dimensions W x H x D (mm): 112 x 114 x 110 | Weight (kg): 3.60
WY2224-300APCapacity: 300 VA | Secondary current (A): 12.5 | Dimensions W x H x D (mm): 121 x 122 x 114 | Weight (kg): 4.97
WY2224-500APCapacity: 500 VA | Secondary current (A): 20 | Dimensions W x H x D (mm): 140 x 140 x 126 | Weight (kg): 7.10
WY2224-750APCapacity: 750 VA | Secondary current (A): 30 | Dimensions W x H x D (mm): 160 x 162 x 146 | Weight (kg): 10.70
WY2224-1KAPCapacity: 1 kVA | Secondary current (A): 40 | Dimensions W x H x D (mm): 160 x 160 x 157 | Weight (kg): 12.30
WY2224-1.5KAPCapacity: 1.5 kVA | Secondary current (A): 60 | Dimensions W x H x D (mm): 185 x 188 x 151 | Weight (kg): 17.00
WY2224-2KAPCapacity: 2 kVA | Secondary current (A): 80 | Dimensions W x H x D (mm): 185 x 188 x 171 | Weight (kg): 20.10
